Public Member Functions | Static Public Member Functions | List of all members
seriesWriter Class Reference

Provides a means of accumulating and generating VTK file series. More...

Public Member Functions

 seriesWriter ()=default

 seriesWriter (const seriesWriter &)=default

 seriesWriter (seriesWriter &&)=default

seriesWriter & operator= (const seriesWriter &)=default

seriesWriter & operator= (seriesWriter &&)=default

 ~seriesWriter ()=default

bool empty () const noexcept

label size () const noexcept

void clear ()

bool append (const fileNameInstant &inst)

bool append (fileNameInstant &&inst)

bool append (scalar timeValue, const fileName &file)

bool append (scalar timeValue, fileName &&file)

label load (const fileName &seriesName, const bool checkFiles=false, const scalar restartTime=ROOTVGREAT)

label scan (const fileName &seriesName, const scalar restartTime=ROOTVGREAT)

bool removeNewer (const scalar timeValue)

void sort ()

void print (Ostream &os) const

void write (const fileName &seriesName) const


Static Public Member Functions

static fileName base (const fileName &outputName, char sep='_')

static word suffix (const fileName &file, char sep='_')

static Ostream & print (Ostream &os, const fileName &seriesName, const UList< instant > &series, const char sep='_')

static void write (const fileName &base, const UList< instant > &series, const char sep='_')

static Ostream & print (Ostream &os, const UList< fileNameInstant > &series)

static void write (const fileName &seriesName, const UList< fileNameInstant > &series)


Detailed Description

Provides a means of accumulating and generating VTK file series.

The VTK file series format is a simple JSON format with the following type of content:

{
  "file-series-version" : "1.0",
  "files": [
    { "name" : "file1.vtk", "time" : 10 },
    { "name" : "file2.vtk", "time" : 20 },
    { "name" : "file3.vtk", "time" : 30 },
  ]
}

The append() operations include various sanity checks. Entries with an empty name are ignored. If an entry with an identical name already exists, its place will be overwritten with the new time value.

Source files

Definition at line 71 of file foamVtkSeriesWriter.H.

Constructor & Destructor Documentation

◆ seriesWriter() [1/3]

seriesWriter ( )
default

◆ seriesWriter() [2/3]

seriesWriter ( const seriesWriter &  )
default

◆ seriesWriter() [3/3]

seriesWriter ( seriesWriter &&  )
default

◆ ~seriesWriter()

~seriesWriter ( )
default

Member Function Documentation

◆ operator=() [1/2]

seriesWriter& operator= ( const seriesWriter &  )
default

◆ operator=() [2/2]

seriesWriter& operator= ( seriesWriter &&  )
default

◆ base()

Foam::fileName base ( const fileName &  outputName,
char  sep = '_'
)
static

Definition at line 84 of file foamVtkSeriesWriter.C.

References Foam::dot(), and outputName().

Referenced by vtkCloud::write(), and vtkWrite::write().

Here is the call graph for this function:
Here is the caller graph for this function:

◆ suffix()

Foam::word suffix ( const fileName &  file,
char  sep = '_'
)
static

Definition at line 114 of file foamVtkSeriesWriter.C.

References Foam::dot().

Here is the call graph for this function:

◆ print() [1/3]

Foam::Ostream & print ( Ostream &  os,
const fileName &  seriesName,
const UList< instant > &  series,
const char  sep = '_'
)
static

Definition at line 144 of file foamVtkSeriesWriter.C.

References fileName::ext(), fileName::nameLessExt(), Foam::nl, os(), and UList::size().

Referenced by seriesWriter::print().

Here is the call graph for this function:
Here is the caller graph for this function:

◆ write() [1/3]

void write ( const fileName &  base,
const UList< instant > &  series,
const char  sep = '_'
)
static

Definition at line 226 of file foamVtkSeriesWriter.C.

References fileName::hasExt(), Foam::mkDir(), Foam::New(), fileName::path(), and Foam::BitOps::print().

Referenced by seriesWriter::write(), vtkCloud::write(), and vtkWrite::write().

Here is the call graph for this function:
Here is the caller graph for this function:

◆ print() [2/3]

Foam::Ostream & print ( Ostream &  os,
const UList< fileNameInstant > &  series
)
static

Definition at line 191 of file foamVtkSeriesWriter.C.

References Foam::nl, os(), and UList::size().

Here is the call graph for this function:

◆ write() [2/3]

void write ( const fileName &  seriesName,
const UList< fileNameInstant > &  series
)
static

Definition at line 247 of file foamVtkSeriesWriter.C.

References fileName::hasExt(), Foam::mkDir(), Foam::New(), fileName::path(), and Foam::BitOps::print().

Here is the call graph for this function:

◆ empty()

bool empty ( ) const
inlinenoexcept

Definition at line 23 of file foamVtkSeriesWriterI.H.

Referenced by vtkCloud::write(), and vtkWrite::write().

Here is the caller graph for this function:

◆ size()

Foam::label size ( ) const
inlinenoexcept

Definition at line 29 of file foamVtkSeriesWriterI.H.

◆ clear()

void clear ( )
inline

Definition at line 35 of file foamVtkSeriesWriterI.H.

◆ append() [1/4]

bool append ( const fileNameInstant &  inst)
inline

Definition at line 42 of file foamVtkSeriesWriterI.H.

References Instant< T >::name(), and Instant< T >::value().

Referenced by vtkCloud::write(), and vtkWrite::write().

Here is the call graph for this function:
Here is the caller graph for this function:

◆ append() [2/4]

bool append ( fileNameInstant &&  inst)
inline

Definition at line 49 of file foamVtkSeriesWriterI.H.

◆ append() [3/4]

bool append ( scalar  timeValue,
const fileName &  file
)
inline

Definition at line 59 of file foamVtkSeriesWriterI.H.

References fileName::name().

Here is the call graph for this function:

◆ append() [4/4]

bool append ( scalar  timeValue,
fileName &&  file
)
inline

Definition at line 70 of file foamVtkSeriesWriterI.H.

References fileName::removePath().

Here is the call graph for this function:

◆ load()

Foam::label load ( const fileName &  seriesName,
const bool  checkFiles = false,
const scalar  restartTime = ROOTVGREAT
)

Definition at line 359 of file foamVtkSeriesWriter.C.

References token::BEGIN_BLOCK, token::BEGIN_SQR, clear(), token::COMMA, token::END_BLOCK, token::END_SQR, fileName::ext(), Foam::getToken(), Foam::getValueToken(), fileName::hasExt(), HashSet::insert(), Foam::isFile(), token::isNumber(), token::isPunctuation(), token::isString(), Foam::glTF::key(), Foam::lessThan(), Instant< T >::name(), token::number(), fileName::path(), token::pToken(), Foam::readDir(), token::stringToken(), and Instant< T >::value().

Referenced by vtkCloud::write(), and vtkWrite::write().

Here is the call graph for this function:
Here is the caller graph for this function:

◆ scan()

Foam::label scan ( const fileName &  seriesName,
const scalar  restartTime = ROOTVGREAT
)

Definition at line 577 of file foamVtkSeriesWriter.C.

References append(), clear(), fileName::ext(), fileName::hasExt(), Foam::Info, Foam::isDir(), Foam::lessThan(), fileName::nameLessExt(), Foam::nl, path(), fileName::path(), Foam::readDir(), fileName::removeExt(), Foam::sort(), string::starts_with(), and Foam::subsetList().

Here is the call graph for this function:

◆ removeNewer()

bool removeNewer ( const scalar  timeValue)

Definition at line 708 of file foamVtkSeriesWriter.C.

References Foam::lessThan(), Instant< T >::name(), Foam::name(), and Instant< T >::value().

Here is the call graph for this function:

◆ sort()

void sort ( )

Definition at line 738 of file foamVtkSeriesWriter.C.

References Foam::sort().

Here is the call graph for this function:

◆ print() [3/3]

void print ( Ostream &  os) const
inline

Definition at line 82 of file foamVtkSeriesWriterI.H.

References os(), and seriesWriter::print().

Here is the call graph for this function:

◆ write() [3/3]

void write ( const fileName &  seriesName) const
inline

Definition at line 88 of file foamVtkSeriesWriterI.H.

References seriesWriter::write().

Here is the call graph for this function:
The documentation for this class was generated from the following files:
