A correlation for boiling film modelling based on Bromley (1950) for boiling flows. More...

Inheritance diagram for Bromley:

Collaboration diagram for Bromley:

Public Member Functions
	TypeName ("Bromley")

	Bromley (const dictionary &dict)

virtual	~Bromley ()=default

virtual tmp< scalarField >	htcFilmBoil (const phaseModel &liquid, const phaseModel &vapor, const label patchi, const scalarField &Tl, const scalarField &Tsatw, const scalarField &L) const

virtual void	write (Ostream &os) const

Public Member Functions inherited from filmBoilingModel
	TypeName ("filmBoilingModel")

	declareRunTimeSelectionTable (autoPtr, filmBoilingModel, dictionary,(const dictionary &dict),(dict))

	filmBoilingModel ()=default

virtual	~filmBoilingModel ()=default

Additional Inherited Members
Static Public Member Functions inherited from filmBoilingModel
static autoPtr< filmBoilingModel >	New (const dictionary &dict)

Detailed Description

A correlation for boiling film modelling based on Bromley (1950) for boiling flows.

Reference:

    Bromley, L. A. (1950).
    Heat transfer in stable film boiling.
    Chemical Engineering Progress, 46, 221-227.

Usage

Example of the model specification:

filmBoilingModel
{
    // Mandatory entries
    type            Bromley;
    L               <scalar>;

    // Optional entries
    Cn              <scalar>;
    emissivity      <scalar>;
}

where the entries mean:

Property	Description	Type	Reqd	Deflt
`type`	Type name: Bromley	word	yes	-
`L`	Characteristic length scale	scalar	yes	-
`Cn`	Coefficient for nucleation site density	scalar	no	0.62
`emissivity`	Wall emissivity	scalar	no	1.0

Source files

Definition at line 112 of file Bromley.H.

Constructor & Destructor Documentation

◆ Bromley()

Bromley ( const dictionary & dict )

Definition at line 51 of file Bromley.C.

◆ ~Bromley()

virtual ~Bromley ( )

virtualdefault

Member Function Documentation

◆ TypeName()

TypeName ( "Bromley" )

◆ htcFilmBoil()

Foam::tmp< Foam::scalarField > htcFilmBoil	(	const phaseModel &	liquid,
		const phaseModel &	vapor,
		const label	patchi,
		const scalarField &	Tl,
		const scalarField &	Tsatw,
		const scalarField &	L
	)		const

virtual

Implements filmBoilingModel.

Definition at line 66 of file Bromley.C.

References cells, basicThermo::Cp(), Foam::constant::electromagnetic::e, g, phaseModel::kappa(), L(), Foam::mag(), Foam::max(), phaseModel::mu(), Foam::pow025(), Foam::pow3(), Foam::pow4(), tmp::ref(), basicThermo::rhoEoS(), Foam::constant::physicoChemical::sigma, tCp, and phaseModel::thermo().

Here is the call graph for this function:

◆ write()

void write ( Ostream & os ) const

virtual

Reimplemented from filmBoilingModel.

Definition at line 116 of file Bromley.C.

References os(), and Foam::vtk::write().
