Searching on a rotated box. More...

Inheritance diagram for searchableRotatedBox:

Collaboration diagram for searchableRotatedBox:

Public Member Functions
	TypeName ("searchableRotatedBox")

	searchableRotatedBox (const IOobject &io, const vector &span, const coordSystem::cartesian &csys=coordSystem::cartesian{})

	searchableRotatedBox (const IOobject &io, const dictionary &dict)

virtual	~searchableRotatedBox ()=default

virtual const wordList &	regions () const

virtual bool	hasVolumeType () const

virtual volumeType	outsideVolumeType () const

virtual label	size () const

virtual tmp< pointField >	coordinates () const

virtual void	boundingSpheres (pointField &centres, scalarField &radiusSqr) const

virtual tmp< pointField >	points () const

virtual bool	overlaps (const boundBox &bb) const

pointIndexHit	findNearest (const point &sample, const scalar nearestDistSqr) const

pointIndexHit	findNearest (const linePointRef &ln, treeBoundBox &tightest, point &linePoint) const

pointIndexHit	findLine (const point &start, const point &end) const

pointIndexHit	findLineAny (const point &start, const point &end) const

virtual void	findNearest (const pointField &sample, const scalarField &nearestDistSqr, List< pointIndexHit > &) const

virtual void	findLine (const pointField &start, const pointField &end, List< pointIndexHit > &) const

virtual void	findLineAny (const pointField &start, const pointField &end, List< pointIndexHit > &) const

virtual void	findLineAll (const pointField &start, const pointField &end, List< List< pointIndexHit >> &) const

virtual void	getRegion (const List< pointIndexHit > &, labelList &region) const

virtual void	getNormal (const List< pointIndexHit > &, vectorField &normal) const

virtual void	getVolumeType (const pointField &points, List< volumeType > &volType) const

bool	writeData (Ostream &) const

virtual void	findNearest (const pointField &sample, const scalarField &nearestDistSqr, List< pointIndexHit > &) const=0

virtual void	findNearest (const pointField &samples, const scalarField &nearestDistSqr, const labelList &regionIndices, List< pointIndexHit > &info) const

virtual void	findNearest (const pointField &sample, const scalarField &nearestDistSqr, List< pointIndexHit > &, vectorField &normal, labelList &region) const

Public Member Functions inherited from searchableSurface
	TypeName ("searchableSurface")

	declareRunTimeSelectionTable (autoPtr, searchableSurface, dict,(const IOobject &io, const dictionary &dict),(io, dict))

	searchableSurface (const IOobject &io)

virtual autoPtr< searchableSurface >	clone () const

virtual	~searchableSurface ()=default

virtual bool	global () const

virtual fileName	filePath () const

virtual const boundBox &	bounds () const

virtual boundBox &	bounds ()

virtual label	globalSize () const

virtual void	findNearest (const pointField &samples, const scalarField &nearestDistSqr, const labelList &regionIndices, List< pointIndexHit > &info) const

virtual void	findNearest (const pointField &sample, const scalarField &nearestDistSqr, List< pointIndexHit > &, vectorField &normal, labelList &region) const

virtual void	distribute (const List< treeBoundBox > &, const bool keepNonLocal, autoPtr< mapDistribute > &faceMap, autoPtr< mapDistribute > &pointMap)

virtual void	setField (const labelList &values)

virtual void	getField (const List< pointIndexHit > &, labelList &values) const

Public Member Functions inherited from regIOobject
	TypeName ("regIOobject")

	regIOobject (const IOobject &io, const bool isTimeObject=false)

	regIOobject (const regIOobject &rio)

	regIOobject (const regIOobject &rio, bool registerCopy)

	regIOobject (const word &newName, const regIOobject &, bool registerCopy)

	regIOobject (const IOobject &io, const regIOobject &rio)

virtual	~regIOobject ()

bool	checkIn ()

bool	checkOut ()

virtual void	addWatch ()

bool	ownedByRegistry () const

bool	store ()

void	release (const bool unregister=false)

label	eventNo () const

label &	eventNo ()

bool	upToDate (const regIOobject &) const

bool	upToDate (const regIOobject &, const regIOobject &) const

bool	upToDate (const regIOobject &, const regIOobject &, const regIOobject &) const

bool	upToDate (const regIOobject &, const regIOobject &, const regIOobject &, const regIOobject &) const

void	setUpToDate ()

virtual void	rename (const word &newName)

const dictionary *	findMetaData () const noexcept

dictionary &	getMetaData () noexcept

void	removeMetaData ()

virtual void	updateMetaData ()

bool	headerOk ()

Istream &	readStream (const word &, const bool valid=true)

void	close ()

virtual bool	readData (Istream &)

virtual bool	read ()

virtual label	addWatch (const fileName &)

const labelList &	watchIndices () const

labelList &	watchIndices ()

virtual bool	modified () const

virtual bool	readIfModified ()

virtual bool	writeObject (IOstreamOption streamOpt, const bool valid) const

virtual bool	write (const bool valid=true) const

void	operator= (const IOobject &io)

virtual bool	writeObject (IOstreamOption::streamFormat fmt, IOstreamOption::versionNumber ver, IOstreamOption::compressionType comp, const bool valid) const

Public Member Functions inherited from IOobject
	TypeName ("IOobject")

	IOobject (const IOobject &)=default

virtual	~IOobject ()=default

	IOobject (const word &name, const fileName &instance, const objectRegistry &registry, readOption r=NO_READ, writeOption w=NO_WRITE, bool registerObject=true, bool globalObject=false)

	IOobject (const word &name, const fileName &instance, const fileName &local, const objectRegistry &registry, readOption r=NO_READ, writeOption w=NO_WRITE, bool registerObject=true, bool globalObject=false)

	IOobject (const fileName &path, const objectRegistry &registry, readOption r=NO_READ, writeOption w=NO_WRITE, bool registerObject=true, bool globalObject=false)

	IOobject (const IOobject &io, const objectRegistry &registry)

	IOobject (const IOobject &io, const word &name)

	IOobject (const IOobject &io, readOption, writeOption)

autoPtr< IOobject >	clone () const

autoPtr< IOobject >	clone (const objectRegistry &registry) const

const objectRegistry &	db () const noexcept

const Time &	time () const

const word &	name () const noexcept

const word &	headerClassName () const noexcept

word &	headerClassName () noexcept

const string &	note () const noexcept

string &	note () noexcept

bool	registerObject () const noexcept

bool	registerObject (bool on) noexcept

bool	globalObject () const noexcept

bool	globalObject (bool on) noexcept

unsigned	labelByteSize () const noexcept

unsigned	scalarByteSize () const noexcept

bool	isHeaderClassName (const word &clsName) const

template<class Type >
bool	isHeaderClassName () const

readOption	readOpt () const noexcept

readOption	readOpt (readOption opt) noexcept

writeOption	writeOpt () const noexcept

writeOption	writeOpt (writeOption opt) noexcept

word	group () const

word	member () const

const fileName &	rootPath () const

const fileName &	caseName () const

const fileName &	instance () const noexcept

fileName &	instance () noexcept

const fileName &	local () const noexcept

fileName	path () const

fileName	path (const word &instance, const fileName &local=fileName::null) const

fileName	objectPath () const

fileName	objectRelPath () const

fileName	localFilePath (const word &typeName, const bool search=true) const

fileName	globalFilePath (const word &typeName, const bool search=true) const

IOstreamOption	parseHeader (const dictionary &headerDict)

bool	readHeader (Istream &is)

bool	readHeader (dictionary &headerDict, Istream &is)

template<class Type >
bool	typeHeaderOk (const bool checkType=true, const bool search=true, const bool verbose=true)

template<class Type >
void	warnNoRereading () const

bool	writeHeader (Ostream &os) const

bool	writeHeader (Ostream &os, const word &objectType) const

void	writeHeader (dictionary &dict, IOstreamOption streamOpt) const

void	writeHeader (dictionary &dict, const word &objectType, IOstreamOption streamOpt) const

bool	good () const noexcept

bool	bad () const noexcept

InfoProxy< IOobject >	info () const

void	operator= (const IOobject &io)

readOption &	readOpt () noexcept

writeOption &	writeOpt () noexcept

bool &	registerObject () noexcept

bool &	globalObject () noexcept

template<>
bool	isHeaderClassName () const

template<class StringType >
Foam::word	groupName (StringType base, const word &group)

Additional Inherited Members
Public Types inherited from IOobject
enum	objectState : char { GOOD, BAD }

enum	readOption : char { MUST_READ, MUST_READ_IF_MODIFIED, READ_IF_PRESENT, NO_READ }

enum	writeOption : char { AUTO_WRITE = 0, NO_WRITE = 1 }

enum	fileCheckTypes : char { timeStamp, timeStampMaster, inotify, inotifyMaster }

Static Public Member Functions inherited from searchableSurface
static autoPtr< searchableSurface >	New (const word &surfaceType, const IOobject &io, const dictionary &dict)

Static Public Member Functions inherited from regIOobject
template<class Type >
static Type &	store (Type *p)

template<class Type >
static Type &	store (autoPtr< Type > &ptr)

template<class Type >
static Type &	store (autoPtr< Type > &&ptr)

template<class Type >
static Type &	store (refPtr< Type > &ptr)

template<class Type >
static Type &	store (refPtr< Type > &&ptr)

template<class Type >
static Type &	store (tmp< Type > &ptr)

template<class Type >
static Type &	store (tmp< Type > &&ptr)

Static Public Member Functions inherited from IOobject
static bool	bannerEnabled () noexcept

static bool	bannerEnabled (bool on) noexcept

static bool	fileNameComponents (const fileName &path, fileName &instance, fileName &local, word &name)

template<class StringType >
static word	groupName (StringType base, const word &group)

static word	group (const word &name)

static word	member (const word &name)

static word	scopedName (const std::string &scope, const word &name)

static IOobject	selectIO (const IOobject &io, const fileName &altFile, const word &ioName="")

static Ostream &	writeBanner (Ostream &os, const bool noSyntaxHint=false)

static Ostream &	writeDivider (Ostream &os)

static Ostream &	writeEndDivider (Ostream &os)

Static Public Attributes inherited from IOobject
static const Enum< fileCheckTypes >	fileCheckTypesNames

static char	scopeSeparator

static fileCheckTypes	fileModificationChecking

static float	fileModificationSkew

static int	maxFileModificationPolls

Protected Member Functions inherited from regIOobject
bool	readHeaderOk (const IOstreamOption::streamFormat fmt, const word &typeName)

Protected Member Functions inherited from IOobject
void	setBad (const string &s)

Static Protected Member Functions inherited from IOobject
static void	writeHeaderContent (Ostream &os, const IOobject &io, const word &objectType, const dictionary *metaDataDict=nullptr)

static void	writeHeaderContent (dictionary &dict, const IOobject &io, const word &objectType, IOstreamOption streamOpt, const dictionary *metaDataDict=nullptr)

Static Protected Attributes inherited from regIOobject
static bool	masterOnlyReading = false

Detailed Description

Searching on a rotated box.

Box defined as min and max coordinate. Rotation by coordinate system at box middle.

E.g. box with sides 1 1 1 rotated 45 degrees around z-axis at origin (0.5 0.5 0.5)

    span    (1 1 1);
    origin  (0.5 0.5 0.5);
    e1      (1 1 0);
    e3      (0 0 1);

Dictionary parameters

Property	Description	Required
`type`	rotatedBox	selector
`span`	The box dimensions	yes
`origin`	The box corner	yes
`e1`	Local x-axis of the box	yes
`e3`	Local z-axis of the box	yes

Note: Longer type name : searchableRotatedBox

Source files

Definition at line 105 of file searchableRotatedBox.H.

Constructor & Destructor Documentation

◆ searchableRotatedBox() [1/2]

searchableRotatedBox	(	const IOobject &	io,
		const vector &	span,
		const coordSystem::cartesian &	csys = `coordSystem::cartesian{}`
	)

Definition at line 49 of file searchableRotatedBox.C.

◆ searchableRotatedBox() [2/2]

searchableRotatedBox	(	const IOobject &	io,
		const dictionary &	dict
	)

Definition at line 77 of file searchableRotatedBox.C.

◆ ~searchableRotatedBox()

virtual ~searchableRotatedBox ( )

virtualdefault

Member Function Documentation

◆ TypeName()

TypeName ( "searchableRotatedBox" )

◆ regions()

const Foam::wordList & regions ( ) const

virtual

Implements searchableSurface.

Definition at line 98 of file searchableRotatedBox.C.

References searchableBox::regions().

Here is the call graph for this function:

◆ hasVolumeType()

virtual bool hasVolumeType ( ) const

inlinevirtual

Reimplemented from searchableSurface.

Definition at line 164 of file searchableRotatedBox.H.

◆ outsideVolumeType()

virtual volumeType outsideVolumeType ( ) const

inlinevirtual

Implements searchableSurface.

Definition at line 170 of file searchableRotatedBox.H.

References volumeType::OUTSIDE.

◆ size()

virtual label size ( ) const

inlinevirtual

Implements searchableSurface.

Definition at line 176 of file searchableRotatedBox.H.

◆ coordinates()

Foam::tmp< Foam::pointField > coordinates ( ) const

virtual

Implements searchableSurface.

Definition at line 104 of file searchableRotatedBox.C.

◆ boundingSpheres()

void boundingSpheres	(	pointField &	centres,
		scalarField &	radiusSqr
	)		const

virtual

Implements searchableSurface.

Definition at line 111 of file searchableRotatedBox.C.

◆ points()

Foam::tmp< Foam::pointField > points ( ) const

virtual

Implements searchableSurface.

Definition at line 121 of file searchableRotatedBox.C.

◆ overlaps()

bool overlaps ( const boundBox & bb ) const

virtual

Implements searchableSurface.

Definition at line 127 of file searchableRotatedBox.C.

References boundBox::containsAny(), PointHit< PointType >::distance(), Foam::constant::electromagnetic::e, treeBoundBox::edges, f(), treeBoundBox::faces, intersection::HALF_RAY, PointHit< PointType >::hit(), treeBoundBox::intersects(), boundBox::overlaps(), and boundBox::points().

Here is the call graph for this function:

◆ findNearest() [1/6]

Foam::pointIndexHit findNearest	(	const point &	sample,
		const scalar	nearestDistSqr
	)		const

Definition at line 189 of file searchableRotatedBox.C.

References PointIndexHit::rawPoint().

Here is the call graph for this function:

◆ findNearest() [2/6]

Foam::pointIndexHit findNearest	(	const linePointRef &	ln,
		treeBoundBox &	tightest,
		point &	linePoint
	)		const

Definition at line 210 of file searchableRotatedBox.C.

References NotImplemented.

◆ findLine() [1/2]

Foam::pointIndexHit findLine	(	const point &	start,
		const point &	end
	)		const

Definition at line 222 of file searchableRotatedBox.C.

References stdFoam::end(), and PointIndexHit::rawPoint().

Here is the call graph for this function:

◆ findLineAny() [1/2]

Foam::pointIndexHit findLineAny	(	const point &	start,
		const point &	end
	)		const

Definition at line 243 of file searchableRotatedBox.C.

References stdFoam::end().

Here is the call graph for this function:

◆ findNearest() [3/6]

void findNearest	(	const pointField &	sample,
		const scalarField &	nearestDistSqr,
		List< pointIndexHit > &	info
	)		const

virtual

Implements searchableSurface.

Definition at line 253 of file searchableRotatedBox.C.

References forAll, samples(), and List::setSize().

Here is the call graph for this function:

◆ findLine() [2/2]

void findLine	(	const pointField &	start,
		const pointField &	end,
		List< pointIndexHit > &	info
	)		const

virtual

Implements searchableSurface.

Definition at line 269 of file searchableRotatedBox.C.

References stdFoam::end(), forAll, and List::setSize().

Here is the call graph for this function:

◆ findLineAny() [2/2]

void findLineAny	(	const pointField &	start,
		const pointField &	end,
		List< pointIndexHit > &	info
	)		const

virtual

Implements searchableSurface.

Definition at line 285 of file searchableRotatedBox.C.

References stdFoam::end(), forAll, and List::setSize().

Here is the call graph for this function:

◆ findLineAll()

void findLineAll	(	const pointField &	start,
		const pointField &	end,
		List< List< pointIndexHit >> &	info
	)		const

virtual

Implements searchableSurface.

Definition at line 301 of file searchableRotatedBox.C.

References DynamicList::append(), List::clear(), DynamicList::clear(), stdFoam::end(), forAll, PointIndexHit::hit(), PointIndexHit::hitPoint(), PointIndexHit::index(), Foam::magSqr(), List::setSize(), Foam::sqrt(), and List::transfer().

Here is the call graph for this function:

◆ getRegion()

void getRegion	(	const List< pointIndexHit > &	info,
		labelList &	region
	)		const

virtual

Implements searchableSurface.

Definition at line 369 of file searchableRotatedBox.C.

References List::setSize().

Here is the call graph for this function:

◆ getNormal()

void getNormal	(	const List< pointIndexHit > &	info,
		vectorField &	normal
	)		const

virtual

Implements searchableSurface.

Definition at line 380 of file searchableRotatedBox.C.

◆ getVolumeType()

void getVolumeType	(	const pointField &	points,
		List< volumeType > &	volType
	)		const

virtual

Implements searchableSurface.

Definition at line 393 of file searchableRotatedBox.C.

References points.

◆ writeData()

bool writeData ( Ostream & ) const

inlinevirtual

Implements regIOobject.

Definition at line 301 of file searchableRotatedBox.H.

References NotImplemented.

◆ findNearest() [4/6]

virtual void findNearest

◆ findNearest() [5/6]

virtual void findNearest

inline

Definition at line 291 of file searchableSurface.H.

◆ findNearest() [6/6]

void findNearest

Definition at line 76 of file searchableSurface.C.

The documentation for this class was generated from the following files:

src/meshTools/searchableSurfaces/searchableRotatedBox/searchableRotatedBox.H
src/meshTools/searchableSurfaces/searchableRotatedBox/searchableRotatedBox.C

Public Member Functions

Additional Inherited Members

Detailed Description

Constructor & Destructor Documentation

◆ searchableRotatedBox() [1/2]

◆ searchableRotatedBox() [2/2]

◆ ~searchableRotatedBox()

Member Function Documentation

◆ TypeName()

◆ regions()

◆ hasVolumeType()

◆ outsideVolumeType()

◆ size()

◆ coordinates()

◆ boundingSpheres()

◆ points()

◆ overlaps()

◆ findNearest() [1/6]

◆ findNearest() [2/6]

◆ findLine() [1/2]

◆ findLineAny() [1/2]

◆ findNearest() [3/6]

◆ findLine() [2/2]

◆ findLineAny() [2/2]

◆ findLineAll()

◆ getRegion()

◆ getNormal()

◆ getVolumeType()

◆ writeData()

◆ findNearest() [4/6]

◆ findNearest() [5/6]

◆ findNearest() [6/6]
