slidingInterface Class Reference

Sliding interface mesh modifier. Given two face zones, couple the master and slave side using a cutting procedure. More...

Inheritance diagram for slidingInterface:

Collaboration diagram for slidingInterface:

Public Types
enum	typeOfMatch { INTEGRAL, PARTIAL }

Public Member Functions
	TypeName ("slidingInterface")
	slidingInterface (const word &name, const label index, const polyTopoChanger &mme, const word &masterFaceZoneName, const word &slaveFaceZoneName, const word &cutPointZoneName, const word &cutFaceZoneName, const word &masterPatchName, const word &slavePatchName, const typeOfMatch tom, const bool coupleDecouple=false, const intersection::algorithm algo=intersection::VISIBLE)
	slidingInterface (const word &name, const dictionary &dict, const label index, const polyTopoChanger &mme)
virtual	~slidingInterface ()=default
const faceZoneID &	masterFaceZoneID () const
const faceZoneID &	slaveFaceZoneID () const
bool	attached () const
virtual bool	changeTopology () const
virtual void	setRefinement (polyTopoChange &) const
virtual void	modifyMotionPoints (pointField &motionPoints) const
virtual void	updateMesh (const mapPolyMesh &)
const pointField &	pointProjection () const
void	setTolerances (const dictionary &, bool report=false)
virtual void	write (Ostream &) const
virtual void	writeDict (Ostream &) const
Public Member Functions inherited from polyMeshModifier
	TypeName ("meshModifier")
	declareRunTimeSelectionTable (autoPtr, polyMeshModifier, dictionary,(const word &name, const dictionary &dict, const label index, const polyTopoChanger &mme),(name, dict, index, mme))
	polyMeshModifier (const word &name, const label index, const polyTopoChanger &mme, const bool act)
virtual	~polyMeshModifier ()=default
const word &	name () const
label	index () const
const polyTopoChanger &	topoChanger () const
Switch	active () const
void	enable () const
void	disable () const

Static Public Attributes
static const Enum< typeOfMatch >	typeOfMatchNames

Additional Inherited Members
Static Public Member Functions inherited from polyMeshModifier
static autoPtr< polyMeshModifier >	New (const word &name, const dictionary &dict, const label index, const polyTopoChanger &mme)

Detailed Description

Sliding interface mesh modifier. Given two face zones, couple the master and slave side using a cutting procedure.

The coupled faces are collected into the "coupled" zone and can become either internal or placed into a master and slave coupled zone. The remaining faces (uncovered master or slave) are placed into the master and slave patch.

The definition of the sliding interface can be either integral or partial. Integral interface implies that the slave side completely covers the master (i.e. no faces are uncovered); partial interface implies that the uncovered part of master/slave face zone should become boundary faces.

Source files

• slidingInterface.H
• slidingInterface.C
• coupleSlidingInterface.C
• decoupleSlidingInterface.C
• slidingInterfaceProjectPoints.C
• slidingInterfaceAttachedAddressing.C
• slidingInterfaceClearCouple.C

Definition at line 70 of file slidingInterface.H.

Member Enumeration Documentation

typeOfMatch

enum typeOfMatch

Enumerator
INTEGRAL
PARTIAL

Definition at line 79 of file slidingInterface.H.

Constructor & Destructor Documentation

slidingInterface() [1/2]

slidingInterface	(	const word &	name,
		const label	index,
		const polyTopoChanger &	mme,
		const word &	masterFaceZoneName,
		const word &	slaveFaceZoneName,
		const word &	cutPointZoneName,
		const word &	cutFaceZoneName,
		const word &	masterPatchName,
		const word &	slavePatchName,
		const typeOfMatch	tom,
		const bool	coupleDecouple = false,
		const intersection::algorithm	algo = intersection::VISIBLE
	)

Definition at line 112 of file slidingInterface.C.

References Foam::abort(), Foam::FatalError, and FatalErrorInFunction.

Here is the call graph for this function:

slidingInterface() [2/2]

slidingInterface	(	const word &	name,
		const dictionary &	dict,
		const label	index,
		const polyTopoChanger &	mme
	)

Definition at line 202 of file slidingInterface.C.

References Foam::expressions::patchExpr::debug, dict, Foam::endl(), Foam::name(), Foam::Pout, and dictionary::readEntry().

Here is the call graph for this function:

~slidingInterface()

virtual ~slidingInterface ( )

virtualdefault

Member Function Documentation

TypeName()

TypeName

(

"slidingInterface"

)

masterFaceZoneID()

const Foam::faceZoneID & masterFaceZoneID

(

)

const

Definition at line 310 of file slidingInterface.C.

slaveFaceZoneID()

const Foam::faceZoneID & slaveFaceZoneID

(

)

const

Definition at line 316 of file slidingInterface.C.

attached()

bool attached ( ) const

inline

Definition at line 352 of file slidingInterface.H.

changeTopology()

bool changeTopology ( ) const

virtual

Implements polyMeshModifier.

Definition at line 322 of file slidingInterface.C.

References Foam::expressions::patchExpr::debug, Foam::endl(), mesh, Foam::name(), and Foam::Pout.

Here is the call graph for this function:

setRefinement()

void setRefinement ( polyTopoChange &  ref ) const

virtual

Implements polyMeshModifier.

Definition at line 363 of file slidingInterface.C.

References ref().

Here is the call graph for this function:

modifyMotionPoints()

void modifyMotionPoints ( pointField &  motionPoints ) const

virtual

Implements polyMeshModifier.

Definition at line 396 of file slidingInterface.C.

References Foam::abort(), Foam::constant::physicoChemical::b, Foam::constant::universal::c, Foam::expressions::patchExpr::debug, PointHit< PointType >::distance(), PrimitivePatch< FaceList, PointField >::edges(), edge::end(), Foam::endl(), polyMesh::faceZones(), Foam::FatalError, FatalErrorInFunction, PointHit< PointType >::hit(), PointHit< PointType >::hitPoint(), edge::line(), plane::lineIntersect(), PrimitivePatch< FaceList, PointField >::localPoints(), line::mag(), Foam::mag(), mesh, PointHit< PointType >::missPoint(), Foam::name(), line::nearestDist(), PrimitivePatch< FaceList, PointField >::pointNormals(), polyMesh::pointZones(), Foam::Pout, edge::second(), Foam::sqr(), line::start(), edge::start(), line::vec(), edge::vec(), PrimitivePatch< FaceList, PointField >::whichEdge(), and PrimitivePatch< FaceList, PointField >::whichPoint().

Here is the call graph for this function:

updateMesh()

void updateMesh ( const mapPolyMesh &  m )

virtual

Implements polyMeshModifier.

Definition at line 627 of file slidingInterface.C.

References polyMesh::boundaryMesh(), Foam::expressions::patchExpr::debug, Foam::endl(), polyMesh::faceZones(), mesh, Foam::name(), polyMesh::pointZones(), Foam::Pout, and dynamicFvMesh::update().

Here is the call graph for this function:

pointProjection()

const Foam::pointField & pointProjection

(

)

const

Definition at line 659 of file slidingInterface.C.

setTolerances()

void setTolerances	(	const dictionary &	dict,
		bool	report = false
	)

Definition at line 670 of file slidingInterface.C.

References dict, Foam::endl(), dictionary::getOrDefault(), Foam::Info, and Foam::nl.

Here is the call graph for this function:

write()

void write ( Ostream &  os ) const

virtual

Implements polyMeshModifier.

Definition at line 728 of file slidingInterface.C.

References Foam::endl(), Foam::name(), Foam::nl, os(), and Foam::type().

Here is the call graph for this function:

writeDict()

void writeDict ( Ostream &  os ) const

virtual

Implements polyMeshModifier.

Definition at line 752 of file slidingInterface.C.

References intersection::algorithmNames_, Ostream::beginBlock(), Ostream::endBlock(), Foam::name(), Foam::nl, os(), Foam::type(), WRITE_NON_DEFAULT, and Ostream::writeEntry().

Here is the call graph for this function:

Member Data Documentation

typeOfMatchNames

const Foam::Enum< Foam::slidingInterface::typeOfMatch > typeOfMatchNames

static

Definition at line 86 of file slidingInterface.H.

---

The documentation for this class was generated from the following files:

• src/dynamicMesh/slidingInterface/slidingInterface.H
• src/dynamicMesh/slidingInterface/coupleSlidingInterface.C
• src/dynamicMesh/slidingInterface/decoupleSlidingInterface.C
• src/dynamicMesh/slidingInterface/slidingInterface.C
• src/dynamicMesh/slidingInterface/slidingInterfaceAttachedAddressing.C
• src/dynamicMesh/slidingInterface/slidingInterfaceClearCouple.C
• src/dynamicMesh/slidingInterface/slidingInterfaceProjectPoints.C
