topoDistanceData Class Reference

For use with FaceCellWave. Determines topological distance to starting faces. Templated on passive transported data. More...

Public Member Functions
	topoDistanceData ()
	topoDistanceData (const label distance, const Type &data)
label	distance () const
const Type &	data () const
template<class TrackingData >
bool	valid (TrackingData &td) const
template<class TrackingData >
bool	sameGeometry (const polyMesh &, const topoDistanceData< Type > &, const scalar, TrackingData &td) const
template<class TrackingData >
void	leaveDomain (const polyMesh &, const polyPatch &, const label patchFacei, const point &faceCentre, TrackingData &td)
template<class TrackingData >
void	enterDomain (const polyMesh &, const polyPatch &, const label patchFacei, const point &faceCentre, TrackingData &td)
template<class TrackingData >
void	transform (const polyMesh &, const tensor &, TrackingData &td)
template<class TrackingData >
bool	updateCell (const polyMesh &, const label thisCelli, const label neighbourFacei, const topoDistanceData< Type > &neighbourInfo, const scalar tol, TrackingData &td)
template<class TrackingData >
bool	updateFace (const polyMesh &, const label thisFacei, const label neighbourCelli, const topoDistanceData< Type > &neighbourInfo, const scalar tol, TrackingData &td)
template<class TrackingData >
bool	updateFace (const polyMesh &, const label thisFacei, const topoDistanceData< Type > &neighbourInfo, const scalar tol, TrackingData &td)
template<class TrackingData >
bool	equal (const topoDistanceData< Type > &, TrackingData &td) const
bool	operator== (const topoDistanceData< Type > &) const
bool	operator!= (const topoDistanceData< Type > &) const

Friends
Ostream &	operator (Ostream &, const topoDistanceData< Type > &)
Istream &	operator>> (Istream &, topoDistanceData< Type > &)

Detailed Description

For use with FaceCellWave. Determines topological distance to starting faces. Templated on passive transported data.

Source files

• topoDistanceData.H
• topoDistanceDataI.H
• topoDistanceData.C

Definition at line 49 of file topoDistanceData.H.

Constructor & Destructor Documentation

topoDistanceData() [1/2]

topoDistanceData ( )

inline

Definition at line 27 of file topoDistanceDataI.H.

topoDistanceData() [2/2]

topoDistanceData ( const label  distance, const Type &  data  )

inline

Definition at line 36 of file topoDistanceDataI.H.

Member Function Documentation

distance()

label distance ( ) const

inline

Definition at line 92 of file topoDistanceData.H.

Referenced by structuredRenumber::layerLess::operator()(), and topoDistanceData::operator==().

Here is the caller graph for this function:

data()

const Type& data ( ) const

inline

Definition at line 97 of file topoDistanceData.H.

Referenced by structuredRenumber::layerLess::operator()(), and topoDistanceData::operator==().

Here is the caller graph for this function:

valid()

bool valid ( TrackingData &  td ) const

inline

Definition at line 50 of file topoDistanceDataI.H.

Referenced by structuredRenumber::layerLess::operator()().

Here is the caller graph for this function:

sameGeometry()

bool sameGeometry ( const polyMesh &  , const topoDistanceData< Type > &  , const  scalar, TrackingData &  td  ) const

inline

Definition at line 60 of file topoDistanceDataI.H.

leaveDomain()

void leaveDomain ( const polyMesh &  , const polyPatch &  patch, const label  patchFacei, const point &  faceCentre, TrackingData &  td  )

inline

Definition at line 75 of file topoDistanceDataI.H.

enterDomain()

void enterDomain ( const polyMesh &  , const polyPatch &  patch, const label  patchFacei, const point &  faceCentre, TrackingData &  td  )

inline

Definition at line 101 of file topoDistanceDataI.H.

transform()

void transform ( const polyMesh &  , const tensor &  rotTensor, TrackingData &  td  )

inline

Definition at line 89 of file topoDistanceDataI.H.

updateCell()

bool updateCell ( const polyMesh &  , const label  thisCelli, const label  neighbourFacei, const topoDistanceData< Type > &  neighbourInfo, const scalar  tol, TrackingData &  td  )

inline

Definition at line 115 of file topoDistanceDataI.H.

updateFace() [1/2]

bool updateFace ( const polyMesh &  mesh, const label  thisFacei, const label  neighbourCelli, const topoDistanceData< Type > &  neighbourInfo, const scalar  tol, TrackingData &  td  )

inline

Definition at line 138 of file topoDistanceDataI.H.

updateFace() [2/2]

bool updateFace ( const polyMesh &  , const label  thisFacei, const topoDistanceData< Type > &  neighbourInfo, const scalar  tol, TrackingData &  td  )

inline

Definition at line 164 of file topoDistanceDataI.H.

equal()

bool equal ( const topoDistanceData< Type > &  rhs, TrackingData &  td  ) const

inline

Definition at line 186 of file topoDistanceDataI.H.

References Foam::operator==().

Here is the call graph for this function:

operator==()

bool operator== ( const topoDistanceData< Type > &  rhs ) const

inline

Definition at line 199 of file topoDistanceDataI.H.

References topoDistanceData::data(), Foam::distance(), and topoDistanceData::distance().

Here is the call graph for this function:

operator!=()

bool operator!= ( const topoDistanceData< Type > &  rhs ) const

inline

Definition at line 209 of file topoDistanceDataI.H.

Friends And Related Function Documentation

operator

Ostream& operator ( Ostream &  , const topoDistanceData< Type > &    )

friend

operator>>

Istream& operator>> ( Istream &  , topoDistanceData< Type > &    )

friend

---

The documentation for this class was generated from the following files:

• src/meshTools/meshStructure/topoDistanceData.H
• src/meshTools/meshStructure/topoDistanceDataI.H
