Common functions used in temperature coupled boundaries. More...

Inheritance diagram for temperatureCoupledBase:

[legend]

Collaboration diagram for temperatureCoupledBase:

[legend]

Public Types
enum	KMethodType { mtFluidThermo, mtSolidThermo, mtDirectionalSolidThermo, mtLookup, mtFunction }

Public Member Functions
	temperatureCoupledBase (const fvPatch &patch, const word &calculationMethod, const word &kappaName, const word &alphaAniName, const word &alphaName)

	temperatureCoupledBase (const fvPatch &patch, const dictionary &dict)

	temperatureCoupledBase (const fvPatch &patch, const temperatureCoupledBase &base)

	temperatureCoupledBase (const temperatureCoupledBase &)

virtual	~temperatureCoupledBase ()=default

word	KMethod () const

const word &	kappaName () const

const word &	alphaName () const

virtual void	autoMap (const fvPatchFieldMapper &)=0

virtual void	rmap (const fvPatchField< scalar > &, const labelList &)=0

virtual tmp< scalarField >	kappa (const scalarField &Tp) const

virtual tmp< scalarField >	alpha (const scalarField &Tp) const

void	write (Ostream &os) const

Protected Attributes
const fvPatch &	patch_

const KMethodType	method_

const word	kappaName_

const word	alphaAniName_

const word	alphaName_

autoPtr< PatchFunction1< scalar > >	kappaFunction1_

autoPtr< PatchFunction1< scalar > >	alphaFunction1_

Static Protected Attributes
static const Enum< KMethodType >	KMethodTypeNames_

Detailed Description

Common functions used in temperature coupled boundaries.

The thermal conductivity kappa may be obtained by the following methods:

'lookup' : lookup volScalarField (or volSymmTensorField) with name defined by 'kappa'
'fluidThermo' : use fluidThermo and default compressible::turbulenceModel to calculate kappa
'solidThermo' : use solidThermo kappa()
'directionalSolidThermo': uses look up for volSymmTensorField for transformed kappa vector. Field name definable in 'alphaAni', named 'Anialpha' in solid solver by default
'function' : kappa, alpha directly specified as Function1
'phaseSystem' : used for multiphase thermos

Keywords provided by this class:

Property	Description	Required
`kappaMethod`	Thermal conductivity method	yes
`kappa`	Name of thermal conductivity field	no
`alpha`	Name of thermal diffusivity field	no
`alphaAni`	Name of non-isotropic alpha	no
`kappaValue`	Function1 supplying kappa	no
`alphaValue`	Function1 supplying alpha	no

Usage

nonIsotropicWall
{
    ...
    kappaMethod     directionalSolidThermo;
    alphaAni        Anialpha;
    ...
}

specifiedWall
{
    ...
    kappaMethod     function;
    kappaFunction   constant 1.0;
    alphaFunction   constant 100.0;
    ...
}

Source files

Definition at line 131 of file temperatureCoupledBase.H.

Member Enumeration Documentation

◆ KMethodType

enum KMethodType

Enumerator
mtFluidThermo
mtSolidThermo
mtDirectionalSolidThermo
mtLookup
mtFunction

Definition at line 138 of file temperatureCoupledBase.H.

Constructor & Destructor Documentation

◆ temperatureCoupledBase() [1/4]

temperatureCoupledBase	(	const fvPatch &	patch,
		const word &	calculationMethod,
		const word &	kappaName,
		const word &	alphaAniName,
		const word &	alphaName
	)

Definition at line 47 of file temperatureCoupledBase.C.

◆ temperatureCoupledBase() [2/4]

temperatureCoupledBase	(	const fvPatch &	patch,
		const dictionary &	dict
	)

Definition at line 64 of file temperatureCoupledBase.C.

References dict, Foam::exit(), Foam::FatalIOError, FatalIOErrorInFunction, Foam::New(), Foam::nl, and Foam::foamVersion::patch.

Here is the call graph for this function:

◆ temperatureCoupledBase() [3/4]

temperatureCoupledBase	(	const fvPatch &	patch,
		const temperatureCoupledBase &	base
	)

Definition at line 147 of file temperatureCoupledBase.C.

◆ temperatureCoupledBase() [4/4]

temperatureCoupledBase ( const temperatureCoupledBase & base )

Definition at line 132 of file temperatureCoupledBase.C.

◆ ~temperatureCoupledBase()

virtual ~temperatureCoupledBase ( )

virtualdefault

Member Function Documentation

◆ KMethod()

word KMethod ( ) const

inline

Definition at line 218 of file temperatureCoupledBase.H.

References temperatureCoupledBase::KMethodTypeNames_, and temperatureCoupledBase::method_.

◆ kappaName()

const word& kappaName ( ) const

inline

Definition at line 224 of file temperatureCoupledBase.H.

References temperatureCoupledBase::kappaName_.

◆ alphaName()

const word& alphaName ( ) const

inline

Definition at line 230 of file temperatureCoupledBase.H.

References temperatureCoupledBase::alphaName_.

◆ autoMap()

void autoMap ( const fvPatchFieldMapper & mapper )

pure virtual

Implemented in contactHeatFluxSource, humidityTemperatureCoupledMixedFvPatchScalarField, externalWallHeatFluxTemperatureFvPatchScalarField, turbulentTemperatureRadCoupledMixedFvPatchScalarField, turbulentTemperatureCoupledBaffleMixedFvPatchScalarField, filmPyrolysisRadiativeCoupledMixedFvPatchScalarField, lumpedMassWallTemperatureFvPatchScalarField, and fixedIncidentRadiationFvPatchScalarField.

Definition at line 165 of file temperatureCoupledBase.C.

Referenced by fixedIncidentRadiationFvPatchScalarField::autoMap(), contactHeatFluxSource::autoMap(), filmPyrolysisRadiativeCoupledMixedFvPatchScalarField::autoMap(), turbulentTemperatureCoupledBaffleMixedFvPatchScalarField::autoMap(), turbulentTemperatureRadCoupledMixedFvPatchScalarField::autoMap(), and humidityTemperatureCoupledMixedFvPatchScalarField::autoMap().

Here is the caller graph for this function:

◆ rmap()

void rmap	(	const fvPatchField< scalar > &	ptf,
		const labelList &	addr
	)

pure virtual

Implemented in humidityTemperatureCoupledMixedFvPatchScalarField, externalWallHeatFluxTemperatureFvPatchScalarField, fixedIncidentRadiationFvPatchScalarField, contactHeatFluxSource, turbulentTemperatureRadCoupledMixedFvPatchScalarField, turbulentTemperatureCoupledBaffleMixedFvPatchScalarField, filmPyrolysisRadiativeCoupledMixedFvPatchScalarField, and lumpedMassWallTemperatureFvPatchScalarField.

Definition at line 181 of file temperatureCoupledBase.C.

Referenced by fixedIncidentRadiationFvPatchScalarField::rmap(), contactHeatFluxSource::rmap(), filmPyrolysisRadiativeCoupledMixedFvPatchScalarField::rmap(), turbulentTemperatureCoupledBaffleMixedFvPatchScalarField::rmap(), turbulentTemperatureRadCoupledMixedFvPatchScalarField::rmap(), and humidityTemperatureCoupledMixedFvPatchScalarField::rmap().

Here is the caller graph for this function:

◆ kappa()

Foam::tmp< Foam::scalarField > kappa ( const scalarField & Tp ) const

virtual

Reimplemented in turbulentTemperatureRadCoupledMixedFvPatchScalarField, and turbulentTemperatureCoupledBaffleMixedFvPatchScalarField.

Definition at line 203 of file temperatureCoupledBase.C.

References dictName(), Foam::exit(), Foam::FatalError, FatalErrorInFunction, Foam::flatOutput(), Foam::constant::electromagnetic::kappa, basicThermo::kappa(), mesh, n, and Foam::nl.

Referenced by turbulentTemperatureCoupledBaffleMixedFvPatchScalarField::kappa(), turbulentTemperatureRadCoupledMixedFvPatchScalarField::kappa(), lumpedMassWallTemperatureFvPatchScalarField::updateCoeffs(), filmPyrolysisRadiativeCoupledMixedFvPatchScalarField::updateCoeffs(), externalWallHeatFluxTemperatureFvPatchScalarField::updateCoeffs(), and humidityTemperatureCoupledMixedFvPatchScalarField::updateCoeffs().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ alpha()

Foam::tmp< Foam::scalarField > alpha ( const scalarField & Tp ) const

virtual

Definition at line 356 of file temperatureCoupledBase.C.

References basicThermo::alpha(), dictName(), Foam::exit(), Foam::FatalError, FatalErrorInFunction, Foam::flatOutput(), mesh, n, and Foam::nl.

Referenced by filmPyrolysisRadiativeCoupledMixedFvPatchScalarField::updateCoeffs(), and turbulentTemperatureRadCoupledMixedFvPatchScalarField::updateCoeffs().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ write()

void write ( Ostream & os ) const

Definition at line 505 of file temperatureCoupledBase.C.

References temperatureCoupledBase::alphaAniName_, temperatureCoupledBase::alphaFunction1_, temperatureCoupledBase::alphaName_, temperatureCoupledBase::kappaFunction1_, temperatureCoupledBase::kappaName_, temperatureCoupledBase::KMethodTypeNames_, temperatureCoupledBase::method_, and os().

Referenced by fixedIncidentRadiationFvPatchScalarField::write(), lumpedMassWallTemperatureFvPatchScalarField::write(), filmPyrolysisRadiativeCoupledMixedFvPatchScalarField::write(), turbulentTemperatureCoupledBaffleMixedFvPatchScalarField::write(), turbulentTemperatureRadCoupledMixedFvPatchScalarField::write(), externalWallHeatFluxTemperatureFvPatchScalarField::write(), and humidityTemperatureCoupledMixedFvPatchScalarField::write().

Here is the call graph for this function:

Here is the caller graph for this function:

Member Data Documentation

◆ KMethodTypeNames_

const Foam::Enum< Foam::temperatureCoupledBase::KMethodType > KMethodTypeNames_

staticprotected

Initial value:

{
    { KMethodType::mtFluidThermo, "fluidThermo" },
    { KMethodType::mtSolidThermo, "solidThermo" },
    { KMethodType::mtDirectionalSolidThermo, "directionalSolidThermo" },
    { KMethodType::mtLookup, "lookup" },
    { KMethodType::mtFunction, "function" }
}

Definition at line 152 of file temperatureCoupledBase.H.

Referenced by temperatureCoupledBase::KMethod(), and temperatureCoupledBase::write().

◆ patch_

const fvPatch& patch_

protected

Definition at line 155 of file temperatureCoupledBase.H.

◆ method_

const KMethodType method_

protected

Definition at line 158 of file temperatureCoupledBase.H.

Referenced by temperatureCoupledBase::KMethod(), and temperatureCoupledBase::write().

◆ kappaName_

const word kappaName_

protected

Definition at line 161 of file temperatureCoupledBase.H.

Referenced by temperatureCoupledBase::kappaName(), and temperatureCoupledBase::write().

◆ alphaAniName_

const word alphaAniName_

protected

Definition at line 164 of file temperatureCoupledBase.H.

Referenced by temperatureCoupledBase::write().

◆ alphaName_

const word alphaName_

protected

Definition at line 167 of file temperatureCoupledBase.H.

Referenced by temperatureCoupledBase::alphaName(), and temperatureCoupledBase::write().

◆ kappaFunction1_

autoPtr<PatchFunction1<scalar> > kappaFunction1_

protected

Definition at line 170 of file temperatureCoupledBase.H.

Referenced by temperatureCoupledBase::write().

◆ alphaFunction1_

autoPtr<PatchFunction1<scalar> > alphaFunction1_

protected

Definition at line 173 of file temperatureCoupledBase.H.

Referenced by temperatureCoupledBase::write().

The documentation for this class was generated from the following files:

src/TurbulenceModels/compressible/turbulentFluidThermoModels/derivedFvPatchFields/temperatureCoupledBase/temperatureCoupledBase.H
src/TurbulenceModels/compressible/turbulentFluidThermoModels/derivedFvPatchFields/temperatureCoupledBase/temperatureCoupledBase.C
