sixDoFRigidBodyMotionConstraint Class Reference

Base class for defining constraints for sixDoF motions. More...

Inheritance diagram for sixDoFRigidBodyMotionConstraint:

Collaboration diagram for sixDoFRigidBodyMotionConstraint:

Public Member Functions
	TypeName ("sixDoFRigidBodyMotionConstraint")
	declareRunTimeSelectionTable (autoPtr, sixDoFRigidBodyMotionConstraint, dictionary,(const word &name, const dictionary &sDoFRBMCDict, const sixDoFRigidBodyMotion &motion),(name, sDoFRBMCDict, motion))
	sixDoFRigidBodyMotionConstraint (const word &name, const dictionary &sDoFRBMCDict, const sixDoFRigidBodyMotion &motion)
virtual autoPtr< sixDoFRigidBodyMotionConstraint >	clone () const =0
virtual	~sixDoFRigidBodyMotionConstraint ()
const word &	name () const
virtual void	setCentreOfRotation (point &) const
virtual void	constrainTranslation (pointConstraint &) const =0
virtual void	constrainRotation (pointConstraint &) const =0
virtual bool	read (const dictionary &sDoFRBMCDict)
const dictionary &	coeffDict () const
virtual void	write (Ostream &) const

Static Public Member Functions
static autoPtr< sixDoFRigidBodyMotionConstraint >	New (const word &name, const dictionary &sDoFRBMCDict, const sixDoFRigidBodyMotion &motion)

Protected Attributes
word	name_
dictionary	sDoFRBMCCoeffs_
const sixDoFRigidBodyMotion &	motion_

Detailed Description

Base class for defining constraints for sixDoF motions.

Source files

• sixDoFRigidBodyMotionConstraint.H
• sixDoFRigidBodyMotionConstraint.C
• sixDoFRigidBodyMotionConstraintNew.C

Definition at line 64 of file sixDoFRigidBodyMotionConstraint.H.

Constructor & Destructor Documentation

sixDoFRigidBodyMotionConstraint()

sixDoFRigidBodyMotionConstraint	(	const word &	name,
		const dictionary &	sDoFRBMCDict,
		const sixDoFRigidBodyMotion &	motion
	)

Definition at line 35 of file sixDoFRigidBodyMotionConstraint.C.

~sixDoFRigidBodyMotionConstraint()

~sixDoFRigidBodyMotionConstraint ( )

virtual

Definition at line 49 of file sixDoFRigidBodyMotionConstraint.C.

Member Function Documentation

TypeName()

TypeName

(

"sixDoFRigidBodyMotionConstraint"

)

declareRunTimeSelectionTable()

declareRunTimeSelectionTable	(	autoPtr	,
		sixDoFRigidBodyMotionConstraint	,
		dictionary	,
		(const word &name, const dictionary &sDoFRBMCDict, const sixDoFRigidBodyMotion &motion)	,
		(name, sDoFRBMCDict, motion)
	)

clone()

virtual autoPtr<sixDoFRigidBodyMotionConstraint> clone ( ) const

pure virtual

Implemented in line, plane, point, axis, and orientation.

New()

Foam::autoPtr< Foam::sixDoFRigidBodyMotionConstraint > New ( const word &  name, const dictionary &  sDoFRBMCDict, const sixDoFRigidBodyMotion &  motion  )

static

Definition at line 28 of file sixDoFRigidBodyMotionConstraintNew.C.

References dict, Foam::exit(), Foam::FatalIOError, FatalIOErrorInLookup, and Foam::name().

Referenced by sixDoFRigidBodyMotion::addConstraints().

Here is the call graph for this function:

Here is the caller graph for this function:

name()

const word& name ( ) const

inline

Definition at line 135 of file sixDoFRigidBodyMotionConstraint.H.

References sixDoFRigidBodyMotionConstraint::name_.

setCentreOfRotation()

virtual void setCentreOfRotation ( point &  ) const

inlinevirtual

Reimplemented in point.

Definition at line 141 of file sixDoFRigidBodyMotionConstraint.H.

constrainTranslation()

virtual void constrainTranslation ( pointConstraint &  ) const

pure virtual

Implemented in line, plane, point, axis, and orientation.

constrainRotation()

virtual void constrainRotation ( pointConstraint &  ) const

pure virtual

Implemented in line, plane, point, axis, and orientation.

read()

bool read ( const dictionary &  sDoFRBMCDict )

virtual

Reimplemented in line, plane, point, axis, and orientation.

Definition at line 56 of file sixDoFRigidBodyMotionConstraint.C.

Referenced by orientation::read(), axis::read(), point::read(), line::read(), and plane::read().

Here is the caller graph for this function:

coeffDict()

const dictionary& coeffDict ( ) const

inline

Definition at line 156 of file sixDoFRigidBodyMotionConstraint.H.

References sixDoFRigidBodyMotionConstraint::sDoFRBMCCoeffs_.

write()

void write ( Ostream &  os ) const

virtual

Reimplemented in line, plane, point, axis, and orientation.

Definition at line 66 of file sixDoFRigidBodyMotionConstraint.C.

Member Data Documentation

name_

word name_

protected

Definition at line 72 of file sixDoFRigidBodyMotionConstraint.H.

Referenced by sixDoFRigidBodyMotionConstraint::name().

sDoFRBMCCoeffs_

dictionary sDoFRBMCCoeffs_

protected

Definition at line 75 of file sixDoFRigidBodyMotionConstraint.H.

Referenced by sixDoFRigidBodyMotionConstraint::coeffDict().

motion_

const sixDoFRigidBodyMotion& motion_

protected

Definition at line 78 of file sixDoFRigidBodyMotionConstraint.H.

---

The documentation for this class was generated from the following files:

• src/sixDoFRigidBodyMotion/sixDoFRigidBodyMotion/constraints/sixDoFRigidBodyMotionConstraint/sixDoFRigidBodyMotionConstraint.H
• src/sixDoFRigidBodyMotion/sixDoFRigidBodyMotion/constraints/sixDoFRigidBodyMotionConstraint/sixDoFRigidBodyMotionConstraint.C
• src/sixDoFRigidBodyMotion/sixDoFRigidBodyMotion/constraints/sixDoFRigidBodyMotionConstraint/sixDoFRigidBodyMotionConstraintNew.C
