Holds information (coordinate and yStar) regarding nearest wall point. More...

Inheritance diagram for wallPointYPlus:

Collaboration diagram for wallPointYPlus:

Public Member Functions
	wallPointYPlus ()

	wallPointYPlus (const point &origin, const scalar yStar, const scalar distSqr)

template<class TrackingData >
bool	updateCell (const polyMesh &mesh, const label thisCelli, const label neighbourFacei, const wallPointYPlus &neighbourWallInfo, const scalar tol, TrackingData &td)

template<class TrackingData >
bool	updateFace (const polyMesh &mesh, const label thisFacei, const label neighbourCelli, const wallPointYPlus &neighbourWallInfo, const scalar tol, TrackingData &td)

template<class TrackingData >
bool	updateFace (const polyMesh &mesh, const label thisFacei, const wallPointYPlus &neighbourWallInfo, const scalar tol, TrackingData &td)

Public Member Functions inherited from wallPointData< scalar >
	wallPointData ()

	wallPointData (const point &origin, const Type &data, const scalar distSqr)

const Type &	data () const

Type &	data ()

bool	updateCell (const polyMesh &mesh, const label thisCelli, const label neighbourFacei, const wallPointData< Type > &neighbourWallInfo, const scalar tol, TrackingData &td)

bool	updateFace (const polyMesh &mesh, const label thisFacei, const label neighbourCelli, const wallPointData< Type > &neighbourWallInfo, const scalar tol, TrackingData &td)

bool	updateFace (const polyMesh &mesh, const label thisFacei, const wallPointData< Type > &neighbourWallInfo, const scalar tol, TrackingData &td)

Static Public Attributes
static scalar	yPlusCutOff = 200

Additional Inherited Members
Public Types inherited from wallPointData< scalar >
typedef Type	dataType

Detailed Description

Holds information (coordinate and yStar) regarding nearest wall point.

Used in VanDriest wall damping where the interest is in y+ but only needs to be calculated up to e.g. y+ < 200. In all other cells/faces the damping function becomes 1, since y gets initialized to GREAT and yStar to 1.

Note: should feed the additional argument (yPlusCutoff) through as a template argument into FaceCellWave

Source files

Definition at line 56 of file wallPointYPlus.H.

Constructor & Destructor Documentation

◆ wallPointYPlus() [1/2]

wallPointYPlus ( )

inline

Definition at line 78 of file wallPointYPlusI.H.

References wallPointData< scalar >::data().

Here is the call graph for this function:

◆ wallPointYPlus() [2/2]

wallPointYPlus	(	const point &	origin,
		const scalar	yStar,
		const scalar	distSqr
	)

inline

Definition at line 88 of file wallPointYPlusI.H.

Member Function Documentation

◆ updateCell()

bool updateCell	(	const polyMesh &	mesh,
		const label	thisCelli,
		const label	neighbourFacei,
		const wallPointYPlus &	neighbourWallInfo,
		const scalar	tol,
		TrackingData &	td
	)

inline

Definition at line 103 of file wallPointYPlusI.H.

References mesh, and update().

Here is the call graph for this function:

◆ updateFace() [1/2]

bool updateFace	(	const polyMesh &	mesh,
		const label	thisFacei,
		const label	neighbourCelli,
		const wallPointYPlus &	neighbourWallInfo,
		const scalar	tol,
		TrackingData &	td
	)
