searchableSurfacesQueries Class Reference

A collection of tools for searchableSurfaces. More...

Public Member Functions

 ClassName ("searchableSurfacesQueries")


Static Public Member Functions

static void findAnyIntersection (const PtrList< searchableSurface > &, const labelList &surfacesToTest, const pointField &start, const pointField &end, labelList &surfaces, List< pointIndexHit > &)

static void findAllIntersections (const PtrList< searchableSurface > &, const labelList &surfacesToTest, const pointField &start, const pointField &end, labelListList &surfaces, List< List< pointIndexHit >> &surfaceHits)

static void findNearestIntersection (const PtrList< searchableSurface > &allSurfaces, const labelList &surfacesToTest, const pointField &start, const pointField &end, labelList &surface1, List< pointIndexHit > &hit1, labelList &surface2, List< pointIndexHit > &hit2)

static void findNearest (const PtrList< searchableSurface > &, const labelList &surfacesToTest, const pointField &, const scalarField &nearestDistSqr, labelList &surfaces, List< pointIndexHit > &)

static void findNearest (const PtrList< searchableSurface > &allSurfaces, const labelList &surfacesToTest, const labelListList &regionIndices, const pointField &samples, const scalarField &nearestDistSqr, labelList &nearestSurfaces, List< pointIndexHit > &nearestInfo)

static void findNearest (const PtrList< searchableSurface > &allSurfaces, const labelList &surfacesToTest, const pointField &start, const scalarField &distSqr, pointField &near, List< pointConstraint > &constraint, const label nIter=20)

static void signedDistance (const PtrList< searchableSurface > &allSurfaces, const labelList &surfacesToTest, const pointField &samples, const scalarField &nearestDistSqr, const volumeType illegalHandling, labelList &nearestSurfaces, scalarField &distance)

static boundBox bounds (const PtrList< searchableSurface > &allSurfaces, const labelUList &surfacesToTest)


Detailed Description

A collection of tools for searchableSurfaces.

Source files

Definition at line 50 of file searchableSurfacesQueries.H.

Member Function Documentation

◆ ClassName()

ClassName ( "searchableSurfacesQueries"  )

◆ findAnyIntersection()

void findAnyIntersection ( const PtrList< searchableSurface > &  allSurfaces,
const labelList &  surfacesToTest,
const pointField &  start,
const pointField &  end,
labelList &  surfaces,
List< pointIndexHit > &  hitInfo
)
static

Definition at line 115 of file searchableSurfacesQueries.C.

References stdFoam::end(), forAll, Foam::identity(), p0, and List::setSize().

Referenced by searchableSurfaces::findAnyIntersection(), and refinementSurfaces::findAnyIntersection().

Here is the call graph for this function:
Here is the caller graph for this function:

◆ findAllIntersections()

void findAllIntersections ( const PtrList< searchableSurface > &  allSurfaces,
const labelList &  surfacesToTest,
const pointField &  start,
const pointField &  end,
labelListList &  surfaces,
List< List< pointIndexHit >> &  surfaceHits
)
static

Definition at line 176 of file searchableSurfacesQueries.C.

References stdFoam::end(), forAll, Foam::magSqr(), and List::setSize().

Referenced by searchableSurfaces::findAllIntersections().

Here is the call graph for this function:
Here is the caller graph for this function:

◆ findNearestIntersection()

void findNearestIntersection ( const PtrList< searchableSurface > &  allSurfaces,
const labelList &  surfacesToTest,
const pointField &  start,
const pointField &  end,
labelList &  surface1,
List< pointIndexHit > &  hit1,
labelList &  surface2,
List< pointIndexHit > &  hit2
)
static

Definition at line 255 of file searchableSurfacesQueries.C.

References stdFoam::end(), forAll, and List::setSize().

Referenced by searchableSurfaces::findNearestIntersection().

Here is the call graph for this function:
Here is the caller graph for this function:

◆ findNearest() [1/3]

void findNearest ( const PtrList< searchableSurface > &  allSurfaces,
const labelList &  surfacesToTest,
const pointField &  samples,
const scalarField &  nearestDistSqr,
labelList &  surfaces,
List< pointIndexHit > &  nearestInfo
)
static

Definition at line 342 of file searchableSurfacesQueries.C.

References Foam::exit(), Foam::FatalError, FatalErrorInFunction, forAll, Foam::magSqr(), samples(), and List::setSize().

Referenced by searchableSurfaces::findNearest(), refinementSurfaces::findNearest(), refinementSurfaces::findNearestRegion(), projectCurveEdge::position(), and projectEdge::position().

Here is the call graph for this function:
Here is the caller graph for this function:

◆ findNearest() [2/3]

void findNearest ( const PtrList< searchableSurface > &  allSurfaces,
const labelList &  surfacesToTest,
const labelListList &  regionIndices,
const pointField &  samples,
const scalarField &  nearestDistSqr,
labelList &  nearestSurfaces,
List< pointIndexHit > &  nearestInfo
)
static

Definition at line 397 of file searchableSurfacesQueries.C.

References Foam::exit(), Foam::FatalError, FatalErrorInFunction, forAll, Foam::magSqr(), samples(), and List::setSize().

Here is the call graph for this function:

◆ findNearest() [3/3]

void findNearest ( const PtrList< searchableSurface > &  allSurfaces,
const labelList &  surfacesToTest,
const pointField &  start,
const scalarField &  distSqr,
pointField &  near,
List< pointConstraint > &  constraint,
const label  nIter = 20
)
static

Definition at line 470 of file searchableSurfacesQueries.C.

References plane::ray::dir(), Foam::constant::electromagnetic::e, Foam::exit(), Foam::FatalError, FatalErrorInFunction, forAll, Foam::mag(), n, plane::planeIntersect(), plane::ray::refPoint(), s, List::setSize(), Foam::sqrt(), and VectorSpace< Vector< scalar >, scalar, 3 >::zero.

Here is the call graph for this function:

◆ signedDistance()

void signedDistance ( const PtrList< searchableSurface > &  allSurfaces,
const labelList &  surfacesToTest,
const pointField &  samples,
const scalarField &  nearestDistSqr,
const volumeType  illegalHandling,
labelList &  nearestSurfaces,
scalarField &  distance
)
static

Definition at line 592 of file searchableSurfacesQueries.C.

References DynamicList::append(), DynamicField::append(), DynamicList::clear(), DynamicField::clear(), Foam::distance(), Foam::exit(), Foam::FatalError, FatalErrorInFunction, forAll, volumeType::INSIDE, Foam::mag(), volumeType::OUTSIDE, samples(), and volumeType::str().

Here is the call graph for this function:

◆ bounds()

Foam::boundBox bounds ( const PtrList< searchableSurface > &  allSurfaces,
const labelUList &  surfacesToTest
)
static

Definition at line 690 of file searchableSurfacesQueries.C.

References boundBox::add(), and boundBox::invertedBox.

Referenced by searchableSurfaces::bounds().

Here is the call graph for this function:
Here is the caller graph for this function:
The documentation for this class was generated from the following files:
