waveAlphaFvPatchScalarField Class Reference

Example of the boundary condition specification: More...

Inheritance diagram for waveAlphaFvPatchScalarField:

Collaboration diagram for waveAlphaFvPatchScalarField:

Public Member Functions
	TypeName ("waveAlpha")
	waveAlphaFvPatchScalarField (const fvPatch &, const DimensionedField< scalar, volMesh > &)
	waveAlphaFvPatchScalarField (const fvPatch &, const DimensionedField< scalar, volMesh > &, const dictionary &)
	waveAlphaFvPatchScalarField (const waveAlphaFvPatchScalarField &, const fvPatch &, const DimensionedField< scalar, volMesh > &, const fvPatchFieldMapper &)
	waveAlphaFvPatchScalarField (const waveAlphaFvPatchScalarField &)
virtual tmp< fvPatchScalarField >	clone () const
	waveAlphaFvPatchScalarField (const waveAlphaFvPatchScalarField &, const DimensionedField< scalar, volMesh > &)
virtual tmp< fvPatchScalarField >	clone (const DimensionedField< scalar, volMesh > &iF) const
virtual void	updateCoeffs ()
virtual void	write (Ostream &) const

Detailed Description

Example of the boundary condition specification:

inlet
{
    type            waveAlpha;
    value           uniform (0 0 0);
}

Usage

Property	Description	Required	Default value
type	type: waveAlpha	yes
waveDict	Dictionary specifying wave variables	no	waveProperties

Note

• The value is positive inwards
• May not work correctly for transonic inlets
• Strange behaviour with potentialFoam since the U equation is not solved

Source files

• waveAlphaFvPatchScalarField.H
• waveAlphaFvPatchScalarField.C

Definition at line 80 of file waveAlphaFvPatchScalarField.H.

Constructor & Destructor Documentation

waveAlphaFvPatchScalarField() [1/5]

waveAlphaFvPatchScalarField	(	const fvPatch &	p,
		const DimensionedField< scalar, volMesh > &	iF
	)

Definition at line 30 of file waveAlphaFvPatchScalarField.C.

Referenced by waveAlphaFvPatchScalarField::clone().

Here is the caller graph for this function:

waveAlphaFvPatchScalarField() [2/5]

waveAlphaFvPatchScalarField	(	const fvPatch &	p,
		const DimensionedField< scalar, volMesh > &	iF,
		const dictionary &	dict
	)

Definition at line 54 of file waveAlphaFvPatchScalarField.C.

waveAlphaFvPatchScalarField() [3/5]

waveAlphaFvPatchScalarField	(	const waveAlphaFvPatchScalarField &	ptf,
		const fvPatch &	p,
		const DimensionedField< scalar, volMesh > &	iF,
		const fvPatchFieldMapper &	mapper
	)

Definition at line 41 of file waveAlphaFvPatchScalarField.C.

waveAlphaFvPatchScalarField() [4/5]

waveAlphaFvPatchScalarField

(

const waveAlphaFvPatchScalarField &

ptf

)

Definition at line 66 of file waveAlphaFvPatchScalarField.C.

waveAlphaFvPatchScalarField() [5/5]

waveAlphaFvPatchScalarField	(	const waveAlphaFvPatchScalarField &	ptf,
		const DimensionedField< scalar, volMesh > &	iF
	)

Definition at line 76 of file waveAlphaFvPatchScalarField.C.

Member Function Documentation

TypeName()

TypeName

(

"waveAlpha"

)

clone() [1/2]

virtual tmp<fvPatchScalarField> clone ( ) const

inlinevirtual

Definition at line 131 of file waveAlphaFvPatchScalarField.H.

References waveAlphaFvPatchScalarField::waveAlphaFvPatchScalarField().

Here is the call graph for this function:

clone() [2/2]

virtual tmp<fvPatchScalarField> clone ( const DimensionedField< scalar, volMesh > &  iF ) const

inlinevirtual

Definition at line 148 of file waveAlphaFvPatchScalarField.H.

References waveAlphaFvPatchScalarField::waveAlphaFvPatchScalarField().

Here is the call graph for this function:

updateCoeffs()

void updateCoeffs ( )

virtual

Definition at line 88 of file waveAlphaFvPatchScalarField.C.

References waveModel::alpha(), tmp::constCast(), waveModel::correct(), waveModel::lookupOrCreate(), mesh, Foam::operator==(), Foam::foamVersion::patch, and fvPatchField< Type >::updateCoeffs().

Here is the call graph for this function:

write()

void write ( Ostream &  os ) const

virtual

Definition at line 115 of file waveAlphaFvPatchScalarField.C.

References os(), fvPatchField::write(), and Ostream::writeEntry().

Here is the call graph for this function:

---

The documentation for this class was generated from the following files:

• src/waveModels/derivedFvPatchFields/waveAlpha/waveAlphaFvPatchScalarField.H
• src/waveModels/derivedFvPatchFields/waveAlpha/waveAlphaFvPatchScalarField.C
