setUpdater Class Reference

Keeps cell/face/vertex sets uptodate. Both the ones loaded and the ones on disk. More...

Inheritance diagram for setUpdater:

Collaboration diagram for setUpdater:

Public Member Functions
	TypeName ("setUpdater")
	setUpdater (const word &name, const dictionary &dict, const label index, const polyTopoChanger &mme)
virtual	~setUpdater ()=default
virtual bool	changeTopology () const
virtual void	setRefinement (polyTopoChange &) const
virtual void	modifyMotionPoints (pointField &motionPoints) const
virtual void	updateMesh (const mapPolyMesh &)
virtual void	write (Ostream &) const
virtual void	writeDict (Ostream &) const
Public Member Functions inherited from polyMeshModifier
	TypeName ("meshModifier")
	declareRunTimeSelectionTable (autoPtr, polyMeshModifier, dictionary,(const word &name, const dictionary &dict, const label index, const polyTopoChanger &mme),(name, dict, index, mme))
	polyMeshModifier (const word &name, const label index, const polyTopoChanger &mme, const bool act)
virtual	~polyMeshModifier ()=default
const word &	name () const
label	index () const
const polyTopoChanger &	topoChanger () const
Switch	active () const
void	enable () const
void	disable () const

Additional Inherited Members
Static Public Member Functions inherited from polyMeshModifier
static autoPtr< polyMeshModifier >	New (const word &name, const dictionary &dict, const label index, const polyTopoChanger &mme)

Detailed Description

Keeps cell/face/vertex sets uptodate. Both the ones loaded and the ones on disk.

Source files

• setUpdater.H
• setUpdater.C
• setUpdaterTemplates.C

Definition at line 49 of file setUpdater.H.

Constructor & Destructor Documentation

setUpdater()

setUpdater	(	const word &	name,
		const dictionary &	dict,
		const label	index,
		const polyTopoChanger &	mme
	)

Definition at line 47 of file setUpdater.C.

~setUpdater()

virtual ~setUpdater ( )

virtualdefault

Member Function Documentation

TypeName()

TypeName

(

"setUpdater"

)

changeTopology()

bool changeTopology ( ) const

virtual

Implements polyMeshModifier.

Definition at line 60 of file setUpdater.C.

setRefinement()

void setRefinement ( polyTopoChange &  ) const

virtual

Implements polyMeshModifier.

Definition at line 67 of file setUpdater.C.

modifyMotionPoints()

void modifyMotionPoints ( pointField &  motionPoints ) const

virtual

Implements polyMeshModifier.

Definition at line 71 of file setUpdater.C.

updateMesh()

void updateMesh ( const mapPolyMesh &  morphMap )

virtual

Implements polyMeshModifier.

Definition at line 75 of file setUpdater.C.

References Foam::expressions::patchExpr::debug, Foam::endl(), and Foam::Pout.

Here is the call graph for this function:

write()

void write ( Ostream &  os ) const

virtual

Implements polyMeshModifier.

Definition at line 90 of file setUpdater.C.

References Foam::nl, os(), and Foam::type().

Here is the call graph for this function:

writeDict()

void writeDict ( Ostream &  os ) const

virtual

Implements polyMeshModifier.

Definition at line 96 of file setUpdater.C.

References Ostream::beginBlock(), Ostream::endBlock(), Foam::name(), Foam::nl, os(), Foam::type(), and Ostream::writeEntry().

Here is the call graph for this function:

---

The documentation for this class was generated from the following files:

• src/dynamicMesh/setUpdater/setUpdater.H
• src/dynamicMesh/setUpdater/setUpdater.C
• src/dynamicMesh/setUpdater/setUpdaterTemplates.C
