surfaceInterpolationScheme< Type > Class Template Reference

Abstract base class for surface interpolation schemes. More...

Inheritance diagram for surfaceInterpolationScheme< Type >:

Collaboration diagram for surfaceInterpolationScheme< Type >:

Public Member Functions
	TypeName ("surfaceInterpolationScheme")
	declareRunTimeSelectionTable (tmp, surfaceInterpolationScheme, Mesh,(const fvMesh &mesh, Istream &schemeData),(mesh, schemeData))
	declareRunTimeSelectionTable (tmp, surfaceInterpolationScheme, MeshFlux,(const fvMesh &mesh, const surfaceScalarField &faceFlux, Istream &schemeData),(mesh, faceFlux, schemeData))
	surfaceInterpolationScheme (const fvMesh &mesh)
virtual	~surfaceInterpolationScheme ()=default
const fvMesh &	mesh () const
virtual tmp< surfaceScalarField >	weights (const GeometricField< Type, fvPatchField, volMesh > &) const =0
virtual bool	corrected () const
virtual tmp< GeometricField< Type, fvsPatchField, surfaceMesh > >	correction (const GeometricField< Type, fvPatchField, volMesh > &) const
virtual tmp< GeometricField< typename innerProduct< vector, Type >::type, fvsPatchField, surfaceMesh > >	dotInterpolate (const surfaceVectorField &Sf, const GeometricField< Type, fvPatchField, volMesh > &vf) const
tmp< GeometricField< typename innerProduct< vector, Type >::type, fvsPatchField, surfaceMesh > >	dotInterpolate (const surfaceVectorField &Sf, const tmp< GeometricField< Type, fvPatchField, volMesh >> &) const
virtual tmp< GeometricField< Type, fvsPatchField, surfaceMesh > >	interpolate (const GeometricField< Type, fvPatchField, volMesh > &) const
tmp< GeometricField< Type, fvsPatchField, surfaceMesh > >	interpolate (const tmp< GeometricField< Type, fvPatchField, volMesh >> &) const
Public Member Functions inherited from refCount
constexpr	refCount () noexcept
int	count () const noexcept
bool	unique () const noexcept
void	operator++ () noexcept
void	operator++ (int) noexcept
void	operator-- () noexcept
void	operator-- (int) noexcept

Static Public Member Functions
static tmp< surfaceInterpolationScheme< Type > >	New (const fvMesh &mesh, Istream &schemeData)
static tmp< surfaceInterpolationScheme< Type > >	New (const fvMesh &mesh, const surfaceScalarField &faceFlux, Istream &schemeData)
static tmp< GeometricField< Type, fvsPatchField, surfaceMesh > >	interpolate (const GeometricField< Type, fvPatchField, volMesh > &, const tmp< surfaceScalarField > &, const tmp< surfaceScalarField > &)
template<class SFType >
static tmp< GeometricField< typename innerProduct< typename SFType::value_type, Type >::type, fvsPatchField, surfaceMesh > >	dotInterpolate (const SFType &Sf, const GeometricField< Type, fvPatchField, volMesh > &vf, const tmp< surfaceScalarField > &tlambdas)
static tmp< GeometricField< Type, fvsPatchField, surfaceMesh > >	interpolate (const GeometricField< Type, fvPatchField, volMesh > &, const tmp< surfaceScalarField > &)

Detailed Description

template<class Type>
class Foam::surfaceInterpolationScheme< Type >

Abstract base class for surface interpolation schemes.

Source files

• surfaceInterpolationScheme.H
• surfaceInterpolationScheme.C

Definition at line 53 of file surfaceInterpolationScheme.H.

Constructor & Destructor Documentation

surfaceInterpolationScheme()

surfaceInterpolationScheme ( const fvMesh &  mesh )

inline

Definition at line 109 of file surfaceInterpolationScheme.H.

~surfaceInterpolationScheme()

virtual ~surfaceInterpolationScheme ( )

virtualdefault

Member Function Documentation

TypeName()

TypeName

(

"surfaceInterpolationScheme< Type >"

)

declareRunTimeSelectionTable() [1/2]

declareRunTimeSelectionTable	(	tmp	,
		surfaceInterpolationScheme< Type >	,
		Mesh	,
		(const fvMesh &mesh, Istream &schemeData)	,
		(mesh, schemeData)
	)

declareRunTimeSelectionTable() [2/2]

declareRunTimeSelectionTable	(	tmp	,
		surfaceInterpolationScheme< Type >	,
		MeshFlux	,
		(const fvMesh &mesh, const surfaceScalarField &faceFlux, Istream &schemeData)	,
		(mesh, faceFlux, schemeData)
	)

New() [1/2]

Foam::tmp< Foam::surfaceInterpolationScheme< Type > > New ( const fvMesh &  mesh, Istream &  schemeData  )

static

Definition at line 33 of file surfaceInterpolationScheme.C.

Referenced by gaussGrad< Type >::gaussGrad(), laplacianScheme< Type, GType >::laplacianScheme(), and multivariateIndependentScheme< Type >::operator()().

Here is the caller graph for this function:

New() [2/2]

Foam::tmp< Foam::surfaceInterpolationScheme< Type > > New ( const fvMesh &  mesh, const surfaceScalarField &  faceFlux, Istream &  schemeData  )

static

Definition at line 74 of file surfaceInterpolationScheme.C.

mesh()

const fvMesh& mesh ( ) const

inline

Definition at line 140 of file surfaceInterpolationScheme.H.

Referenced by localBlended< Type >::blendingFactor(), CoBlended< Type >::blendingFactor(), cellCoBlended< Type >::blendingFactor(), DEShybrid< Type >::blendingFactor(), skewCorrected< Type >::corrected(), cubic< Type >::correction(), CentredFitScheme< Type, Polynomial, Stencil >::correction(), PureUpwindFitScheme< Type, Polynomial, Stencil >::correction(), UpwindFitScheme< Type, Polynomial, Stencil >::correction(), skewCorrected< Type >::correction(), outletStabilised< Type >::correction(), localBlended< Type >::correction(), localMax< Type >::interpolate(), localMin< Type >::interpolate(), localBlended< Type >::interpolate(), upwind< Type >::limiter(), blended< Type >::limiter(), skewCorrected< Type >::skewCorrection(), midPoint< Type >::weights(), linear< Type >::weights(), reverseLinear< Type >::weights(), LUST< Type >::weights(), clippedLinear< Type >::weights(), outletStabilised< Type >::weights(), localBlended< Type >::weights(), weightedFlux< Type >::weights(), and blended< Type >::weights().

Here is the caller graph for this function:

interpolate() [1/4]

Foam::tmp< Foam::GeometricField< Type, Foam::fvsPatchField, Foam::surfaceMesh > > interpolate ( const GeometricField< Type, fvPatchField, volMesh > &  vf, const tmp< surfaceScalarField > &  tlambdas, const tmp< surfaceScalarField > &  tys  )

static

Definition at line 119 of file surfaceInterpolationScheme.C.

Referenced by cubic< Type >::correction(), harmonic::interpolate(), Foam::linearInterpolate(), and skewCorrected< Type >::skewCorrection().

Here is the caller graph for this function:

dotInterpolate() [1/3]

static tmp< GeometricField < typename innerProduct<typename SFType::value_type, Type>::type, fvsPatchField, surfaceMesh > > dotInterpolate ( const SFType &  Sf, const GeometricField< Type, fvPatchField, volMesh > &  vf, const tmp< surfaceScalarField > &  tlambdas  )

static

interpolate() [2/4]

Foam::tmp< Foam::GeometricField< Type, Foam::fvsPatchField, Foam::surfaceMesh > > interpolate ( const GeometricField< Type, fvPatchField, volMesh > &  vf, const tmp< surfaceScalarField > &  tlambdas  )

static

Definition at line 300 of file surfaceInterpolationScheme.C.

weights()

virtual tmp<surfaceScalarField> weights ( const GeometricField< Type, fvPatchField, volMesh > &  ) const

pure virtual

Implemented in DEShybrid< Type >, cellCoBlended< Type >, CoBlended< Type >, blended< Type >, fixedBlended< Type >, localBlended< Type >, limiterBlended< Type >, outletStabilised< Type >, limitWith< Type >, skewCorrected< Type >, multivariateSurfaceInterpolationScheme< Type >::fieldScheme, limitedSurfaceInterpolationScheme< Type >, weightedFlux< Type >, upwind< Type >, multivariateUpwind< Type >::fieldScheme, clippedLinear< Type >, multivariateSelectionScheme< Type >::fieldScheme, downwind< Type >, weighted< Type >, localMax< Type >, localMin< Type >, LUST< Type >, reverseLinear< Type >, linear< Type >, midPoint< Type >, and harmonic.

corrected()

virtual bool corrected ( ) const

inlinevirtual

Reimplemented in DEShybrid< Type >, cellCoBlended< Type >, CoBlended< Type >, fixedBlended< Type >, localBlended< Type >, outletStabilised< Type >, limiterBlended< Type >, linearUpwindNormal< Type >, limitWith< Type >, linearUpwindV< Type >, deferredCorrection< Type >, skewCorrected< Type >, linearUpwind< Type >, LUST< Type >, PureUpwindFitScheme< Type, Polynomial, Stencil >, UpwindFitScheme< Type, Polynomial, Stencil >, pointLinear< Type >, CentredFitScheme< Type, Polynomial, Stencil >, and cubic< Type >.

Definition at line 191 of file surfaceInterpolationScheme.H.

correction()

virtual tmp<GeometricField<Type, fvsPatchField, surfaceMesh> > correction ( const GeometricField< Type, fvPatchField, volMesh > &  ) const

inlinevirtual

Reimplemented in DEShybrid< Type >, cellCoBlended< Type >, CoBlended< Type >, fixedBlended< Type >, localBlended< Type >, outletStabilised< Type >, skewCorrected< Type >, limiterBlended< Type >, limitWith< Type >, LUST< Type >, PureUpwindFitScheme< Type, Polynomial, Stencil >, UpwindFitScheme< Type, Polynomial, Stencil >, pointLinear< Type >, CentredFitScheme< Type, Polynomial, Stencil >, cubic< Type >, linearUpwindNormal< Type >, linearUpwindV< Type >, deferredCorrection< Type >, and linearUpwind< Type >.

Definition at line 199 of file surfaceInterpolationScheme.H.

dotInterpolate() [2/3]

virtual tmp< GeometricField < typename innerProduct<vector, Type>::type, fvsPatchField, surfaceMesh > > dotInterpolate ( const surfaceVectorField &  Sf, const GeometricField< Type, fvPatchField, volMesh > &  vf  ) const

virtual

dotInterpolate() [3/3]

tmp< GeometricField < typename innerProduct<vector, Type>::type, fvsPatchField, surfaceMesh > > dotInterpolate	(	const surfaceVectorField &	Sf,
		const tmp< GeometricField< Type, fvPatchField, volMesh >> &
	)		const

interpolate() [3/4]

Foam::tmp< Foam::GeometricField< Type, Foam::fvsPatchField, Foam::surfaceMesh > > interpolate ( const GeometricField< Type, fvPatchField, volMesh > &  vf ) const

virtual

Reimplemented in DEShybrid< Type >, cellCoBlended< Type >, CoBlended< Type >, weightedFlux< Type >, fixedBlended< Type >, localBlended< Type >, limiterBlended< Type >, localMax< Type >, localMin< Type >, and harmonic.

Definition at line 390 of file surfaceInterpolationScheme.C.

interpolate() [4/4]

Foam::tmp< Foam::GeometricField< Type, Foam::fvsPatchField, Foam::surfaceMesh > > interpolate

(

const tmp< GeometricField< Type, fvPatchField, volMesh >> &

tvf

)

const

Definition at line 419 of file surfaceInterpolationScheme.C.

---

The documentation for this class was generated from the following files:

• src/finiteVolume/interpolation/surfaceInterpolation/surfaceInterpolationScheme/surfaceInterpolationScheme.H
• src/finiteVolume/interpolation/surfaceInterpolation/surfaceInterpolationScheme/surfaceInterpolationScheme.C
