Write lagrangian (cloud) positions and fields (as PointData) in VTP format. Legacy VTK format is intentionally not supported since the VTP format provides much better field selection in ParaView, and for consistency with the Foam::functionObjects::vtkCloud function object. More...

Inheritance diagram for lagrangianWriter:

[legend]

Collaboration diagram for lagrangianWriter:

[legend]

Public Member Functions
	lagrangianWriter (const fvMesh &mesh, const word &cloudName, const vtk::outputOptions opts=vtk::formatType::INLINE_BASE64, bool useVerts=false)

	lagrangianWriter (const fvMesh &mesh, const word &cloudName, const fileName &file, bool parallel=Pstream::parRun())

	lagrangianWriter (const fvMesh &mesh, const word &cloudName, const vtk::outputOptions opts, const fileName &file, bool parallel=Pstream::parRun())

virtual	~lagrangianWriter ()=default

virtual bool	beginFile (std::string title="")

virtual bool	writeGeometry ()

bool	beginParcelData ()

bool	endParcelData ()

template<class Type >
void	write (const IOField< Type > &field)

template<class Type >
label	writeFields (const wordList &fieldNames, bool verbose=true)

template<class Type >
label	writeFields (const IOobjectList &objects, bool verbose=true)

template<class Type >
Foam::label	writeFields (const wordList &fieldNames, bool verbose)

template<class Type >
Foam::label	writeFields (const IOobjectList &objects, const bool verbose)

Public Member Functions inherited from fileWriter
	fileWriter (const vtk::fileTag contentType, const vtk::outputOptions opts)

virtual	~fileWriter ()

vtk::fileTag	contentType () const

vtk::outputOptions	opts () const

word	ext () const

bool	legacy () const

bool	parallel () const noexcept

const word &	state () const

const fileName &	output () const noexcept

bool	open (const fileName &file, bool parallel=Pstream::parRun())

void	close ()

bool	beginFieldData (label nFields=0)

label	nCellData () const noexcept

label	nPointData () const noexcept

bool	endFieldData ()

bool	endCellData ()

bool	endPointData ()

void	writeTimeValue (scalar timeValue)

Static Public Member Functions
static word	ext (vtk::outputOptions)

Protected Member Functions
virtual bool	beginCellData (label nFields=0)

virtual bool	beginPointData (label nFields=0)

Protected Member Functions inherited from fileWriter
void	checkFormatterValidity () const

Ostream &	reportBadState (Ostream &, outputState expected) const

Ostream &	reportBadState (Ostream &, outputState, outputState) const

std::ofstream &	os () noexcept

vtk::formatter &	format ()

bool	isState (outputState test) const noexcept

bool	notState (outputState test) const noexcept

template<class Type >
void	beginDataArray (const word &fieldName, const label nValues)

void	endDataArray ()

void	beginPoints (const label nPoints)

void	endPoints ()

bool	enter_Piece ()

bool	endPiece ()

bool	enter_CellData (label nEntries, label nFields)

bool	enter_PointData (label nEntries, label nFields)

bool	exit_File ()

template<class Type >
void	writeUniform (const word &fieldName, const Type &val, const label nValues)

template<class Type >
void	writeBasicField (const word &fieldName, const UList< Type > &field)

bool	writeProcIDs (const label nValues)

	fileWriter (const fileWriter &)=delete

void	operator= (const fileWriter &)=delete

Additional Inherited Members
Protected Types inherited from fileWriter
enum	outputState { CLOSED = 0, OPENED, DECLARED, FIELD_DATA, PIECE, CELL_DATA, POINT_DATA }

Protected Attributes inherited from fileWriter
vtk::fileTag	contentType_

outputOptions	opts_

bool	parallel_

outputState	state_

label	nCellData_

label	nPointData_

fileName	outputFile_

autoPtr< vtk::formatter >	format_

std::ofstream	os_

Static Protected Attributes inherited from fileWriter
static const Enum< outputState >	stateNames

Detailed Description

Write lagrangian (cloud) positions and fields (as PointData) in VTP format. Legacy VTK format is intentionally not supported since the VTP format provides much better field selection in ParaView, and for consistency with the Foam::functionObjects::vtkCloud function object.

The file output states are managed by the Foam::vtk::fileWriter class. FieldData (eg, TimeValue) must appear before any geometry pieces.

Note: If fields should be CellData instead of PointData (default), this must be decided at construction time.

Source files

Definition at line 66 of file foamVtkLagrangianWriter.H.

Constructor & Destructor Documentation

◆ lagrangianWriter() [1/3]

lagrangianWriter	(	const fvMesh &	mesh,
		const word &	cloudName,
		const vtk::outputOptions	opts = `vtk::formatType::INLINE_BASE64`,
		bool	useVerts = `false`
	)

Definition at line 111 of file foamVtkLagrangianWriter.C.

References fileWriter::legacy().

Here is the call graph for this function:

◆ lagrangianWriter() [2/3]

lagrangianWriter	(	const fvMesh &	mesh,
		const word &	cloudName,
		const fileName &	file,
		bool	parallel = `Pstream::parRun()`
	)

Definition at line 130 of file foamVtkLagrangianWriter.C.

◆ lagrangianWriter() [3/3]

lagrangianWriter	(	const fvMesh &	mesh,
		const word &	cloudName,
		const vtk::outputOptions	opts,
		const fileName &	file,
		bool	parallel = `Pstream::parRun()`
	)
