Wall distance calculation. Like wallDist but also transports extra data (template argument). More...

Inheritance diagram for wallDistData< TransferType >:

Collaboration diagram for wallDistData< TransferType >:

Public Member Functions
	wallDistData (const fvMesh &mesh, GeometricField< Type, fvPatchField, volMesh > &, bool correctWalls=true)

virtual	~wallDistData ()

const volScalarField &	y () const

label	nUnset () const

const GeometricField< Type, fvPatchField, volMesh > &	data () const

virtual void	correct ()

Public Member Functions inherited from GeometricField
	TypeName ("GeometricField")

	GeometricField (const IOobject &io, const Mesh &mesh, const dimensionSet &ds, const word &patchFieldType=PatchField< Type >::calculatedType())

	GeometricField (const IOobject &io, const Mesh &mesh, const dimensionSet &ds, const wordList &wantedPatchTypes, const wordList &actualPatchTypes=wordList())

	GeometricField (const IOobject &io, const Mesh &mesh, const dimensioned< Type > &dt, const word &patchFieldType=PatchField< Type >::calculatedType())

	GeometricField (const IOobject &io, const Mesh &mesh, const dimensioned< Type > &dt, const wordList &wantedPatchTypes, const wordList &actualPatchTypes=wordList())

	GeometricField (const IOobject &io, const Internal &diField, const PtrList< PatchField< Type >> &ptfl)

	GeometricField (const IOobject &io, const Mesh &mesh, const dimensionSet &ds, const Field< Type > &iField, const word &patchFieldType=PatchField< Type >::calculatedType())

	GeometricField (const IOobject &io, const Mesh &mesh, const dimensionSet &ds, Field< Type > &&iField, const word &patchFieldType=PatchField< Type >::calculatedType())

	GeometricField (const IOobject &io, const Mesh &mesh, const dimensionSet &ds, const Field< Type > &iField, const PtrList< PatchField< Type >> &ptfl)

	GeometricField (const IOobject &io, const Mesh &mesh, const bool readOldTime=true)

	GeometricField (const IOobject &io, const Mesh &mesh, const dictionary &dict)

	GeometricField (const GeometricField< Type, PatchField, GeoMesh > &gf)

	GeometricField (const tmp< GeometricField< Type, PatchField, GeoMesh >> &tgf)

	GeometricField (const IOobject &io, const GeometricField< Type, PatchField, GeoMesh > &gf)

	GeometricField (const IOobject &io, const tmp< GeometricField< Type, PatchField, GeoMesh >> &tgf)

	GeometricField (const word &newName, const GeometricField< Type, PatchField, GeoMesh > &gf)

	GeometricField (const word &newName, const tmp< GeometricField< Type, PatchField, GeoMesh >> &tgf)

	GeometricField (const IOobject &io, const GeometricField< Type, PatchField, GeoMesh > &gf, const word &patchFieldType)

	GeometricField (const IOobject &io, const GeometricField< Type, PatchField, GeoMesh > &gf, const labelList &patchIDs, const word &patchFieldType)

	GeometricField (const IOobject &io, const GeometricField< Type, PatchField, GeoMesh > &gf, const wordList &patchFieldTypes, const wordList &actualPatchTypes=wordList())

	GeometricField (const IOobject &io, const tmp< GeometricField< Type, PatchField, GeoMesh >> &tgf, const wordList &patchFieldTypes, const wordList &actualPatchTypes=wordList())

tmp< GeometricField< Type, PatchField, GeoMesh > >	clone () const

virtual	~GeometricField ()

Internal &	ref (const bool updateAccessTime=true)

const Internal &	internalField () const

const Internal &	v () const

Internal::FieldType &	primitiveFieldRef (const bool updateAccessTime=true)

const Internal::FieldType &	primitiveField () const

Boundary &	boundaryFieldRef (const bool updateAccessTime=true)

const Boundary &	boundaryField () const

label	timeIndex () const

label &	timeIndex ()

void	storeOldTimes () const

void	storeOldTime () const

label	nOldTimes () const

const GeometricField< Type, PatchField, GeoMesh > &	oldTime () const

GeometricField< Type, PatchField, GeoMesh > &	oldTime ()

void	storePrevIter () const

const GeometricField< Type, PatchField, GeoMesh > &	prevIter () const

void	correctBoundaryConditions ()

bool	needReference () const

tmp< GeometricField< cmptType, PatchField, GeoMesh > >	component (const direction) const

bool	writeData (Ostream &) const

tmp< GeometricField< Type, PatchField, GeoMesh > >	T () const

void	relax (const scalar alpha)

void	relax ()

word	select (bool final) const

void	writeMinMax (Ostream &os) const

void	negate ()

void	replace (const direction d, const GeometricField< cmptType, PatchField, GeoMesh > &gcf)

void	replace (const direction d, const dimensioned< cmptType > &ds)

void	min (const dimensioned< Type > &dt)

void	max (const dimensioned< Type > &dt)

void	clip (const dimensioned< MinMax< Type >> &range)

void	clip (const dimensioned< Type > &minVal, const dimensioned< Type > &maxVal)

void	maxMin (const dimensioned< Type > &minVal, const dimensioned< Type > &maxVal)

const Internal &	operator() () const

void	operator= (const GeometricField< Type, PatchField, GeoMesh > &)

void	operator= (const tmp< GeometricField< Type, PatchField, GeoMesh >> &)

void	operator= (const dimensioned< Type > &)

void	operator== (const tmp< GeometricField< Type, PatchField, GeoMesh >> &)

void	operator== (const dimensioned< Type > &)

void	operator+= (const GeometricField< Type, PatchField, GeoMesh > &)

void	operator+= (const tmp< GeometricField< Type, PatchField, GeoMesh >> &)

void	operator-= (const GeometricField< Type, PatchField, GeoMesh > &)

void	operator-= (const tmp< GeometricField< Type, PatchField, GeoMesh >> &)

void	operator*= (const GeometricField< scalar, PatchField, GeoMesh > &)

void	operator*= (const tmp< GeometricField< scalar, PatchField, GeoMesh >> &)

void	operator/= (const GeometricField< scalar, PatchField, GeoMesh > &)

void	operator/= (const tmp< GeometricField< scalar, PatchField, GeoMesh >> &)

void	operator+= (const dimensioned< Type > &)

void	operator-= (const dimensioned< Type > &)

void	operator*= (const dimensioned< scalar > &)

void	operator/= (const dimensioned< scalar > &)

tmp< GeometricField< scalar, faPatchField, areaMesh > >	component (const direction) const

void	replace (const direction, const GeometricField< scalar, faPatchField, areaMesh > &gsf)

tmp< GeometricField< scalar, faPatchField, areaMesh > >	component (const direction) const

void	replace (const direction, const GeometricField< scalar, faPatchField, areaMesh > &sf)

tmp< GeometricField< scalar, fvPatchField, volMesh > >	component (const direction) const

void	replace (const direction, const GeometricField< scalar, fvPatchField, volMesh > &gsf)

tmp< GeometricField< scalar, fvPatchField, volMesh > >	component (const direction) const

void	replace (const direction, const GeometricField< scalar, fvPatchField, volMesh > &sf)

Public Member Functions inherited from cellDistFuncs
	ClassName ("cellDistFuncs")

	cellDistFuncs (const polyMesh &mesh)

const polyMesh &	mesh () const

labelHashSet	getPatchIDs (const UList< wordRe > &patchNames) const

template<class Type >
labelHashSet	getPatchIDs () const

scalar	smallestDist (const point &p, const polyPatch &patch, const labelUList &wallFaces, label &meshFacei) const

void	getPointNeighbours (const primitivePatch &, const label patchFacei, DynamicList< label > &) const

label	maxPatchSize (const labelHashSet &patchIDs) const

label	sumPatchSize (const labelHashSet &patchIDs) const

void	correctBoundaryFaceCells (const labelHashSet &patchIDs, scalarField &wallDistCorrected, Map< label > &nearestFace) const

void	correctBoundaryPointCells (const labelHashSet &patchIDs, scalarField &wallDistCorrected, Map< label > &nearestFace) const

template<class Type >
Foam::labelHashSet	getPatchIDs () const

Additional Inherited Members
Public Types inherited from GeometricField
typedef GeoMesh::Mesh	Mesh

typedef GeoMesh::BoundaryMesh	BoundaryMesh

typedef DimensionedField< Type, GeoMesh >	Internal

typedef PatchField< Type >	Patch

typedef Field< Type >::cmptType	cmptType

Static Public Member Functions inherited from GeometricField
static const GeometricField< Type, PatchField, GeoMesh > &	null ()

static tmp< GeometricField< Type, PatchField, GeoMesh > >	New (const word &name, const Mesh &mesh, const dimensionSet &ds, const word &patchFieldType=PatchField< Type >::calculatedType())

static tmp< GeometricField< Type, PatchField, GeoMesh > >	New (const word &name, const Mesh &mesh, const dimensionSet &ds, const Field< Type > &iField, const word &patchFieldType=PatchField< Type >::calculatedType())

static tmp< GeometricField< Type, PatchField, GeoMesh > >	New (const word &name, const Mesh &mesh, const dimensionSet &ds, Field< Type > &&iField, const word &patchFieldType=PatchField< Type >::calculatedType())

static tmp< GeometricField< Type, PatchField, GeoMesh > >	New (const word &name, const Mesh &mesh, const dimensioned< Type > &dt, const word &patchFieldType=PatchField< Type >::calculatedType())

static tmp< GeometricField< Type, PatchField, GeoMesh > >	New (const word &name, const Mesh &mesh, const dimensioned< Type > &dt, const wordList &patchFieldTypes, const wordList &actualPatchTypes=wordList())

static tmp< GeometricField< Type, PatchField, GeoMesh > >	New (const word &newName, const tmp< GeometricField< Type, PatchField, GeoMesh >> &tgf)

static tmp< GeometricField< Type, PatchField, GeoMesh > >	New (const word &newName, const tmp< GeometricField< Type, PatchField, GeoMesh >> &tgf, const wordList &patchFieldTypes, const wordList &actualPatchTypes=wordList())

Detailed Description

template<class TransferType>
class Foam::wallDistData< TransferType >

Wall distance calculation. Like wallDist but also transports extra data (template argument).

Used for e.g reflection vector calculation or vanDriest damping.

Templated on two parameters:

TransferType: type of overall data transported (e.g. wallPointData<vector>)

Source files

Definition at line 55 of file wallDistData.H.

Constructor & Destructor Documentation

◆ wallDistData()

wallDistData	(	const fvMesh &	mesh,
		GeometricField< Type, fvPatchField, volMesh > &	field,
		bool	correctWalls = `true`
	)

Definition at line 31 of file wallDistData.C.

References correct().

Here is the call graph for this function:

◆ ~wallDistData()

~wallDistData

virtual

Definition at line 60 of file wallDistData.C.

Member Function Documentation

◆ y()

const volScalarField& y ( ) const

inline

Definition at line 109 of file wallDistData.H.

◆ nUnset()

label nUnset ( ) const

inline

Definition at line 114 of file wallDistData.H.

◆ data()

const GeometricField<Type, fvPatchField, volMesh>& data ( ) const

inline

Definition at line 120 of file wallDistData.H.

◆ correct()

void correct

virtual

Definition at line 67 of file wallDistData.C.

References GeometricField::boundaryFieldRef(), patchDataWave< TransferType, TrackingData >::cellData(), patchDataWave< TransferType, TrackingData >::distance(), forAll, mesh, patchDataWave< TransferType, TrackingData >::nUnset(), patchDataWave< TransferType, TrackingData >::patchData(), patchDataWave< TransferType, TrackingData >::patchDistance(), and UPtrList::set().

Here is the call graph for this function:

The documentation for this class was generated from the following files:

src/finiteVolume/fvMesh/wallDist/patchDistMethods/meshWave/wallDistData/wallDistData.H
src/finiteVolume/fvMesh/wallDist/patchDistMethods/meshWave/wallDistData/wallDistData.C
