supersonicFreestreamFvPatchVectorField Class Reference

This boundary condition provides a supersonic free-stream condition. More...

Inheritance diagram for supersonicFreestreamFvPatchVectorField:

Collaboration diagram for supersonicFreestreamFvPatchVectorField:

Public Member Functions
	TypeName ("supersonicFreestream")
	supersonicFreestreamFvPatchVectorField (const fvPatch &, const DimensionedField< vector, volMesh > &)
	supersonicFreestreamFvPatchVectorField (const fvPatch &, const DimensionedField< vector, volMesh > &, const dictionary &)
	supersonicFreestreamFvPatchVectorField (const supersonicFreestreamFvPatchVectorField &, const fvPatch &, const DimensionedField< vector, volMesh > &, const fvPatchFieldMapper &)
	supersonicFreestreamFvPatchVectorField (const supersonicFreestreamFvPatchVectorField &)
virtual tmp< fvPatchVectorField >	clone () const
	supersonicFreestreamFvPatchVectorField (const supersonicFreestreamFvPatchVectorField &, const DimensionedField< vector, volMesh > &)
virtual tmp< fvPatchVectorField >	clone (const DimensionedField< vector, volMesh > &iF) const
const vector &	UInf () const
vector &	UInf ()
scalar	pInf () const
scalar &	pInf ()
scalar	TInf () const
scalar &	TInf ()
virtual void	updateCoeffs ()
virtual void	write (Ostream &) const

Detailed Description

This boundary condition provides a supersonic free-stream condition.

• supersonic outflow is vented according to ???
• supersonic inflow is assumed to occur according to the Prandtl-Meyer expansion process.
• subsonic outflow is applied via a zero-gradient condition from inside the domain.

Usage

Property	Description	Required	Default value
T	Temperature field name	no	T
p	Pressure field name	no	p
psi	Compressibility field name	no	thermo:psi
UInf	free-stream velocity	yes
pInf	free-stream pressure	yes
TInf	free-stream temperature	yes
gamma	heat capacity ratio (cp/Cv)	yes

Example of the boundary condition specification:

    <patchName>
    {
        type            supersonicFreestream;
        UInf            500;
        pInf            1e4;
        TInf            265;
        gamma           1.4;
    }

Note

This boundary condition is ill-posed if the free-stream flow is normal to the boundary.

Source files

• supersonicFreestreamFvPatchVectorField.H
• supersonicFreestreamFvPatchVectorField.C

Definition at line 124 of file supersonicFreestreamFvPatchVectorField.H.

Constructor & Destructor Documentation

supersonicFreestreamFvPatchVectorField() [1/5]

supersonicFreestreamFvPatchVectorField	(	const fvPatch &	p,
		const DimensionedField< vector, volMesh > &	iF
	)

Definition at line 31 of file supersonicFreestreamFvPatchVectorField.C.

References Foam::Zero.

Referenced by supersonicFreestreamFvPatchVectorField::clone().

Here is the caller graph for this function:

supersonicFreestreamFvPatchVectorField() [2/5]

supersonicFreestreamFvPatchVectorField	(	const fvPatch &	p,
		const DimensionedField< vector, volMesh > &	iF,
		const dictionary &	dict
	)

Definition at line 53 of file supersonicFreestreamFvPatchVectorField.C.

References dict, Foam::exit(), Foam::FatalIOError, FatalIOErrorInFunction, p, Foam::foamVersion::patch, and Foam::Zero.

Here is the call graph for this function:

supersonicFreestreamFvPatchVectorField() [3/5]

supersonicFreestreamFvPatchVectorField	(	const supersonicFreestreamFvPatchVectorField &	ptf,
		const fvPatch &	p,
		const DimensionedField< vector, volMesh > &	iF,
		const fvPatchFieldMapper &	mapper
	)

Definition at line 100 of file supersonicFreestreamFvPatchVectorField.C.

supersonicFreestreamFvPatchVectorField() [4/5]

supersonicFreestreamFvPatchVectorField

(

const supersonicFreestreamFvPatchVectorField &

sfspvf

)

Definition at line 120 of file supersonicFreestreamFvPatchVectorField.C.

supersonicFreestreamFvPatchVectorField() [5/5]

supersonicFreestreamFvPatchVectorField	(	const supersonicFreestreamFvPatchVectorField &	sfspvf,
		const DimensionedField< vector, volMesh > &	iF
	)

Definition at line 137 of file supersonicFreestreamFvPatchVectorField.C.

Member Function Documentation

TypeName()

TypeName

(

"supersonicFreestream"

)

clone() [1/2]

virtual tmp<fvPatchVectorField> clone ( ) const

inlinevirtual

Definition at line 192 of file supersonicFreestreamFvPatchVectorField.H.

References supersonicFreestreamFvPatchVectorField::supersonicFreestreamFvPatchVectorField().

Here is the call graph for this function:

clone() [2/2]

virtual tmp<fvPatchVectorField> clone ( const DimensionedField< vector, volMesh > &  iF ) const

inlinevirtual

Definition at line 209 of file supersonicFreestreamFvPatchVectorField.H.

References supersonicFreestreamFvPatchVectorField::supersonicFreestreamFvPatchVectorField().

Here is the call graph for this function:

UInf() [1/2]

const vector& UInf ( ) const

inline

Definition at line 225 of file supersonicFreestreamFvPatchVectorField.H.

UInf() [2/2]

vector& UInf ( )

inline

Definition at line 231 of file supersonicFreestreamFvPatchVectorField.H.

pInf() [1/2]

scalar pInf ( ) const

inline

Definition at line 237 of file supersonicFreestreamFvPatchVectorField.H.

pInf() [2/2]

scalar& pInf ( )

inline

Definition at line 243 of file supersonicFreestreamFvPatchVectorField.H.

TInf() [1/2]

scalar TInf ( ) const

inline

Definition at line 249 of file supersonicFreestreamFvPatchVectorField.H.

TInf() [2/2]

scalar& TInf ( )

inline

Definition at line 256 of file supersonicFreestreamFvPatchVectorField.H.

updateCoeffs()

void updateCoeffs ( )

virtual

Definition at line 155 of file supersonicFreestreamFvPatchVectorField.C.

References Foam::atan(), Foam::exit(), Foam::FatalError, FatalErrorInFunction, forAll, Foam::log(), Foam::mag(), Foam::foamVersion::patch, Foam::pow(), R, Foam::sqr(), Foam::sqrt(), and U.

Here is the call graph for this function:

write()

void write ( Ostream &  os ) const

virtual

Definition at line 291 of file supersonicFreestreamFvPatchVectorField.C.

References os(), fvPatchField::write(), Ostream::writeEntry(), and Ostream::writeEntryIfDifferent().

Here is the call graph for this function:

---

The documentation for this class was generated from the following files:

• src/finiteVolume/fields/fvPatchFields/derived/supersonicFreestream/supersonicFreestreamFvPatchVectorField.H
• src/finiteVolume/fields/fvPatchFields/derived/supersonicFreestream/supersonicFreestreamFvPatchVectorField.C
