swirlInletVelocityFvPatchVectorField Class Reference

This boundary condition describes an inlet vector boundary condition in swirl coordinates given a central axis, central point, axial, radial and tangential velocity profiles. More...

Inheritance diagram for swirlInletVelocityFvPatchVectorField:

Collaboration diagram for swirlInletVelocityFvPatchVectorField:

Public Member Functions
	TypeName ("swirlInletVelocity")
	swirlInletVelocityFvPatchVectorField (const fvPatch &, const DimensionedField< vector, volMesh > &)
	swirlInletVelocityFvPatchVectorField (const fvPatch &, const DimensionedField< vector, volMesh > &, const dictionary &)
	swirlInletVelocityFvPatchVectorField (const swirlInletVelocityFvPatchVectorField &, const fvPatch &, const DimensionedField< vector, volMesh > &, const fvPatchFieldMapper &)
	swirlInletVelocityFvPatchVectorField (const swirlInletVelocityFvPatchVectorField &)
virtual tmp< fvPatchVectorField >	clone () const
	swirlInletVelocityFvPatchVectorField (const swirlInletVelocityFvPatchVectorField &, const DimensionedField< vector, volMesh > &)
virtual tmp< fvPatchVectorField >	clone (const DimensionedField< vector, volMesh > &iF) const
virtual void	updateCoeffs ()
virtual void	write (Ostream &) const

Detailed Description

This boundary condition describes an inlet vector boundary condition in swirl coordinates given a central axis, central point, axial, radial and tangential velocity profiles.

Usage

Property	Description	Required	Default value
axis	Axis of rotation	yes
origin	Origin of rotation	yes
axialVelocity	Axial velocity profile [m/s]	yes
radialVelocity	Radial velocity profile [m/s]	yes
tangentialVelocity	tangential velocity profile [m/s]	yes

Example of the boundary condition specification:

    <patchName>
    {
        type            swirlInletVelocity;
        axis            (0 0 1);
        origin          (0 0 0);
        axialVelocity   constant 30;
        radialVelocity  constant 10;
        tangentialVelocity  constant 100;
    }

Note

The axialVelocity, radialVelocity and tangentialVelocity entries are Function1 types, able to describe time varying functions. The example above gives the usage for supplying constant values.

See also

Foam::fixedValueFvPatchField Foam::Function1Types

Source files

• swirlInletVelocityFvPatchVectorField.H
• swirlInletVelocityFvPatchVectorField.C

Definition at line 113 of file swirlInletVelocityFvPatchVectorField.H.

Constructor & Destructor Documentation

swirlInletVelocityFvPatchVectorField() [1/5]

swirlInletVelocityFvPatchVectorField	(	const fvPatch &	p,
		const DimensionedField< vector, volMesh > &	iF
	)

Definition at line 29 of file swirlInletVelocityFvPatchVectorField.C.

Referenced by swirlInletVelocityFvPatchVectorField::clone().

Here is the caller graph for this function:

swirlInletVelocityFvPatchVectorField() [2/5]

swirlInletVelocityFvPatchVectorField	(	const fvPatch &	p,
		const DimensionedField< vector, volMesh > &	iF,
		const dictionary &	dict
	)

Definition at line 63 of file swirlInletVelocityFvPatchVectorField.C.

swirlInletVelocityFvPatchVectorField() [3/5]

swirlInletVelocityFvPatchVectorField	(	const swirlInletVelocityFvPatchVectorField &	ptf,
		const fvPatch &	p,
		const DimensionedField< vector, volMesh > &	iF,
		const fvPatchFieldMapper &	mapper
	)

Definition at line 45 of file swirlInletVelocityFvPatchVectorField.C.

swirlInletVelocityFvPatchVectorField() [4/5]

swirlInletVelocityFvPatchVectorField

(

const swirlInletVelocityFvPatchVectorField &

ptf

)

Definition at line 86 of file swirlInletVelocityFvPatchVectorField.C.

swirlInletVelocityFvPatchVectorField() [5/5]

swirlInletVelocityFvPatchVectorField	(	const swirlInletVelocityFvPatchVectorField &	ptf,
		const DimensionedField< vector, volMesh > &	iF
	)

Definition at line 101 of file swirlInletVelocityFvPatchVectorField.C.

Member Function Documentation

TypeName()

TypeName

(

"swirlInletVelocity"

)

clone() [1/2]

virtual tmp<fvPatchVectorField> clone ( ) const

inlinevirtual

Definition at line 176 of file swirlInletVelocityFvPatchVectorField.H.

References swirlInletVelocityFvPatchVectorField::swirlInletVelocityFvPatchVectorField().

Here is the call graph for this function:

clone() [2/2]

virtual tmp<fvPatchVectorField> clone ( const DimensionedField< vector, volMesh > &  iF ) const

inlinevirtual

Definition at line 193 of file swirlInletVelocityFvPatchVectorField.H.

References swirlInletVelocityFvPatchVectorField::swirlInletVelocityFvPatchVectorField().

Here is the call graph for this function:

updateCoeffs()

void updateCoeffs ( )

virtual

Definition at line 117 of file swirlInletVelocityFvPatchVectorField.C.

References Foam::mag(), Foam::foamVersion::patch, and fvPatchField< Type >::updateCoeffs().

Here is the call graph for this function:

write()

void write ( Ostream &  os ) const

virtual

Definition at line 147 of file swirlInletVelocityFvPatchVectorField.C.

References os(), fvPatchField::write(), and Ostream::writeEntry().

Here is the call graph for this function:

---

The documentation for this class was generated from the following files:

• src/finiteVolume/fields/fvPatchFields/derived/swirlInletVelocity/swirlInletVelocityFvPatchVectorField.H
• src/finiteVolume/fields/fvPatchFields/derived/swirlInletVelocity/swirlInletVelocityFvPatchVectorField.C
