tetDecomposer Class Reference

Decomposes polyMesh into tets or pyramids. More...

Collaboration diagram for tetDecomposer:

Public Types
enum	decompositionType { FACE_CENTRE_TRIS, FACE_DIAG_TRIS, PYRAMID }

Public Member Functions
	ClassName ("tetDecomposer")
	tetDecomposer (const polyMesh &)
const labelList &	cellToPoint () const
const labelList &	faceToPoint () const
const labelListList &	faceOwnerCells () const
const labelListList &	faceNeighbourCells () const
void	setRefinement (const decompositionType decomposeType, const bitSet &decomposeCell, polyTopoChange &meshMod)
void	updateMesh (const mapPolyMesh &)

Static Public Attributes
static const Enum< decompositionType >	decompositionTypeNames

Detailed Description

Decomposes polyMesh into tets or pyramids.

Cells neighbouring decomposed cells are not decomposed themselves so will be polyhedral.

Source files

• tetDecomposer.H
• tetDecomposer.C

Definition at line 59 of file tetDecomposer.H.

Member Enumeration Documentation

decompositionType

enum decompositionType

Enumerator
FACE_CENTRE_TRIS
FACE_DIAG_TRIS
PYRAMID

Definition at line 65 of file tetDecomposer.H.

Constructor & Destructor Documentation

tetDecomposer()

tetDecomposer

(

const polyMesh &

mesh

)

Definition at line 174 of file tetDecomposer.C.

Member Function Documentation

ClassName()

ClassName

(

"tetDecomposer"

)

cellToPoint()

const labelList& cellToPoint ( ) const

inline

Definition at line 154 of file tetDecomposer.H.

faceToPoint()

const labelList& faceToPoint ( ) const

inline

Definition at line 160 of file tetDecomposer.H.

faceOwnerCells()

const labelListList& faceOwnerCells ( ) const

inline

Definition at line 169 of file tetDecomposer.H.

faceNeighbourCells()

const labelListList& faceNeighbourCells ( ) const

inline

Definition at line 177 of file tetDecomposer.H.

setRefinement()

void setRefinement	(	const decompositionType	decomposeType,
		const bitSet &	decomposeCell,
		polyTopoChange &	meshMod
	)

Definition at line 183 of file tetDecomposer.C.

References Foam::abort(), polyTopoChange::addCell(), polyTopoChange::addPoint(), HashTable::clear(), Foam::constant::electromagnetic::e, HashTable::end(), f(), Foam::FatalError, FatalErrorInFunction, HashTable::find(), faceZone::flipMap(), forAll, HashTable::insert(), Foam::max(), face::nextLabel(), p0, face::prevLabel(), List::setSize(), PackedList::setSize(), syncTools::swapBoundaryFaceList(), and faceZone::whichFace().

Here is the call graph for this function:

updateMesh()

void updateMesh

(

const mapPolyMesh &

map

)

Definition at line 845 of file tetDecomposer.C.

References forAll, Foam::inplaceRenumber(), mapPolyMesh::reverseCellMap(), and mapPolyMesh::reversePointMap().

Here is the call graph for this function:

Member Data Documentation

decompositionTypeNames

const Foam::Enum< Foam::tetDecomposer::decompositionType > decompositionTypeNames

static

Definition at line 72 of file tetDecomposer.H.

---

The documentation for this class was generated from the following files:

• src/dynamicMesh/polyTopoChange/polyTopoChange/tetDecomposer.H
• src/dynamicMesh/polyTopoChange/polyTopoChange/tetDecomposer.C
