viscosityModel Class Reference

An abstract base class for incompressible viscosityModels. More...

Inheritance diagram for viscosityModel:

Collaboration diagram for viscosityModel:

Public Member Functions
	TypeName ("viscosityModel")
	declareRunTimeSelectionTable (autoPtr, viscosityModel, dictionary,(const word &name, const dictionary &viscosityProperties, const volVectorField &U, const surfaceScalarField &phi),(name, viscosityProperties, U, phi))
	viscosityModel (const word &name, const dictionary &viscosityProperties, const volVectorField &U, const surfaceScalarField &phi)
virtual	~viscosityModel ()=default
const dictionary &	viscosityProperties () const
tmp< volScalarField >	strainRate () const
virtual tmp< volScalarField >	nu () const =0
virtual tmp< scalarField >	nu (const label patchi) const =0
virtual void	correct ()=0
virtual bool	read (const dictionary &viscosityProperties)=0

Static Public Member Functions
static autoPtr< viscosityModel >	New (const word &name, const dictionary &viscosityProperties, const volVectorField &U, const surfaceScalarField &phi)

Protected Member Functions
	viscosityModel (const viscosityModel &)=delete
void	operator= (const viscosityModel &)=delete

Protected Attributes
word	name_
dictionary	viscosityProperties_
const volVectorField &	U_
const surfaceScalarField &	phi_

Detailed Description

An abstract base class for incompressible viscosityModels.

Source files

• viscosityModel.H
• viscosityModel.C

The strain rate is defined by:

mag(symm(grad(U)))

Source files

• viscosityModel.H
• viscosityModel.C
• viscosityModelNew.C

Definition at line 64 of file viscosityModel.H.

Constructor & Destructor Documentation

viscosityModel() [1/2]

viscosityModel ( const viscosityModel &  )

protecteddelete

viscosityModel() [2/2]

viscosityModel	(	const word &	name,
		const dictionary &	viscosityProperties,
		const volVectorField &	U,
		const surfaceScalarField &	phi
	)

Definition at line 37 of file viscosityModel.C.

~viscosityModel()

virtual ~viscosityModel ( )

virtualdefault

Member Function Documentation

operator=()

void operator= ( const viscosityModel &  )

protecteddelete

TypeName()

TypeName

(

"viscosityModel"

)

declareRunTimeSelectionTable()

declareRunTimeSelectionTable	(	autoPtr	,
		viscosityModel	,
		dictionary	,
		(const word &name, const dictionary &viscosityProperties, const volVectorField &U, const surfaceScalarField &phi)	,
		(name, viscosityProperties, U, phi)
	)

New()

Foam::autoPtr< Foam::viscosityModel > New ( const word &  name, const dictionary &  viscosityProperties, const volVectorField &  U, const surfaceScalarField &  phi  )

static

Definition at line 29 of file viscosityModelNew.C.

References dict, Foam::endl(), Foam::exit(), Foam::FatalIOError, FatalIOErrorInLookup, Foam::Info, Foam::name(), phi, and U.

Here is the call graph for this function:

viscosityProperties()

const dictionary& viscosityProperties ( ) const

inline

Definition at line 141 of file viscosityModel.H.

References viscosityModel::viscosityProperties_.

strainRate()

Foam::tmp< Foam::volScalarField > strainRate

(

)

const

Definition at line 53 of file viscosityModel.C.

References Foam::fvc::grad(), Foam::mag(), Foam::sqrt(), Foam::symm(), and viscosityModel::U_.

Referenced by powerLaw::calcNu(), HerschelBulkley::calcNu(), CrossPowerLaw::calcNu(), BirdCarreau::calcNu(), and Casson::calcNu().

Here is the call graph for this function:

Here is the caller graph for this function:

nu() [1/2]

virtual tmp<volScalarField> nu ( ) const

pure virtual

Implemented in Casson, strainRateFunction, BirdCarreau, CrossPowerLaw, HerschelBulkley, powerLaw, and Newtonian.

nu() [2/2]

virtual tmp<scalarField> nu ( const label  patchi ) const

pure virtual

Implemented in Casson, strainRateFunction, BirdCarreau, CrossPowerLaw, HerschelBulkley, powerLaw, and Newtonian.

correct()

virtual void correct ( )

pure virtual

Implemented in Casson, BirdCarreau, strainRateFunction, CrossPowerLaw, HerschelBulkley, powerLaw, and Newtonian.

read()

bool read ( const dictionary &  viscosityProperties )

pure virtual

Implemented in Casson, BirdCarreau, CrossPowerLaw, HerschelBulkley, powerLaw, strainRateFunction, and Newtonian.

Definition at line 59 of file viscosityModel.C.

Referenced by strainRateFunction::read(), CrossPowerLaw::read(), HerschelBulkley::read(), powerLaw::read(), BirdCarreau::read(), and Casson::read().

Here is the caller graph for this function:

Member Data Documentation

name_

word name_

protected

Definition at line 71 of file viscosityModel.H.

viscosityProperties_

dictionary viscosityProperties_

protected

Definition at line 72 of file viscosityModel.H.

Referenced by viscosityModel::viscosityProperties().

U_

const volVectorField& U_

protected

Definition at line 74 of file viscosityModel.H.

Referenced by viscosityModel::strainRate().

phi_

const surfaceScalarField& phi_

protected

Definition at line 75 of file viscosityModel.H.

---

The documentation for this class was generated from the following files:

• src/transportModels/incompressible/viscosityModels/viscosityModel/viscosityModel.H
• src/transportModels/incompressible/viscosityModels/viscosityModel/viscosityModel.C
• src/transportModels/incompressible/viscosityModels/viscosityModel/viscosityModelNew.C
