triSurfaceLoader Class Reference

Convenience class for loading single or multiple surface files from the constant/triSurface (or other) directory. More...

Collaboration diagram for triSurfaceLoader:

Public Types
enum	loadingOption { SINGLE_REGION, FILE_REGION, OFFSET_REGION, MERGE_REGION }

Public Member Functions
	triSurfaceLoader (const fileName &directory)
	triSurfaceLoader (const Time &runTime)
	~triSurfaceLoader ()=default
const fileName &	directory () const
const hashedWordList &	available () const
const hashedWordList &	selected () const
label	readDir ()
label	selectAll ()
label	select (const word &name)
label	select (const wordRe &mat)
label	select (const UList< wordRe > &matcher)
autoPtr< triSurface >	load (const enum loadingOption opt=loadingOption::OFFSET_REGION, const scalar scaleFactor=-1) const

Static Public Attributes
static const Enum< loadingOption >	loadingOptionNames

Detailed Description

Convenience class for loading single or multiple surface files from the constant/triSurface (or other) directory.

Surfaces selection based on word, wordRe, list of wordRe. If multiple surfaces are selected, they are concatenated into a single surface with offset faces,points,regions.

Source files

• triSurfaceLoader.H
• triSurfaceLoader.C

Definition at line 58 of file triSurfaceLoader.H.

Member Enumeration Documentation

loadingOption

enum loadingOption

Enumerator
SINGLE_REGION	"single" = One region for all files
FILE_REGION	"file" = One region for each file
OFFSET_REGION	"offset" = Offset regions per file
MERGE_REGION	"merge" = Merge regions by name

Definition at line 63 of file triSurfaceLoader.H.

Constructor & Destructor Documentation

triSurfaceLoader() [1/2]

triSurfaceLoader

(

const fileName &

directory

)

Definition at line 43 of file triSurfaceLoader.C.

References triSurfaceLoader::readDir().

Here is the call graph for this function:

triSurfaceLoader() [2/2]

triSurfaceLoader

(

const Time &

runTime

)

Definition at line 53 of file triSurfaceLoader.C.

References triSurfaceLoader::readDir().

Here is the call graph for this function:

~triSurfaceLoader()

~triSurfaceLoader ( )

default

Member Function Documentation

directory()

const fileName& directory ( ) const

inline

Definition at line 117 of file triSurfaceLoader.H.

available()

const hashedWordList& available ( ) const

inline

Definition at line 123 of file triSurfaceLoader.H.

selected()

const hashedWordList& selected ( ) const

inline

Definition at line 129 of file triSurfaceLoader.H.

readDir()

Foam::label readDir

(

)

Definition at line 65 of file triSurfaceLoader.C.

References triSurface::canRead(), f(), fileName::FILE, Foam::PtrListOps::names(), and Foam::readDir().

Referenced by triSurfaceLoader::triSurfaceLoader().

Here is the call graph for this function:

Here is the caller graph for this function:

selectAll()

Foam::label selectAll

(

)

Definition at line 90 of file triSurfaceLoader.C.

select() [1/3]

Foam::label select

(

const word &

name

)

Definition at line 97 of file triSurfaceLoader.C.

References Foam::name().

Here is the call graph for this function:

select() [2/3]

Foam::label select

(

const wordRe &

mat

)

Definition at line 112 of file triSurfaceLoader.C.

References DynamicList::append(), Foam::exit(), Foam::FatalError, FatalErrorInFunction, Foam::findStrings(), wordRe::isPattern(), Foam::nl, and Foam::sort().

Here is the call graph for this function:

select() [3/3]

Foam::label select

(

const UList< wordRe > &

matcher

)

Definition at line 142 of file triSurfaceLoader.C.

References DynamicList::append(), Foam::exit(), Foam::FatalError, FatalErrorInFunction, Foam::findStrings(), Foam::flatOutput(), HashSet::insert(), Foam::nl, UList::size(), and Foam::sort().

Here is the call graph for this function:

load()

Foam::autoPtr< Foam::triSurface > load	(	const enum loadingOption	opt = loadingOption::OFFSET_REGION,
		const scalar	scaleFactor = -1
	)		const

Definition at line 205 of file triSurfaceLoader.C.

References PtrList::append(), List::append(), f(), forAll, HashTable::insert(), Foam::output(), p, patches, triSurface::patches(), patchId(), points, List::setSize(), triSurface::swapFaces(), triSurface::swapPoints(), and List::transfer().

Here is the call graph for this function:

Member Data Documentation

loadingOptionNames

const Foam::Enum< Foam::triSurfaceLoader::loadingOption > loadingOptionNames

static

Definition at line 72 of file triSurfaceLoader.H.

---

The documentation for this class was generated from the following files:

• src/meshTools/triSurface/triSurfaceLoader/triSurfaceLoader.H
• src/meshTools/triSurface/triSurfaceLoader/triSurfaceLoader.C
