totalTemperatureFvPatchScalarField Class Reference

This boundary condition provides a total temperature condition. More...

Inheritance diagram for totalTemperatureFvPatchScalarField:

Collaboration diagram for totalTemperatureFvPatchScalarField:

Public Member Functions
	TypeName ("totalTemperature")
	totalTemperatureFvPatchScalarField (const fvPatch &, const DimensionedField< scalar, volMesh > &)
	totalTemperatureFvPatchScalarField (const fvPatch &, const DimensionedField< scalar, volMesh > &, const dictionary &)
	totalTemperatureFvPatchScalarField (const totalTemperatureFvPatchScalarField &, const fvPatch &, const DimensionedField< scalar, volMesh > &, const fvPatchFieldMapper &)
	totalTemperatureFvPatchScalarField (const totalTemperatureFvPatchScalarField &)
virtual tmp< fvPatchScalarField >	clone () const
	totalTemperatureFvPatchScalarField (const totalTemperatureFvPatchScalarField &, const DimensionedField< scalar, volMesh > &)
virtual tmp< fvPatchScalarField >	clone (const DimensionedField< scalar, volMesh > &iF) const
const scalarField &	T0 () const
scalarField &	T0 ()
virtual void	autoMap (const fvPatchFieldMapper &)
virtual void	rmap (const fvPatchScalarField &, const labelList &)
virtual void	updateCoeffs ()
virtual void	write (Ostream &) const

Detailed Description

This boundary condition provides a total temperature condition.

Usage

Property	Description	Required	Default value
U	Velocity field name	no	U
phi	Flux field name	no	phi
psi	Compressibility field name	no	thermo:psi
gamma	ratio of specific heats (Cp/Cv)	yes
T0	total temperature	yes

Example of the boundary condition specification:

    <patchName>
    {
        type            totalTemperature;
        gamma           1.4;
        T0              uniform 800;
    }

Source files

• totalTemperatureFvPatchScalarField.H
• totalTemperatureFvPatchScalarField.C

See also

Foam::fixedValueFvPatchField

Definition at line 102 of file totalTemperatureFvPatchScalarField.H.

Constructor & Destructor Documentation

totalTemperatureFvPatchScalarField() [1/5]

totalTemperatureFvPatchScalarField	(	const fvPatch &	p,
		const DimensionedField< scalar, volMesh > &	iF
	)

Definition at line 31 of file totalTemperatureFvPatchScalarField.C.

Referenced by totalTemperatureFvPatchScalarField::clone().

Here is the caller graph for this function:

totalTemperatureFvPatchScalarField() [2/5]

totalTemperatureFvPatchScalarField	(	const fvPatch &	p,
		const DimensionedField< scalar, volMesh > &	iF,
		const dictionary &	dict
	)

Definition at line 63 of file totalTemperatureFvPatchScalarField.C.

References dict, and p.

totalTemperatureFvPatchScalarField() [3/5]

totalTemperatureFvPatchScalarField	(	const totalTemperatureFvPatchScalarField &	ptf,
		const fvPatch &	p,
		const DimensionedField< scalar, volMesh > &	iF,
		const fvPatchFieldMapper &	mapper
	)

Definition at line 46 of file totalTemperatureFvPatchScalarField.C.

totalTemperatureFvPatchScalarField() [4/5]

totalTemperatureFvPatchScalarField

(

const totalTemperatureFvPatchScalarField &

tppsf

)

Definition at line 91 of file totalTemperatureFvPatchScalarField.C.

totalTemperatureFvPatchScalarField() [5/5]

totalTemperatureFvPatchScalarField	(	const totalTemperatureFvPatchScalarField &	tppsf,
		const DimensionedField< scalar, volMesh > &	iF
	)

Definition at line 105 of file totalTemperatureFvPatchScalarField.C.

Member Function Documentation

TypeName()

TypeName

(

"totalTemperature"

)

clone() [1/2]

virtual tmp<fvPatchScalarField> clone ( ) const

inlinevirtual

Definition at line 164 of file totalTemperatureFvPatchScalarField.H.

References totalTemperatureFvPatchScalarField::totalTemperatureFvPatchScalarField().

Here is the call graph for this function:

clone() [2/2]

virtual tmp<fvPatchScalarField> clone ( const DimensionedField< scalar, volMesh > &  iF ) const

inlinevirtual

Definition at line 181 of file totalTemperatureFvPatchScalarField.H.

References totalTemperatureFvPatchScalarField::totalTemperatureFvPatchScalarField().

Here is the call graph for this function:

T0() [1/2]

const scalarField& T0 ( ) const

inline

Definition at line 197 of file totalTemperatureFvPatchScalarField.H.

T0() [2/2]

scalarField& T0 ( )

inline

Definition at line 203 of file totalTemperatureFvPatchScalarField.H.

autoMap()

void autoMap ( const fvPatchFieldMapper &  m )

virtual

Definition at line 122 of file totalTemperatureFvPatchScalarField.C.

rmap()

void rmap ( const fvPatchScalarField &  ptf, const labelList &  addr  )

virtual

Definition at line 132 of file totalTemperatureFvPatchScalarField.C.

updateCoeffs()

void updateCoeffs ( )

virtual

Definition at line 146 of file totalTemperatureFvPatchScalarField.C.

References Foam::magSqr(), Foam::foamVersion::patch, and Foam::pos0().

Here is the call graph for this function:

write()

void write ( Ostream &  os ) const

virtual

Definition at line 173 of file totalTemperatureFvPatchScalarField.C.

References os(), fvPatchField::write(), Ostream::writeEntry(), and Ostream::writeEntryIfDifferent().

Here is the call graph for this function:

---

The documentation for this class was generated from the following files:

• src/finiteVolume/fields/fvPatchFields/derived/totalTemperature/totalTemperatureFvPatchScalarField.H
• src/finiteVolume/fields/fvPatchFields/derived/totalTemperature/totalTemperatureFvPatchScalarField.C
