columnFvMeshInfo Class Reference

Inheritance diagram for columnFvMeshInfo:

Collaboration diagram for columnFvMeshInfo:

Public Member Functions
	ClassName ("columnFvMeshInfo")
	columnFvMeshInfo (const Time &runTime, const word &regionName)

Protected Member Functions
void	addLocalPatches (fvMesh &mesh) const
void	initialiseZones (fvMesh &mesh)

Protected Attributes
const word	regionName_
const fileName	regionPrefix_
const word	localInstance_
bool	createFromMesh_
pointField	points1D_
faceList	faces1D_
labelList	owner1D_
labelList	neighbour1D_
dictionary	patchEntries_
label	nPatchWithFace_

Detailed Description

Definition at line 49 of file columnFvMesh.H.

Constructor & Destructor Documentation

columnFvMeshInfo()

columnFvMeshInfo	(	const Time &	runTime,
		const word &	regionName
	)

Definition at line 399 of file columnFvMesh.C.

References topoSet::disallowGenericSets, ZoneMesh< cellZone, polyMesh >::disallowGenericZones, and runTime.

Member Function Documentation

addLocalPatches()

void addLocalPatches ( fvMesh &  mesh ) const

protected

Definition at line 318 of file columnFvMesh.C.

References Foam::expressions::patchExpr::debug, DebugPout, Foam::constant::electromagnetic::e, Foam::endl(), dictionary::get(), mesh, polyPatch::New(), Foam::nl, patches, Foam::Pout, and dictionary::set().

Here is the call graph for this function:

initialiseZones()

void initialiseZones ( fvMesh &  mesh )

protected

Definition at line 379 of file columnFvMesh.C.

References mesh.

ClassName()

ClassName

(

"columnFvMeshInfo"

)

Member Data Documentation

regionName_

const word regionName_

protected

Definition at line 74 of file columnFvMesh.H.

regionPrefix_

const fileName regionPrefix_

protected

Definition at line 77 of file columnFvMesh.H.

localInstance_

const word localInstance_

protected

Definition at line 80 of file columnFvMesh.H.

createFromMesh_

bool createFromMesh_

protected

Definition at line 83 of file columnFvMesh.H.

points1D_

pointField points1D_

protected

Definition at line 89 of file columnFvMesh.H.

faces1D_

faceList faces1D_

protected

Definition at line 92 of file columnFvMesh.H.

owner1D_

labelList owner1D_

protected

Definition at line 95 of file columnFvMesh.H.

neighbour1D_

labelList neighbour1D_

protected

Definition at line 98 of file columnFvMesh.H.

patchEntries_

dictionary patchEntries_

protected

Definition at line 104 of file columnFvMesh.H.

nPatchWithFace_

label nPatchWithFace_

protected

Definition at line 107 of file columnFvMesh.H.

---

The documentation for this class was generated from the following files:

• src/finiteVolume/fvMesh/simplifiedFvMesh/columnFvMesh/columnFvMesh.H
• src/finiteVolume/fvMesh/simplifiedFvMesh/columnFvMesh/columnFvMesh.C
• src/finiteVolume/fvMesh/simplifiedFvMesh/columnFvMesh/columnFvMeshTemplates.C
