Class for parallel communication in a narrow band. It either provides a Map with the neighbouring values of the selected region or returns a Map of the required values in global addressing. Also holds a reference to the stencil Before the data transfer the communation has to be set up: exchangeFields_.setUpCommforZone(interfaceCell_); Is used in the plicRDF. More...

Inheritance diagram for zoneDistribute:

[legend]

Collaboration diagram for zoneDistribute:

[legend]

Public Member Functions
	TypeName ("zoneDistribute")

	zoneDistribute (const fvMesh &)

virtual	~zoneDistribute ()=default

void	setUpCommforZone (const boolList &zone, bool updateStencil=true)

void	updateStencil (const boolList &zone)

const labelListList &	getStencil () noexcept

const globalIndex &	globalNumbering () const noexcept

template<typename Type >
Type	getValue (const GeometricField< Type, fvPatchField, volMesh > &phi, const Map< Type > &valuesFromOtherProc, const label gblIdx) const

template<typename Type >
Map< Field< Type > >	getFields (const boolList &zone, const GeometricField< Type, fvPatchField, volMesh > &phi)

template<typename Type >
Map< Type >	getDatafromOtherProc (const boolList &zone, const GeometricField< Type, fvPatchField, volMesh > &phi)

template<typename Type >
Foam::Map< Foam::Field< Type > >	getFields (const boolList &zone, const GeometricField< Type, fvPatchField, volMesh > &phi)

template<typename Type >
Foam::Map< Type >	getDatafromOtherProc (const boolList &zone, const GeometricField< Type, fvPatchField, volMesh > &phi)

Public Member Functions inherited from MeshObject< fvMesh, TopologicalMeshObject, zoneDistribute >
	MeshObject (const fvMesh &mesh)

virtual	~MeshObject ()=default

const fvMesh &	mesh () const

virtual bool	writeData (Ostream &os) const

Public Member Functions inherited from TopologicalMeshObject< fvMesh >
	TopologicalMeshObject (const word &typeName, const objectRegistry &obr)

Public Member Functions inherited from meshObject
	ClassName ("meshObject")

	meshObject (const word &typeName, const objectRegistry &obr)

Public Member Functions inherited from regIOobject
	TypeName ("regIOobject")

	regIOobject (const IOobject &io, const bool isTimeObject=false)

	regIOobject (const regIOobject &rio)

	regIOobject (const regIOobject &rio, bool registerCopy)

	regIOobject (const word &newName, const regIOobject &, bool registerCopy)

	regIOobject (const IOobject &io, const regIOobject &rio)

virtual	~regIOobject ()

bool	checkIn ()

bool	checkOut ()

virtual void	addWatch ()

bool	ownedByRegistry () const

bool	store ()

void	release (const bool unregister=false)

label	eventNo () const

label &	eventNo ()

bool	upToDate (const regIOobject &) const

bool	upToDate (const regIOobject &, const regIOobject &) const

bool	upToDate (const regIOobject &, const regIOobject &, const regIOobject &) const

bool	upToDate (const regIOobject &, const regIOobject &, const regIOobject &, const regIOobject &) const

void	setUpToDate ()

virtual void	rename (const word &newName)

const dictionary *	findMetaData () const noexcept

dictionary &	getMetaData () noexcept

void	removeMetaData ()

virtual void	updateMetaData ()

virtual fileName	filePath () const

bool	headerOk ()

Istream &	readStream (const word &, const bool valid=true)

void	close ()

virtual bool	readData (Istream &)

virtual bool	read ()

virtual label	addWatch (const fileName &)

const labelList &	watchIndices () const

labelList &	watchIndices ()

virtual bool	modified () const

virtual bool	readIfModified ()

virtual bool	writeObject (IOstreamOption streamOpt, const bool valid) const

virtual bool	write (const bool valid=true) const

virtual bool	global () const

void	operator= (const IOobject &io)

virtual bool	writeObject (IOstreamOption::streamFormat fmt, IOstreamOption::versionNumber ver, IOstreamOption::compressionType comp, const bool valid) const

Public Member Functions inherited from IOobject
	TypeName ("IOobject")

	IOobject (const IOobject &)=default

virtual	~IOobject ()=default

	IOobject (const word &name, const fileName &instance, const objectRegistry &registry, readOption r=NO_READ, writeOption w=NO_WRITE, bool registerObject=true, bool globalObject=false)

	IOobject (const word &name, const fileName &instance, const fileName &local, const objectRegistry &registry, readOption r=NO_READ, writeOption w=NO_WRITE, bool registerObject=true, bool globalObject=false)

	IOobject (const fileName &path, const objectRegistry &registry, readOption r=NO_READ, writeOption w=NO_WRITE, bool registerObject=true, bool globalObject=false)

	IOobject (const IOobject &io, const objectRegistry &registry)

	IOobject (const IOobject &io, const word &name)

	IOobject (const IOobject &io, readOption, writeOption)

autoPtr< IOobject >	clone () const

autoPtr< IOobject >	clone (const objectRegistry &registry) const

const objectRegistry &	db () const noexcept

const Time &	time () const

const word &	name () const noexcept

const word &	headerClassName () const noexcept

word &	headerClassName () noexcept

const string &	note () const noexcept

string &	note () noexcept

bool	registerObject () const noexcept

bool	registerObject (bool on) noexcept

bool	globalObject () const noexcept

bool	globalObject (bool on) noexcept

unsigned	labelByteSize () const noexcept

unsigned	scalarByteSize () const noexcept

bool	isHeaderClassName (const word &clsName) const

template<class Type >
bool	isHeaderClassName () const

readOption	readOpt () const noexcept

readOption	readOpt (readOption opt) noexcept

writeOption	writeOpt () const noexcept

writeOption	writeOpt (writeOption opt) noexcept

word	group () const

word	member () const

const fileName &	rootPath () const

const fileName &	caseName () const

const fileName &	instance () const noexcept

fileName &	instance () noexcept

const fileName &	local () const noexcept

fileName	path () const

fileName	path (const word &instance, const fileName &local=fileName::null) const

fileName	objectPath () const

fileName	objectRelPath () const

fileName	localFilePath (const word &typeName, const bool search=true) const

fileName	globalFilePath (const word &typeName, const bool search=true) const

IOstreamOption	parseHeader (const dictionary &headerDict)

bool	readHeader (Istream &is)

bool	readHeader (dictionary &headerDict, Istream &is)

template<class Type >
bool	typeHeaderOk (const bool checkType=true, const bool search=true, const bool verbose=true)

template<class Type >
void	warnNoRereading () const

bool	writeHeader (Ostream &os) const

bool	writeHeader (Ostream &os, const word &objectType) const

void	writeHeader (dictionary &dict, IOstreamOption streamOpt) const

void	writeHeader (dictionary &dict, const word &objectType, IOstreamOption streamOpt) const

bool	good () const noexcept

bool	bad () const noexcept

InfoProxy< IOobject >	info () const

void	operator= (const IOobject &io)

readOption &	readOpt () noexcept

writeOption &	writeOpt () noexcept

bool &	registerObject () noexcept

bool &	globalObject () noexcept

template<>
bool	isHeaderClassName () const

template<class StringType >
Foam::word	groupName (StringType base, const word &group)

Static Public Member Functions
static zoneDistribute &	New (const fvMesh &)

Static Public Member Functions inherited from MeshObject< fvMesh, TopologicalMeshObject, zoneDistribute >
static const zoneDistribute &	New (const fvMesh &mesh, Args &&... args)

static bool	Delete (const fvMesh &mesh)

Static Public Member Functions inherited from meshObject
template<class Mesh >
static void	movePoints (objectRegistry &obr)

template<class Mesh >
static void	updateMesh (objectRegistry &obr, const mapPolyMesh &mpm)

template<class Mesh , template< class > class MeshObjectType>
static void	clear (objectRegistry &obr)

template<class Mesh , template< class > class FromType, template< class > class ToType>
static void	clearUpto (objectRegistry &obr)

Static Public Member Functions inherited from regIOobject
template<class Type >
static Type &	store (Type *p)

template<class Type >
static Type &	store (autoPtr< Type > &ptr)

template<class Type >
static Type &	store (autoPtr< Type > &&ptr)

template<class Type >
static Type &	store (refPtr< Type > &ptr)

template<class Type >
static Type &	store (refPtr< Type > &&ptr)

template<class Type >
static Type &	store (tmp< Type > &ptr)

template<class Type >
static Type &	store (tmp< Type > &&ptr)

Static Public Member Functions inherited from IOobject
static bool	bannerEnabled () noexcept

static bool	bannerEnabled (bool on) noexcept

static bool	fileNameComponents (const fileName &path, fileName &instance, fileName &local, word &name)

template<class StringType >
static word	groupName (StringType base, const word &group)

static word	group (const word &name)

static word	member (const word &name)

static word	scopedName (const std::string &scope, const word &name)

static IOobject	selectIO (const IOobject &io, const fileName &altFile, const word &ioName="")

static Ostream &	writeBanner (Ostream &os, const bool noSyntaxHint=false)

static Ostream &	writeDivider (Ostream &os)

static Ostream &	writeEndDivider (Ostream &os)

Additional Inherited Members
Public Types inherited from IOobject
enum	objectState : char { GOOD, BAD }

enum	readOption : char { MUST_READ, MUST_READ_IF_MODIFIED, READ_IF_PRESENT, NO_READ }

enum	writeOption : char { AUTO_WRITE = 0, NO_WRITE = 1 }

enum	fileCheckTypes : char { timeStamp, timeStampMaster, inotify, inotifyMaster }

Static Public Attributes inherited from IOobject
static const Enum< fileCheckTypes >	fileCheckTypesNames

static char	scopeSeparator

static fileCheckTypes	fileModificationChecking

static float	fileModificationSkew

static int	maxFileModificationPolls

Protected Member Functions inherited from regIOobject
bool	readHeaderOk (const IOstreamOption::streamFormat fmt, const word &typeName)

Protected Member Functions inherited from IOobject
void	setBad (const string &s)

Static Protected Member Functions inherited from IOobject
static void	writeHeaderContent (Ostream &os, const IOobject &io, const word &objectType, const dictionary *metaDataDict=nullptr)

static void	writeHeaderContent (dictionary &dict, const IOobject &io, const word &objectType, IOstreamOption streamOpt, const dictionary *metaDataDict=nullptr)

Protected Attributes inherited from MeshObject< fvMesh, TopologicalMeshObject, zoneDistribute >
const fvMesh &	mesh_

Static Protected Attributes inherited from regIOobject
static bool	masterOnlyReading = false

Detailed Description

Class for parallel communication in a narrow band. It either provides a Map with the neighbouring values of the selected region or returns a Map of the required values in global addressing. Also holds a reference to the stencil Before the data transfer the communation has to be set up: exchangeFields_.setUpCommforZone(interfaceCell_); Is used in the plicRDF.

Original code supplied by Henning Scheufler, DLR (2019)

Source files

Definition at line 60 of file zoneDistribute.H.
