For use with FaceCellWave. Determines topological distance to starting faces. More...

Collaboration diagram for wallPoints:

[legend]

Classes
class	trackData

Public Member Functions
	wallPoints ()

	wallPoints (const UList< point > &origin, const UList< scalar > &distSqr, const UList< FixedList< label, 3 >> &surface)

const List< point > &	origin () const

const List< scalar > &	distSqr () const

const List< FixedList< label, 3 > > &	surface () const

template<class TrackingData >
bool	valid (TrackingData &td) const

template<class TrackingData >
bool	sameGeometry (const polyMesh &, const wallPoints &, const scalar, TrackingData &td) const

template<class TrackingData >
void	leaveDomain (const polyMesh &, const polyPatch &, const label patchFacei, const point &faceCentre, TrackingData &td)

template<class TrackingData >
void	enterDomain (const polyMesh &, const polyPatch &, const label patchFacei, const point &faceCentre, TrackingData &td)

template<class TrackingData >
void	transform (const polyMesh &, const tensor &, TrackingData &td)

template<class TrackingData >
bool	updateCell (const polyMesh &, const label thisCelli, const label neighbourFacei, const wallPoints &neighbourInfo, const scalar tol, TrackingData &td)

template<class TrackingData >
bool	updateFace (const polyMesh &, const label thisFacei, const label neighbourCelli, const wallPoints &neighbourInfo, const scalar tol, TrackingData &td)

template<class TrackingData >
bool	updateFace (const polyMesh &, const label thisFacei, const wallPoints &neighbourInfo, const scalar tol, TrackingData &td)

template<class TrackingData >
bool	equal (const wallPoints &, TrackingData &) const

bool	operator== (const wallPoints &) const

bool	operator!= (const wallPoints &) const

Protected Member Functions
template<class TrackingData >
bool	update (const point &pt, const label index1, const wallPoints &w2, const label index2, const scalar tol, TrackingData &td)

Protected Attributes
DynamicList< point >	origin_

DynamicList< scalar >	distSqr_

DynamicList< FixedList< label, 3 > >	surface_

Friends
Ostream &	operator<< (Ostream &, const wallPoints &)

Istream &	operator>> (Istream &, wallPoints &)

Detailed Description

For use with FaceCellWave. Determines topological distance to starting faces.

Source files

Definition at line 58 of file wallPoints.H.

Constructor & Destructor Documentation

◆ wallPoints() [1/2]

wallPoints ( )

inline

Definition at line 83 of file wallPointsI.H.

◆ wallPoints() [2/2]

wallPoints	(	const UList< point > &	origin,
		const UList< scalar > &	distSqr,
		const UList< FixedList< label, 3 >> &	surface
	)

inline

Definition at line 93 of file wallPointsI.H.

Member Function Documentation

◆ update()

bool update	(	const point &	pt,
		const label	index1,
		const wallPoints &	w2,
		const label	index2,
		const scalar	tol,
		TrackingData &	td
	)

inlineprotected

Definition at line 28 of file wallPointsI.H.

References Foam::diff(), Foam::magSqr(), and w2.

Here is the call graph for this function:

◆ origin()

const List<point>& origin ( ) const

inline

Definition at line 133 of file wallPoints.H.

References wallPoints::origin_.

◆ distSqr()

const List<scalar>& distSqr ( ) const

inline

Definition at line 137 of file wallPoints.H.

References wallPoints::distSqr_.

◆ surface()

const List<FixedList<label, 3> >& surface ( ) const

inline

Definition at line 142 of file wallPoints.H.

References wallPoints::surface_.

◆ valid()

bool valid ( TrackingData & td ) const

inline

Definition at line 110 of file wallPointsI.H.

◆ sameGeometry()

bool sameGeometry	(	const polyMesh &	,
		const wallPoints &	,
		const	scalar,
		TrackingData &	td
	)		const

inline

Definition at line 119 of file wallPointsI.H.

◆ leaveDomain()

void leaveDomain	(	const polyMesh &	,
		const polyPatch &	patch,
		const label	patchFacei,
		const point &	faceCentre,
		TrackingData &	td
	)

inline

Definition at line 133 of file wallPointsI.H.

◆ enterDomain()

void enterDomain	(	const polyMesh &	,
		const polyPatch &	patch,
		const label	patchFacei,
		const point &	faceCentre,
		TrackingData &	td
	)

inline

Definition at line 167 of file wallPointsI.H.

◆ transform()

void transform	(	const polyMesh &	,
		const tensor &	rotTensor,
		TrackingData &	td
	)

inline

Definition at line 151 of file wallPointsI.H.

References Foam::transform().

Here is the call graph for this function:

◆ updateCell()

bool updateCell	(	const polyMesh &	mesh,
		const label	thisCelli,
		const label	neighbourFacei,
		const wallPoints &	neighbourInfo,
		const scalar	tol,
		TrackingData &	td
	)

inline

Definition at line 186 of file wallPointsI.H.

References primitiveMesh::cellCentres(), forAll, Foam::magSqr(), mesh, wallPoints::origin_, wallPoints::surface_, and update().

Here is the call graph for this function:

◆ updateFace() [1/2]

bool updateFace	(	const polyMesh &	mesh,
		const label	thisFacei,
		const label	neighbourCelli,
		const wallPoints &	neighbourInfo,
		const scalar	tol,
		TrackingData &	td
	)

inline

Definition at line 228 of file wallPointsI.H.

References primitiveMesh::faceCentres(), forAll, Foam::magSqr(), mesh, wallPoints::origin_, wallPoints::surface_, and update().

Here is the call graph for this function:

◆ updateFace() [2/2]

bool updateFace	(	const polyMesh &	mesh,
		const label	thisFacei,
		const wallPoints &	neighbourInfo,
		const scalar	tol,
		TrackingData &	td
	)

inline

Definition at line 275 of file wallPointsI.H.

References primitiveMesh::faceCentres(), forAll, Foam::magSqr(), mesh, wallPoints::origin_, wallPoints::surface_, and update().

Here is the call graph for this function:

◆ equal()

bool equal	(	const wallPoints &	rhs,
		TrackingData &	td
	)		const

inline

Definition at line 320 of file wallPointsI.H.

References Foam::operator==().

Here is the call graph for this function:

◆ operator==()

bool operator== ( const wallPoints & rhs ) const

inline

Definition at line 332 of file wallPointsI.H.

References wallPoints::distSqr_, wallPoints::origin_, and wallPoints::surface_.

◆ operator!=()

bool operator!= ( const wallPoints & rhs ) const

inline

Definition at line 345 of file wallPointsI.H.

Friends And Related Function Documentation

◆ operator<<

Ostream& operator<<	(	Ostream &	,
		const wallPoints &
	)

friend

◆ operator>>

Istream& operator>>	(	Istream &	,
		wallPoints &
	)

friend

Member Data Documentation

◆ origin_

DynamicList<point> origin_

protected

Definition at line 82 of file wallPoints.H.

Referenced by wallPoints::operator==(), wallPoints::origin(), wallPoints::updateCell(), and wallPoints::updateFace().

◆ distSqr_

DynamicList<scalar> distSqr_

protected

Definition at line 85 of file wallPoints.H.

Referenced by wallPoints::distSqr(), and wallPoints::operator==().

◆ surface_

DynamicList<FixedList<label, 3> > surface_

protected

Definition at line 88 of file wallPoints.H.

Referenced by wallPoints::operator==(), wallPoints::surface(), wallPoints::updateCell(), and wallPoints::updateFace().

The documentation for this class was generated from the following files:

src/mesh/snappyHexMesh/meshRefinement/wallPoints.H
src/mesh/snappyHexMesh/meshRefinement/wallPointsI.H
