Foam::ensightOutput Namespace Reference

A collection of functions for writing ensight file content. More...

Namespaces
	Detail

Functions
template<class Type >
bool	writeAreaField (ensightFile &os, const GeometricField< Type, faPatchField, areaMesh > &fld, const ensightFaMesh &ensMesh)
template<class Type >
bool	writeVolField (ensightFile &os, const GeometricField< Type, fvPatchField, volMesh > &vf, const ensightMesh &ensMesh)
template<class Type >
bool	writeVolField (ensightFile &os, const GeometricField< Type, fvPatchField, volMesh > &vf, const ensightMesh &ensMesh, const bool nodeValues)
template<class Type >
bool	writePointField (ensightFile &os, const GeometricField< Type, pointPatchField, pointMesh > &pf, const ensightMesh &ensMesh)
void	writeFaceList (ensightGeoFile &os, const UList< face > &faces)
void	writeFaceList (ensightGeoFile &os, const UIndirectList< face > &faces)
void	writeCellShapes (ensightGeoFile &os, const UList< cellShape > &shapes)
void	writePolysPoints (ensightGeoFile &os, const cellUList &meshCells, const labelUList &addr, const faceUList &meshFaces, const labelUList &faceOwner)
void	writePolysPoints (ensightGeoFile &os, const polyMesh &mesh, const labelUList &addr, const labelList &pointMap)
void	writeFaceConnectivity (ensightGeoFile &os, const ensightFaces::elemType etype, const label nTotal, const UIndirectList< face > &faces, bool parallel)
void	writeFaceConnectivity (ensightGeoFile &os, const ensightFaces::elemType etype, const label nTotal, const faceUList &faces, bool parallel)
void	writeFaceConnectivity (ensightGeoFile &os, const ensightFaces &part, const faceUList &faces, bool parallel)
void	writeFaceConnectivityPresorted (ensightGeoFile &os, const ensightFaces &part, const faceUList &faces, bool parallel)
template<class Type >
bool	writeField (ensightFile &os, const Field< Type > &fld, const ensightCells &part, bool parallel)
template<class Type >
bool	writeField (ensightFile &os, const Field< Type > &fld, const ensightFaces &part, bool parallel)
bool	writeCloudPositions (const fvMesh &mesh, const word &cloudName, bool exists, autoPtr< ensightFile > &output)
template<class Type >
bool	writeCloudField (const IOField< Type > &field, ensightFile &os)
template<class Type >
bool	writeCloudField (const IOobject &io, bool exists, autoPtr< ensightFile > &output)

Detailed Description

A collection of functions for writing ensight file content.

Source files

• ensightOutput.H
• ensightOutput.C
• ensightOutputTemplates.C

Function Documentation

writeAreaField()

bool writeAreaField	(	ensightFile &	os,
		const GeometricField< Type, faPatchField, areaMesh > &	fld,
		const ensightFaMesh &	ensMesh
	)

Definition at line 29 of file ensightOutputAreaFieldTemplates.C.

References ensightFaMesh::areaPart(), fld, os(), and Foam::ensightOutput::Detail::writeFaceLocalField().

Here is the call graph for this function:

writeVolField() [1/2]

bool writeVolField	(	ensightFile &	os,
		const GeometricField< Type, fvPatchField, volMesh > &	vf,
		const ensightMesh &	ensMesh
	)

Definition at line 35 of file ensightOutputVolFieldTemplates.C.

References GeometricField::boundaryField(), ensightMesh::boundaryParts(), ensightMesh::cellZoneParts(), ensightFaces::decrFaceIds(), faceId(), ensightFaces::faceIds(), ensightMesh::faceZoneParts(), forAll, forAllConstIters(), Foam::linearInterpolate(), Foam::max(), mesh, polyPatch::offset(), os(), patchId(), List::resize(), ensightFaces::size(), polyBoundaryMesh::start(), Foam::HashTableOps::values(), Foam::ensightOutput::Detail::writeFaceSubField(), writeField(), and Foam::Zero.

Here is the call graph for this function:

writeVolField() [2/2]

bool writeVolField	(	ensightFile &	os,
		const GeometricField< Type, fvPatchField, volMesh > &	vf,
		const ensightMesh &	ensMesh,
		const bool	nodeValues
	)

Definition at line 323 of file ensightOutputVolFieldTemplates.C.

References Foam::New(), os(), and tmp::ref().

Here is the call graph for this function:

writePointField()

bool writePointField	(	ensightFile &	os,
		const GeometricField< Type, pointPatchField, pointMesh > &	pf,
		const ensightMesh &	ensMesh
	)

Definition at line 194 of file ensightOutputVolFieldTemplates.C.

References GeometricField::boundaryField(), ensightMesh::boundaryParts(), ensightMesh::cellZoneParts(), coordinates(), ensightMesh::faceZoneParts(), ensightPart::index(), GeometricField::internalField(), mesh, ensightMesh::mesh(), PrimitivePatch< FaceList, PointField >::meshPointMap(), os(), patchId(), ensightFaces::uniqueMeshPoints(), ensightCells::uniqueMeshPoints(), and Foam::ensightOutput::Detail::writeFieldComponents().

Here is the call graph for this function:

writeFaceList() [1/2]

void writeFaceList	(	ensightGeoFile &	os,
		const UList< face > &	faces
	)

Definition at line 130 of file ensightOutput.C.

References f(), and os().

Referenced by writeFaceConnectivity().

Here is the call graph for this function:

Here is the caller graph for this function:

writeFaceList() [2/2]

void writeFaceList	(	ensightGeoFile &	os,
		const UIndirectList< face > &	faces
	)

Definition at line 148 of file ensightOutput.C.

References f(), and os().

Here is the call graph for this function:

writeCellShapes()

void writeCellShapes	(	ensightGeoFile &	os,
		const UList< cellShape > &	shapes
	)

Definition at line 166 of file ensightOutput.C.

References os().

Here is the call graph for this function:

writePolysPoints() [1/2]

void writePolysPoints	(	ensightGeoFile &	os,
		const cellUList &	meshCells,
		const labelUList &	addr,
		const faceUList &	meshFaces,
		const labelUList &	faceOwner
	)

Parameters

addr	Cell ids to write

Definition at line 231 of file ensightOutput.C.

References cellId, f(), faceId(), os(), and UList::size().

Here is the call graph for this function:

writePolysPoints() [2/2]

void writePolysPoints	(	ensightGeoFile &	os,
		const polyMesh &	mesh,
		const labelUList &	addr,
		const labelList &	pointMap
	)

Parameters

addr	Cell ids to write
pointMap	Point map to use

Definition at line 188 of file ensightOutput.C.

References cellId, f(), faceId(), mesh, and os().

Here is the call graph for this function:

writeFaceConnectivity() [1/3]

void writeFaceConnectivity	(	ensightGeoFile &	os,
		const ensightFaces::elemType	etype,
		const label	nTotal,
		const UIndirectList< face > &	faces,
		bool	parallel
	)

Parameters

parallel

Collective write?

Definition at line 362 of file ensightOutput.C.

References Foam::ensightOutput::Detail::getFaceSizes(), Foam::glTF::key(), os(), and writeFaceList().

Referenced by ensightOutputSurface::write(), writeFaceConnectivity(), and writeFaceConnectivityPresorted().

Here is the call graph for this function:

Here is the caller graph for this function:

writeFaceConnectivity() [2/3]

void writeFaceConnectivity	(	ensightGeoFile &	os,
		const ensightFaces::elemType	etype,
		const label	nTotal,
		const faceUList &	faces,
		bool	parallel
	)

Parameters

parallel

Collective write?

Definition at line 271 of file ensightOutput.C.

References Foam::ensightOutput::Detail::getFaceSizes(), Foam::glTF::key(), os(), and writeFaceList().

Here is the call graph for this function:

writeFaceConnectivity() [3/3]

void writeFaceConnectivity	(	ensightGeoFile &	os,
		const ensightFaces &	part,
		const faceUList &	faces,
		bool	parallel
	)

Parameters

parallel

Collective write?

Definition at line 455 of file ensightOutput.C.

References ensightFaces::faceIds(), os(), ensightFaces::total(), and writeFaceConnectivity().

Here is the call graph for this function:

writeFaceConnectivityPresorted()

void writeFaceConnectivityPresorted	(	ensightGeoFile &	os,
		const ensightFaces &	part,
		const faceUList &	faces,
		bool	parallel
	)

Parameters

parallel

Collective write?

Definition at line 479 of file ensightOutput.C.

References os(), ensightFaces::range(), ensightFaces::total(), and writeFaceConnectivity().

Referenced by ensightFaces::write().

Here is the call graph for this function:

Here is the caller graph for this function:

writeField() [1/2]

bool writeField	(	ensightFile &	os,
		const Field< Type > &	fld,
		const ensightCells &	part,
		bool	parallel
	)

Parameters

parallel

Collective write?

Definition at line 306 of file ensightOutputTemplates.C.

References ensightCells::cellIds(), fld, ensightPart::index(), Foam::glTF::key(), os(), reduce(), ensightCells::size(), ensightCells::total(), and Foam::ensightOutput::Detail::writeFieldComponents().

Referenced by rotorDiskSource::read(), exprResult::writeDict(), ensightOutputSurface::writeFaceData(), and writeVolField().

Here is the call graph for this function:

Here is the caller graph for this function:

writeField() [2/2]

bool writeField	(	ensightFile &	os,
		const Field< Type > &	fld,
		const ensightFaces &	part,
		bool	parallel
	)

Parameters

parallel

Collective write?

Definition at line 356 of file ensightOutputTemplates.C.

References ensightFaces::faceIds(), fld, ensightPart::index(), Foam::glTF::key(), os(), reduce(), ensightFaces::size(), ensightFaces::total(), and Foam::ensightOutput::Detail::writeFieldComponents().

Here is the call graph for this function:

writeCloudPositions()

bool writeCloudPositions	(	const fvMesh &	mesh,
		const word &	cloudName,
		bool	exists,
		autoPtr< ensightFile > &	output
	)

Definition at line 72 of file ensightOutputCloud.C.

References cloudName(), Foam::exists(), globalIndex::localSize(), globalIndex::maxSize(), mesh, os(), Foam::output(), p, Foam::blockMeshTools::read(), DynamicList::reserve(), autoPtr::reset(), DynamicList::resize_nocopy(), Foam::returnReduce(), globalIndex::subProcs(), Foam::vtk::write(), Foam::writeMeasured_ascii(), and Foam::writeMeasured_binary().

Referenced by if().

Here is the call graph for this function:

Here is the caller graph for this function:

writeCloudField() [1/2]

bool writeCloudField	(	const IOField< Type > &	field,
		ensightFile &	os
	)

Definition at line 64 of file ensightOutputCloudTemplates.C.

References Foam::BitOps::count(), field(), globalIndex::localSize(), globalIndex::maxNonLocalSize(), os(), Foam::blockMeshTools::read(), globalIndex::reset(), DynamicList::resize_nocopy(), Foam::returnReduce(), globalIndex::subProcs(), Foam::vtk::write(), and Foam::ensightOutput::Detail::writeCloudFieldContent().

Referenced by writeCloudField().

Here is the call graph for this function:

Here is the caller graph for this function:

writeCloudField() [2/2]

bool writeCloudField	(	const IOobject &	io,
		bool	exists,
		autoPtr< ensightFile > &	output
	)

Definition at line 145 of file ensightOutputCloudTemplates.C.

References Foam::exists(), field(), Foam::output(), IOobject::readOpt(), and writeCloudField().

Here is the call graph for this function:
