splineInterpolationWeights Class Reference

Catmull-Rom spline interpolation. More...

Inheritance diagram for splineInterpolationWeights:

Collaboration diagram for splineInterpolationWeights:

Public Member Functions
	TypeName ("spline")
	splineInterpolationWeights (const scalarField &samples, const bool checkEqualDistance=true)
virtual	~splineInterpolationWeights ()=default
virtual bool	valueWeights (const scalar t, labelList &indices, scalarField &weights) const
virtual bool	integrationWeights (const scalar t1, const scalar t2, labelList &indices, scalarField &weights) const
Public Member Functions inherited from interpolationWeights
	TypeName ("interpolationWeights")
	declareRunTimeSelectionTable (autoPtr, interpolationWeights, word,(const scalarField &samples),(samples))
	interpolationWeights (const scalarField &samples)
virtual	~interpolationWeights ()=default
template<class ListType1 , class ListType2 >
Foam::outerProduct< typename ListType1::value_type, typename ListType2::value_type >::type	weightedSum (const ListType1 &f1, const ListType2 &f2)

Additional Inherited Members
Static Public Member Functions inherited from interpolationWeights
static autoPtr< interpolationWeights >	New (const word &type, const scalarField &samples)
template<class ListType1 , class ListType2 >
static outerProduct< typename ListType1::value_type, typename ListType2::value_type >::type	weightedSum (const ListType1 &f1, const ListType2 &f2)
Protected Member Functions inherited from interpolationWeights
	interpolationWeights (const interpolationWeights &)=delete
void	operator= (const interpolationWeights &)=delete
Protected Attributes inherited from interpolationWeights
const scalarField &	samples_

Detailed Description

Catmull-Rom spline interpolation.

Source files

• splineInterpolationWeights.H
• splineInterpolationWeights.C

Definition at line 47 of file splineInterpolationWeights.H.

Constructor & Destructor Documentation

splineInterpolationWeights()

splineInterpolationWeights ( const scalarField &  samples, const bool  checkEqualDistance = true  )

explicit

Definition at line 44 of file splineInterpolationWeights.C.

References Foam::endl(), Foam::mag(), Foam::nl, samples(), and WarningInFunction.

Here is the call graph for this function:

~splineInterpolationWeights()

virtual ~splineInterpolationWeights ( )

virtualdefault

Member Function Documentation

TypeName()

TypeName

(

"spline"

)

valueWeights()

bool valueWeights ( const scalar  t, labelList &  indices, scalarField &  weights  ) const

virtual

Implements interpolationWeights.

Definition at line 76 of file splineInterpolationWeights.C.

References Foam::findLower(), Foam::constant::physicoChemical::mu, List::setSize(), linearInterpolationWeights::valueWeights(), w0, w1, w2, and w3.

Here is the call graph for this function:

integrationWeights()

virtual bool integrationWeights ( const scalar  t1, const scalar  t2, labelList &  indices, scalarField &  weights  ) const

inlinevirtual

Implements interpolationWeights.

Definition at line 93 of file splineInterpolationWeights.H.

References NotImplemented.

---

The documentation for this class was generated from the following files:

• src/OpenFOAM/interpolations/interpolationWeights/splineInterpolationWeights/splineInterpolationWeights.H
• src/OpenFOAM/interpolations/interpolationWeights/splineInterpolationWeights/splineInterpolationWeights.C
