Public Member Functions | List of all members
abaqusWriter Class Reference

A surface writer for the ABAQUS file format - both surface mesh and fields. More...

Inheritance diagram for abaqusWriter:
Inheritance graph
[legend]
Collaboration diagram for abaqusWriter:
Collaboration graph
[legend]

Public Member Functions

 TypeNameNoDebug ("abaqus")

 abaqusWriter ()

 abaqusWriter (const dictionary &options)

 abaqusWriter (const meshedSurf &surf, const fileName &outputPath, bool parallel=Pstream::parRun(), const dictionary &options=dictionary())

 abaqusWriter (const pointField &points, const faceList &faces, const fileName &outputPath, bool parallel=Pstream::parRun(), const dictionary &options=dictionary())

virtual ~abaqusWriter ()=default

virtual bool usesFaceIds () const

virtual fileName write ()

 declareSurfaceWriterWriteMethod (label)

 declareSurfaceWriterWriteMethod (scalar)

 declareSurfaceWriterWriteMethod (vector)

 declareSurfaceWriterWriteMethod (sphericalTensor)

 declareSurfaceWriterWriteMethod (symmTensor)

 declareSurfaceWriterWriteMethod (tensor)

template<class Type >
Foam::Ostream & writeFaceValue (Ostream &os, const Type &value, const label elemId) const

template<class Type >
Foam::fileName writeTemplate (const word &fieldName, const Field< Type > &localValues)

- Public Member Functions inherited from surfaceWriter
 TypeName ("surfaceWriter")

 declareRunTimeSelectionTable (autoPtr, surfaceWriter, word,(),())

 declareRunTimeSelectionTable (autoPtr, surfaceWriter, wordDict,(const dictionary &writeOpts),(writeOpts))

 surfaceWriter ()

 surfaceWriter (const dictionary &options)

 surfaceWriter (const meshedSurf &surf, bool parallel=Pstream::parRun(), const dictionary &options=dictionary())

 surfaceWriter (const pointField &points, const faceList &faces, bool parallel=Pstream::parRun(), const dictionary &options=dictionary())

virtual ~surfaceWriter ()

virtual bool enabled () const

virtual bool separateGeometry () const

virtual bool needsUpdate () const

virtual bool wroteData () const

virtual bool expire ()

virtual void clear ()

virtual void setSurface (const meshedSurf &surf, bool parallel)

virtual void setSurface (const pointField &points, const faceList &faces, bool parallel)

virtual void setSurface (const meshedSurf &surf)

virtual void setSurface (const pointField &points, const faceList &faces)

bool hasSurface () const

bool empty () const

label size () const

label nFields () const

label nFields (const label n)

bool isPointData () const

bool isPointData (const bool on)

bool useTimeDir () const

bool useTimeDir (const bool on)

bool verbose () const

bool verbose (const bool on)

scalar mergeDim () const

scalar mergeDim (const scalar dist)

bool hasTime () const

const word & timeName () const

scalar timeValue () const

void setTime (const instant &inst)

void setTime (scalar timeValue)

void setTime (scalar timeValue, const word &timeName)

void unsetTime ()

virtual void beginTime (const Time &t)

virtual void beginTime (const instant &inst)

virtual void endTime ()

virtual void open (const fileName &outputPath)

virtual void open (const pointField &points, const faceList &faces, const fileName &outputPath, bool parallel)

virtual void open (const meshedSurf &surf, const fileName &outputPath, bool parallel)

virtual void open (const pointField &points, const faceList &faces, const fileName &outputPath)

virtual void open (const meshedSurf &surf, const fileName &outputPath)

virtual void close ()

virtual fileName write (const word &fieldName, const Field< label > &values)=0
 Write field of label (per face or vertex) More...

virtual fileName write (const word &fieldName, const Field< scalar > &values)=0
 Write field of scalar (per face or vertex) More...

virtual fileName write (const word &fieldName, const Field< vector > &values)=0
 Write field of vector (per face or vertex) More...

virtual fileName write (const word &fieldName, const Field< sphericalTensor > &values)=0
 Write field of sphericalTensor (per face or vertex) More...

virtual fileName write (const word &fieldName, const Field< symmTensor > &values)=0
 Write field of symmTensor (per face or vertex) More...

virtual fileName write (const word &fieldName, const Field< tensor > &values)=0
 Write field of tensor (per face or vertex) More...

virtual InfoProxy< surfaceWriter > info () const

template<class Type >
Foam::tmp< Foam::Field< Type > > mergeFieldTemplate (const Field< Type > &fld) const


Additional Inherited Members

- Static Public Member Functions inherited from surfaceWriter
static bool supportedType (const word &writeType)

static autoPtr< surfaceWriter > New (const word &writeType)

static autoPtr< surfaceWriter > New (const word &writeType, const dictionary &writeOptions)

- Static Public Attributes inherited from surfaceWriter
static scalar defaultMergeDim = 1e-8

- Protected Member Functions inherited from surfaceWriter
bool checkOpen () const

virtual bool merge () const

const meshedSurf & surface () const

template<class Type >
tmp< Field< Type > > mergeFieldTemplate (const Field< Type > &fld) const

tmp< Field< label > > mergeField (const Field< label > &fld) const

tmp< Field< scalar > > mergeField (const Field< scalar > &fld) const

tmp< Field< vector > > mergeField (const Field< vector > &fld) const

tmp< Field< sphericalTensor > > mergeField (const Field< sphericalTensor > &fld) const

tmp< Field< symmTensor > > mergeField (const Field< symmTensor > &fld) const

tmp< Field< tensor > > mergeField (const Field< tensor > &fld) const

template<class Type >
fileName writeTemplate (const word &fieldName, const Field< Type > &localValues)

- Protected Attributes inherited from surfaceWriter
std::reference_wrapper< const meshedSurf > surf_

meshedSurfRef surfComp_

bool useComponents_

bool upToDate_

bool wroteGeom_

bool parallel_

bool useTimeDir_

bool isPointData_

bool verbose_

label nFields_

scalar mergeDim_

mergedSurf merged_

instant currTime_

fileName outputPath_

- Static Protected Attributes inherited from surfaceWriter
static const meshedSurf::emptySurface emptySurface_


Detailed Description

A surface writer for the ABAQUS file format - both surface mesh and fields.

The formatOptions for abaqus:

Property Description Required Default
scale output geometry scaling no 1
fieldScale output field scaling (dictionary) no empty
noGeometry Suppress geometry output (beta feature) no false

For example,

    formatOptions
    {
        abaqus
        {
            scale   1000;     // [m] -> [mm]
            fieldScale
            {
               "p.*"   0.01;  // [Pa] -> [mbar]
            }
        }
    }

file locations

The rootdir normally corresponds to something like postProcessing/<name>

Geometry

    rootdir
    `-- surfaceName0
        `-- geometry
            `-- surfaceName0_\<time\>.abq

Fields

    rootdir
    `-- surfaceName0
        `-- field0
        |   `-- surfaceName0_\<time\>.{inp}
        `-- field1
            `-- surfaceName0_\<time\>.{inp}
Note
Output variable scaling does not apply to integer types such as Ids.
Source files

Definition at line 119 of file abaqusSurfaceWriter.H.

Constructor & Destructor Documentation

◆ abaqusWriter() [1/4]

abaqusWriter ( )

Definition at line 230 of file abaqusSurfaceWriter.C.

◆ abaqusWriter() [2/4]

abaqusWriter ( const dictionary &  options)
explicit

Definition at line 241 of file abaqusSurfaceWriter.C.

◆ abaqusWriter() [3/4]

abaqusWriter ( const meshedSurf &  surf,
const fileName &  outputPath,
bool  parallel = Pstream::parRun(),
const dictionary &  options = dictionary()
)

Definition at line 254 of file abaqusSurfaceWriter.C.

◆ abaqusWriter() [4/4]

abaqusWriter ( const pointField &  points,
const faceList &  faces,
const fileName &  outputPath,
bool  parallel = Pstream::parRun(),
const dictionary &  options = dictionary()
)

Definition at line 268 of file abaqusSurfaceWriter.C.

References points.

◆ ~abaqusWriter()

virtual ~abaqusWriter ( )
virtualdefault

Member Function Documentation

◆ TypeNameNoDebug()

TypeNameNoDebug ( "abaqus"  )

◆ usesFaceIds()

virtual bool usesFaceIds ( ) const
inlinevirtual

Reimplemented from surfaceWriter.

Definition at line 228 of file abaqusSurfaceWriter.H.

◆ write()

Foam::fileName write ( )
virtual

Implements surfaceWriter.

Definition at line 284 of file abaqusSurfaceWriter.C.

References Foam::endl(), fileName::ext(), Foam::Info, Foam::isDir(), UPstream::master(), Foam::mkDir(), fileName::name(), os(), fileName::path(), timeName, and writeGeometry().

Here is the call graph for this function:

◆ declareSurfaceWriterWriteMethod() [1/6]

declareSurfaceWriterWriteMethod ( label  )

◆ declareSurfaceWriterWriteMethod() [2/6]

declareSurfaceWriterWriteMethod ( scalar  )

◆ declareSurfaceWriterWriteMethod() [3/6]

declareSurfaceWriterWriteMethod ( vector  )

◆ declareSurfaceWriterWriteMethod() [4/6]

declareSurfaceWriterWriteMethod ( sphericalTensor  )

◆ declareSurfaceWriterWriteMethod() [5/6]

declareSurfaceWriterWriteMethod ( symmTensor  )

◆ declareSurfaceWriterWriteMethod() [6/6]

declareSurfaceWriterWriteMethod ( tensor  )

◆ writeFaceValue()

Foam::Ostream& writeFaceValue ( Ostream &  os,
const Type &  value,
const label  elemId
) const

Definition at line 29 of file abaqusSurfaceWriterImpl.C.

References Foam::mag(), Foam::nl, and os().

Here is the call graph for this function:

◆ writeTemplate()

Foam::fileName writeTemplate ( const word &  fieldName,
const Field< Type > &  localValues
)

Definition at line 70 of file abaqusSurfaceWriterImpl.C.

References Foam::endl(), Foam::MatrixTools::equal(), fileName::ext(), f(), meshedSurf::faceIds(), meshedSurf::faces(), forAll, Foam::Info, Foam::isDir(), fileName::lessExt(), Foam::max(), Foam::mkDir(), Foam::nl, os(), fileName::path(), meshedSurf::points(), timeName, Foam::HashTableOps::values(), writeGeometry(), and Foam::Zero.

Here is the call graph for this function:
The documentation for this class was generated from the following files:
