waveVelocityFvPatchVectorField Class Reference

Example of the boundary condition specification: More...

Inheritance diagram for waveVelocityFvPatchVectorField:

Collaboration diagram for waveVelocityFvPatchVectorField:

Public Member Functions
	TypeName ("waveVelocity")
	waveVelocityFvPatchVectorField (const fvPatch &, const DimensionedField< vector, volMesh > &)
	waveVelocityFvPatchVectorField (const fvPatch &, const DimensionedField< vector, volMesh > &, const dictionary &)
	waveVelocityFvPatchVectorField (const waveVelocityFvPatchVectorField &, const fvPatch &, const DimensionedField< vector, volMesh > &, const fvPatchFieldMapper &)
	waveVelocityFvPatchVectorField (const waveVelocityFvPatchVectorField &)
virtual tmp< fvPatchVectorField >	clone () const
	waveVelocityFvPatchVectorField (const waveVelocityFvPatchVectorField &, const DimensionedField< vector, volMesh > &)
virtual tmp< fvPatchVectorField >	clone (const DimensionedField< vector, volMesh > &iF) const
virtual void	updateCoeffs ()
virtual void	write (Ostream &) const

Detailed Description

Example of the boundary condition specification:

inlet
{
    type            waveVelocity;
    value           uniform (0 0 0);
}

Usage

Property	Description	Required	Default value
type	type: waveVelocity	yes
waveDict	Dictionary specifying wave variables	no	waveProperties

Note

• The value is positive inwards
• May not work correctly for transonic inlets
• Strange behaviour with potentialFoam since the U equation is not solved

Source files

• waveVelocityFvPatchVectorField.H
• waveVelocityFvPatchVectorField.C

Definition at line 80 of file waveVelocityFvPatchVectorField.H.

Constructor & Destructor Documentation

waveVelocityFvPatchVectorField() [1/5]

waveVelocityFvPatchVectorField	(	const fvPatch &	p,
		const DimensionedField< vector, volMesh > &	iF
	)

Definition at line 30 of file waveVelocityFvPatchVectorField.C.

Referenced by waveVelocityFvPatchVectorField::clone().

Here is the caller graph for this function:

waveVelocityFvPatchVectorField() [2/5]

waveVelocityFvPatchVectorField	(	const fvPatch &	p,
		const DimensionedField< vector, volMesh > &	iF,
		const dictionary &	dict
	)

Definition at line 54 of file waveVelocityFvPatchVectorField.C.

waveVelocityFvPatchVectorField() [3/5]

waveVelocityFvPatchVectorField	(	const waveVelocityFvPatchVectorField &	ptf,
		const fvPatch &	p,
		const DimensionedField< vector, volMesh > &	iF,
		const fvPatchFieldMapper &	mapper
	)

Definition at line 41 of file waveVelocityFvPatchVectorField.C.

waveVelocityFvPatchVectorField() [4/5]

waveVelocityFvPatchVectorField

(

const waveVelocityFvPatchVectorField &

ptf

)

Definition at line 66 of file waveVelocityFvPatchVectorField.C.

waveVelocityFvPatchVectorField() [5/5]

waveVelocityFvPatchVectorField	(	const waveVelocityFvPatchVectorField &	ptf,
		const DimensionedField< vector, volMesh > &	iF
	)

Definition at line 76 of file waveVelocityFvPatchVectorField.C.

Member Function Documentation

TypeName()

TypeName

(

"waveVelocity"

)

clone() [1/2]

virtual tmp<fvPatchVectorField> clone ( ) const

inlinevirtual

Definition at line 131 of file waveVelocityFvPatchVectorField.H.

References waveVelocityFvPatchVectorField::waveVelocityFvPatchVectorField().

Here is the call graph for this function:

clone() [2/2]

virtual tmp<fvPatchVectorField> clone ( const DimensionedField< vector, volMesh > &  iF ) const

inlinevirtual

Definition at line 148 of file waveVelocityFvPatchVectorField.H.

References waveVelocityFvPatchVectorField::waveVelocityFvPatchVectorField().

Here is the call graph for this function:

updateCoeffs()

void updateCoeffs ( )

virtual

Definition at line 88 of file waveVelocityFvPatchVectorField.C.

References tmp::constCast(), waveModel::correct(), waveModel::lookupOrCreate(), mesh, Foam::operator==(), Foam::foamVersion::patch, waveModel::U(), and fvPatchField< Type >::updateCoeffs().

Here is the call graph for this function:

write()

void write ( Ostream &  os ) const

virtual

Definition at line 115 of file waveVelocityFvPatchVectorField.C.

References os(), fvPatchField::write(), and Ostream::writeEntry().

Here is the call graph for this function:

---

The documentation for this class was generated from the following files:

• src/waveModels/derivedFvPatchFields/waveVelocity/waveVelocityFvPatchVectorField.H
• src/waveModels/derivedFvPatchFields/waveVelocity/waveVelocityFvPatchVectorField.C
