smoothSolver Class Reference

Iterative solver for symmetric and asymmetric matrices which uses a run-time selected smoother e.g. GaussSeidel to converge the solution to the required tolerance. More...

Inheritance diagram for smoothSolver:

Collaboration diagram for smoothSolver:

Public Member Functions
	TypeName ("smoothSolver")
	smoothSolver (const word &fieldName, const lduMatrix &matrix, const FieldField< Field, scalar > &interfaceBouCoeffs, const FieldField< Field, scalar > &interfaceIntCoeffs, const lduInterfaceFieldPtrsList &interfaces, const dictionary &solverControls)
virtual	~smoothSolver ()=default
virtual solverPerformance	solve (scalarField &psi, const scalarField &source, const direction cmpt=0) const
Public Member Functions inherited from lduMatrix::solver
virtual const word &	type () const =0
	declareRunTimeSelectionTable (autoPtr, solver, symMatrix,(const word &fieldName, const lduMatrix &matrix, const FieldField< Field, scalar > &interfaceBouCoeffs, const FieldField< Field, scalar > &interfaceIntCoeffs, const lduInterfaceFieldPtrsList &interfaces, const dictionary &solverControls),(fieldName, matrix, interfaceBouCoeffs, interfaceIntCoeffs, interfaces, solverControls))
	declareRunTimeSelectionTable (autoPtr, solver, asymMatrix,(const word &fieldName, const lduMatrix &matrix, const FieldField< Field, scalar > &interfaceBouCoeffs, const FieldField< Field, scalar > &interfaceIntCoeffs, const lduInterfaceFieldPtrsList &interfaces, const dictionary &solverControls),(fieldName, matrix, interfaceBouCoeffs, interfaceIntCoeffs, interfaces, solverControls))
	solver (const word &fieldName, const lduMatrix &matrix, const FieldField< Field, scalar > &interfaceBouCoeffs, const FieldField< Field, scalar > &interfaceIntCoeffs, const lduInterfaceFieldPtrsList &interfaces, const dictionary &solverControls)
virtual	~solver ()=default
const word &	fieldName () const noexcept
const lduMatrix &	matrix () const noexcept
const FieldField< Field, scalar > &	interfaceBouCoeffs () const noexcept
const FieldField< Field, scalar > &	interfaceIntCoeffs () const noexcept
const lduInterfaceFieldPtrsList &	interfaces () const noexcept
virtual void	read (const dictionary &)
virtual solverPerformance	scalarSolve (solveScalarField &psi, const solveScalarField &source, const direction cmpt=0) const
solveScalarField::cmptType	normFactor (const solveScalarField &psi, const solveScalarField &source, const solveScalarField &Apsi, solveScalarField &tmpField) const

Protected Member Functions
virtual void	readControls ()

Protected Attributes
label	nSweeps_
Protected Attributes inherited from lduMatrix::solver
word	fieldName_
const lduMatrix &	matrix_
const FieldField< Field, scalar > &	interfaceBouCoeffs_
const FieldField< Field, scalar > &	interfaceIntCoeffs_
lduInterfaceFieldPtrsList	interfaces_
dictionary	controlDict_
int	log_
label	minIter_
label	maxIter_
scalar	tolerance_
scalar	relTol_
profilingTrigger	profiling_

Additional Inherited Members
Static Public Member Functions inherited from lduMatrix::solver
static autoPtr< solver >	New (const word &fieldName, const lduMatrix &matrix, const FieldField< Field, scalar > &interfaceBouCoeffs, const FieldField< Field, scalar > &interfaceIntCoeffs, const lduInterfaceFieldPtrsList &interfaces, const dictionary &solverControls)
Static Protected Attributes inherited from lduMatrix::solver
static const label	defaultMaxIter_ = 1000

Detailed Description

Iterative solver for symmetric and asymmetric matrices which uses a run-time selected smoother e.g. GaussSeidel to converge the solution to the required tolerance.

To improve efficiency, the residual is evaluated after every nSweeps smoothing iterations.

Source files

• smoothSolver.H
• smoothSolver.C

Definition at line 55 of file smoothSolver.H.

Constructor & Destructor Documentation

smoothSolver()

smoothSolver	(	const word &	fieldName,
		const lduMatrix &	matrix,
		const FieldField< Field, scalar > &	interfaceBouCoeffs,
		const FieldField< Field, scalar > &	interfaceIntCoeffs,
		const lduInterfaceFieldPtrsList &	interfaces,
		const dictionary &	solverControls
	)

Definition at line 43 of file smoothSolver.C.

~smoothSolver()

virtual ~smoothSolver ( )

virtualdefault

Member Function Documentation

readControls()

void readControls ( )

protectedvirtual

Reimplemented from lduMatrix::solver.

Definition at line 68 of file smoothSolver.C.

References lduMatrix::solver::controlDict_, dictionary::getOrDefault(), smoothSolver::nSweeps_, and lduMatrix::solver::readControls().

Here is the call graph for this function:

TypeName()

TypeName

(

"smoothSolver"

)

solve()

Foam::solverPerformance solve ( scalarField &  psi, const scalarField &  source, const direction  cmpt = 0  ) const

virtual

Implements lduMatrix::solver.

Definition at line 76 of file smoothSolver.C.

References addProfiling, SolverPerformance::checkConvergence(), Foam::expressions::patchExpr::debug, Foam::endl(), SolverPerformance::finalResidual(), Foam::gSumMag(), Foam::Info, SolverPerformance::initialResidual(), messageStream::masterStream(), mesh, lduMatrix::smoother::New(), SolverPerformance::nIterations(), psi, refPtr< Field< Type > >::ref(), lduMatrix::setResidualField(), and Foam::solve().

Here is the call graph for this function:

Member Data Documentation

nSweeps_

label nSweeps_

protected

Definition at line 64 of file smoothSolver.H.

Referenced by smoothSolver::readControls().

---

The documentation for this class was generated from the following files:

• src/OpenFOAM/matrices/lduMatrix/solvers/smoothSolver/smoothSolver.H
• src/OpenFOAM/matrices/lduMatrix/solvers/smoothSolver/smoothSolver.C
