Newmark 2nd-order time-integrator for 6DoF solid-body motion. More...

Inheritance diagram for Newmark:

Collaboration diagram for Newmark:

Public Member Functions
	TypeName ("Newmark")

	Newmark (const dictionary &dict, sixDoFRigidBodyMotion &body)

virtual autoPtr< sixDoFSolver >	clone () const

virtual	~Newmark ()

virtual void	solve (bool firstIter, const vector &fGlobal, const vector &tauGlobal, scalar deltaT, scalar deltaT0)

Public Member Functions inherited from sixDoFSolver
	TypeName ("sixDoFSolver")

	declareRunTimeSelectionTable (autoPtr, sixDoFSolver, dictionary,(const dictionary &dict, sixDoFRigidBodyMotion &body),(dict, body))

	sixDoFSolver (const dictionary &dict, sixDoFRigidBodyMotion &body)

virtual	~sixDoFSolver ()

void	write (Ostream &) const

Additional Inherited Members
Static Public Member Functions inherited from sixDoFSolver
static autoPtr< sixDoFSolver >	New (const dictionary &dict, sixDoFRigidBodyMotion &body)

Protected Member Functions inherited from sixDoFSolver
point &	centreOfRotation ()

tensor &	Q ()

vector &	v ()

vector &	a ()

vector &	pi ()

vector &	tau ()

const point &	centreOfRotation0 () const

const tensor &	Q0 () const

const vector &	v0 () const

const vector &	a0 () const

const vector &	pi0 () const

const vector &	tau0 () const

scalar	aDamp () const

tensor	tConstraints () const

tensor	rConstraints () const

Tuple2< tensor, vector >	rotate (const tensor &Q0, const vector &pi, const scalar deltaT) const

void	updateAcceleration (const vector &fGlobal, const vector &tauGlobal)

Protected Attributes inherited from sixDoFSolver
sixDoFRigidBodyMotion &	body_

dictionary	dict_

Detailed Description

Newmark 2nd-order time-integrator for 6DoF solid-body motion.

Reference:

    Newmark, N. M. (1959).
    A method of computation for structural dynamics.
    Journal of the Engineering Mechanics Division, 85(3), 67-94.

Example specification in dynamicMeshDict:

solver
{
    type    Newmark;
    gamma   0.5;    // Velocity integration coefficient
    beta    0.25;   // Position integration coefficient
}

Source files

Definition at line 68 of file Newmark.H.

Constructor & Destructor Documentation

Definition at line 40 of file Newmark.C.

~Newmark ( )

virtual

Definition at line 60 of file Newmark.C.

TypeName ( "Newmark" )

virtual autoPtr<sixDoFSolver> clone ( ) const

inlinevirtual

Definition at line 97 of file Newmark.H.

virtual

Definition at line 67 of file Newmark.C.

Here is the call graph for this function:

The documentation for this class was generated from the following files:
