A sampledSurface defined by the cell faces corresponding to a threshold value. More...

Inheritance diagram for sampledThresholdCellFaces:

Collaboration diagram for sampledThresholdCellFaces:

Public Member Functions
	TypeName ("sampledThresholdCellFaces")

	sampledThresholdCellFaces (const word &name, const polyMesh &, const dictionary &)

virtual	~sampledThresholdCellFaces ()=default

virtual bool	needsUpdate () const

virtual bool	expire ()

virtual bool	update ()

virtual const pointField &	points () const

virtual const faceList &	faces () const

virtual const labelList &	zoneIds () const

virtual const vectorField &	Sf () const

virtual const scalarField &	magSf () const

virtual const vectorField &	Cf () const

virtual tmp< scalarField >	sample (const interpolation< scalar > &sampler) const

virtual tmp< vectorField >	sample (const interpolation< vector > &sampler) const

virtual tmp< sphericalTensorField >	sample (const interpolation< sphericalTensor > &sampler) const

virtual tmp< symmTensorField >	sample (const interpolation< symmTensor > &sampler) const

virtual tmp< tensorField >	sample (const interpolation< tensor > &sampler) const

virtual tmp< scalarField >	interpolate (const interpolation< scalar > &interpolator) const

virtual tmp< vectorField >	interpolate (const interpolation< vector > &interpolator) const

virtual tmp< sphericalTensorField >	interpolate (const interpolation< sphericalTensor > &interpolator) const

virtual tmp< symmTensorField >	interpolate (const interpolation< symmTensor > &interpolator) const

virtual tmp< tensorField >	interpolate (const interpolation< tensor > &interpolator) const

virtual void	print (Ostream &os, int level=0) const

template<class Type >
Foam::tmp< Foam::Field< Type > >	sampleOnFaces (const interpolation< Type > &sampler) const

template<class Type >
Foam::tmp< Foam::Field< Type > >	sampleOnPoints (const interpolation< Type > &interpolator) const

Public Member Functions inherited from sampledSurface
	TypeName ("sampledSurface")

	declareRunTimeSelectionTable (autoPtr, sampledSurface, word,(const word &name, const polyMesh &mesh, const dictionary &dict),(name, mesh, dict))

	sampledSurface (const word &name, const polyMesh &mesh, const bool interpolateToPoints=false)

	sampledSurface (const word &name, const polyMesh &mesh, const dictionary &dict)

autoPtr< sampledSurface >	clone () const

virtual	~sampledSurface ()

const polyMesh &	mesh () const noexcept

const word &	name () const noexcept

bool	enabled () const noexcept

bool	invariant () const noexcept

bool	isPointData () const noexcept

virtual bool	isPointData (const bool on)

scalar	area () const

virtual bool	hasFaceIds () const

polySurface *	getRegistrySurface (const objectRegistry &obr, word lookupName="") const

polySurface *	storeRegistrySurface (objectRegistry &obr, word lookupName="") const

bool	removeRegistrySurface (objectRegistry &obr, word lookupName="") const

template<class Type , class GeoMeshType >
bool	storeRegistryField (const objectRegistry &obr, const word &fieldName, const dimensionSet &dims, const Field< Type > &values, word lookupName="") const

template<class Type , class GeoMeshType >
bool	storeRegistryField (const objectRegistry &obr, const word &fieldName, const dimensionSet &dims, Field< Type > &&values, word lookupName="") const

surfMesh *	getSurfMesh (word lookupName="") const

surfMesh *	storeSurfMesh (word lookupName="") const

bool	removeSurfMesh (word lookupName="") const

template<class Type , class GeoMeshType >
bool	storeSurfMeshField (const word &fieldName, const dimensionSet &dims, const Field< Type > &values, word lookupName="") const

template<class Type , class GeoMeshType >
bool	storeSurfMeshField (const word &fieldName, const dimensionSet &dims, Field< Type > &&values, word lookupName="") const

virtual bool	withSurfaceFields () const

virtual tmp< scalarField >	sample (const surfaceScalarField &sField) const

virtual tmp< vectorField >	sample (const surfaceVectorField &sField) const

virtual tmp< sphericalTensorField >	sample (const surfaceSphericalTensorField &sField) const

virtual tmp< symmTensorField >	sample (const surfaceSymmTensorField &sField) const

virtual tmp< tensorField >	sample (const surfaceTensorField &sField) const

virtual void	rename (const word &newName)

bool	interpolate () const noexcept

template<class Type >
Foam::tmp< Foam::Field< Type > >	sampleOnFaces (const interpolation< Type > &sampler, const labelUList &elements, const faceList &fcs, const pointField &pts, const Type &defaultValue)

template<class Type >
Foam::tmp< Foam::Field< Type > >	sampleOnPoints (const interpolation< Type > &interpolator, const labelUList &elements, const faceList &fcs, const pointField &pts)

template<class Type >
Foam::tmp< Foam::GeometricField< Type, Foam::fvPatchField, Foam::volMesh > >	pointAverage (const GeometricField< Type, pointPatchField, pointMesh > &pfld)

Public Member Functions inherited from meshedSurf
constexpr	meshedSurf () noexcept=default

virtual	~meshedSurf ()=default

virtual const labelList &	faceIds () const

Public Member Functions inherited from MeshedSurface
	ClassName ("MeshedSurface")

	MeshedSurface ()

	MeshedSurface (const MeshedSurface &surf)

	MeshedSurface (const UnsortedMeshedSurface< Face > &surf)

	MeshedSurface (MeshedSurface &&surf)

	MeshedSurface (UnsortedMeshedSurface< Face > &&surf)

	MeshedSurface (const pointField &pointLst, const UList< Face > &faceLst, const UList< surfZone > &zoneLst)

	MeshedSurface (pointField &&pointLst, List< Face > &&faceLst, const UList< surfZone > &zoneLst)

	MeshedSurface (const pointField &pointLst, const UList< Face > &faceLst, const labelUList &zoneSizes=labelUList(), const UList< word > &zoneNames=UList< word >())

	MeshedSurface (pointField &&pointLst, List< Face > &&faceLst, const labelUList &zoneSizes=labelUList(), const UList< word > &zoneNames=UList< word >())

	MeshedSurface (const polyBoundaryMesh &bMesh, const bool globalPoints=false)

	MeshedSurface (const surfMesh &mesh)

	MeshedSurface (const fileName &name)

	MeshedSurface (const fileName &name, const word &fileType)

	MeshedSurface (Istream &is)

	MeshedSurface (const Time &runTime)

	MeshedSurface (const Time &runTime, const word &surfName)

	MeshedSurface (const IOobject &io, const dictionary &dict, const bool isGlobal=true)

	declareRunTimeSelectionTable (autoPtr, MeshedSurface, fileExtension,(const fileName &name),(name))

virtual	~MeshedSurface ()

	declareMemberFunctionSelectionTable (void, UnsortedMeshedSurface, write, fileExtension,(const fileName &name, const MeshedSurface< Face > &surf, IOstreamOption streamOpt, const dictionary &options),(name, surf, streamOpt, options))

label	size () const

const List< Face > &	surfFaces () const

const labelList &	faceIds () const

const surfZoneList &	surfZones () const

const vectorField &	Sf () const

const scalarField &	magSf () const

const vectorField &	Cf () const

virtual void	clear ()

virtual void	addZones (const UList< surfZone > &, const bool cullEmpty=false)

virtual void	addZones (const labelUList &sizes, const UList< word > &names, const bool cullEmpty=false)

virtual void	addZones (const labelUList &sizes, const bool cullEmpty=false)

bool	addZonesToFaces ()

virtual void	removeZones ()

virtual void	movePoints (const pointField &newPoints)

virtual void	scalePoints (const scalar scaleFactor)

virtual void	cleanup (const bool verbose)

virtual void	compactPoints (labelList &pointMap=const_cast< labelList & >(labelList::null()))

virtual bool	stitchFaces (const scalar tol=SMALL, const bool verbose=false)

virtual bool	checkFaces (const bool verbose=false)

virtual label	nTriangles () const

virtual label	nTriangles (labelList &faceMap) const

virtual label	triangulate ()

virtual label	triangulate (labelList &faceMap)

template<class BoolListType >
void	subsetMeshMap (const BoolListType &include, labelList &pointMap, labelList &faceMap) const

MeshedSurface	subsetMesh (const UList< bool > &include, labelList &pointMap, labelList &faceMap) const

MeshedSurface	subsetMesh (const bitSet &include, labelList &pointMap, labelList &faceMap) const

MeshedSurface	subsetMesh (const UList< bool > &include) const

MeshedSurface	subsetMesh (const bitSet &include) const

MeshedSurface	subsetMesh (const wordRes &includeNames, const wordRes &excludeNames=wordRes()) const

void	swap (MeshedSurface< Face > &surf)

void	transfer (pointField &pointLst, List< Face > &faceLst)

void	transfer (MeshedSurface< Face > &surf)

void	transfer (UnsortedMeshedSurface< Face > &surf)

autoPtr< MeshedSurface< Face > >	releaseGeom ()

void	swapFaces (List< Face > &faces)

void	swapPoints (pointField &points)

bool	read (const fileName &name, const word &fileType)

virtual bool	read (const fileName &name)

void	writeStats (Ostream &os) const

virtual void	write (const fileName &name, IOstreamOption streamOpt=IOstreamOption(), const dictionary &options=dictionary::null) const

virtual void	write (const fileName &name, const word &fileType, IOstreamOption streamOpt=IOstreamOption(), const dictionary &options=dictionary::null) const

void	write (const Time &runTime, const word &surfName=word::null) const

void	operator= (const MeshedSurface< Face > &surf)

void	operator= (MeshedSurface< Face > &&surf)

	operator MeshedSurfaceProxy< Face > () const

template<class Face >
	MeshedSurface ()

template<class Face >
	MeshedSurface (const MeshedSurface< Face > &surf)

template<class Face >
	MeshedSurface (const UnsortedMeshedSurface< Face > &surf)

template<class Face >
	MeshedSurface (MeshedSurface< Face > &&surf)

template<class Face >
	MeshedSurface (UnsortedMeshedSurface< Face > &&surf)

template<class Face >
	MeshedSurface (const pointField &pointLst, const UList< Face > &faceLst, const UList< surfZone > &zoneLst)

template<class Face >
	MeshedSurface (pointField &&pointLst, List< Face > &&faceLst, const UList< surfZone > &zoneLst)

template<class Face >
	MeshedSurface (const pointField &pointLst, const UList< Face > &faceLst, const labelUList &zoneSizes, const UList< word > &zoneNames)

template<class Face >
	MeshedSurface (pointField &&pointLst, List< Face > &&faceLst, const labelUList &zoneSizes, const UList< word > &zoneNames)

template<class Face >
	MeshedSurface (const surfMesh &mesh)

template<class Face >
	MeshedSurface (const polyBoundaryMesh &bMesh, const bool useGlobalPoints)

template<class Face >
	MeshedSurface (const fileName &name, const word &fileType)

template<class Face >
	MeshedSurface (const fileName &name)

template<class Face >
	MeshedSurface (Istream &is)

template<class Face >
	MeshedSurface (const Time &runTime)

template<class Face >
	MeshedSurface (const Time &runTime, const word &surfName)

template<class Face >
	MeshedSurface (const IOobject &io, const dictionary &dict, const bool isGlobal)

bool	addZonesToFaces ()

bool	addZonesToFaces ()

Additional Inherited Members
Public Types inherited from MeshedSurface
typedef Face	face_type

typedef point	point_type

Static Public Member Functions inherited from sampledSurface
static autoPtr< sampledSurface >	New (const word &name, const polyMesh &mesh, const dictionary &dict)

Static Public Member Functions inherited from MeshedSurface
static wordHashSet	readTypes ()

static wordHashSet	writeTypes ()

static bool	canReadType (const word &fileType, bool verbose=false)

static bool	canWriteType (const word &fileType, bool verbose=false)

static bool	canRead (const fileName &name, bool verbose=false)

static autoPtr< MeshedSurface >	New (const fileName &name, const word &fileType, bool mandatory=true)

static autoPtr< MeshedSurface >	New (const fileName &name)

static void	write (const fileName &name, const MeshedSurface< Face > &surf, IOstreamOption streamOpt=IOstreamOption(), const dictionary &options=dictionary::null)

static void	write (const fileName &name, const word &fileType, const MeshedSurface< Face > &surf, IOstreamOption streamOpt=IOstreamOption(), const dictionary &options=dictionary::null)

Static Public Attributes inherited from sampledSurface
static const wordList	surfaceFieldTypes

Protected Member Functions inherited from sampledSurface
virtual void	clearGeom () const

	sampledSurface (const word &name, std::nullptr_t)

Protected Member Functions inherited from MeshedSurface
void	transcribe (MeshedSurface< face > &surf)

void	checkZones (const bool verbose=true)

pointField &	storedPoints ()

List< Face > &	storedFaces ()

labelList &	storedFaceIds ()

surfZoneList &	storedZones ()

void	sortFacesAndStore (DynamicList< Face > &unsortedFaces, DynamicList< label > &zoneIds, DynamicList< label > &elemIds, bool sorted)

virtual void	remapFaces (const labelUList &faceMapNewToOld)

void	transcribe (MeshedSurface< face > &surf)

void	transcribe (MeshedSurface< face > &surf)

void	transcribe (MeshedSurface< face > &surf)

Static Protected Member Functions inherited from sampledSurface
template<class Type >
static tmp< Field< Type > >	sampleOnFaces (const interpolation< Type > &sampler, const labelUList &elements, const faceList &fcs, const pointField &pts, const Type &defaultValue=Type(Zero))

template<class Type >
static tmp< Field< Type > >	sampleOnPoints (const interpolation< Type > &interpolator, const labelUList &elements, const faceList &fcs, const pointField &pts)

template<class Type >
static tmp< GeometricField< Type, fvPatchField, volMesh > >	pointAverage (const GeometricField< Type, pointPatchField, pointMesh > &pfld)

Detailed Description

A sampledSurface defined by the cell faces corresponding to a threshold value.

This is often embedded as part of a sampled surfaces function object.

Usage

Example of function object partial specification:

surfaces
{
    surface1
    {
        type    thresholdCellFaces;
        field   rho;
        lowerLimit 0.1;
    }
}

Where the sub-entries comprise:

Property	Description	Required	Default
`type`	thresholdCellFaces	yes
`field`	field name for threshold	yes
`lowerLimit`	lower limit for threshold	partly	-Inf
`upperLimit`	upper limit for threshold	partly	+Inf
`triangulate`	triangulate faces	no	false

Note: Must specify at least one or both of lowerLimit or upperLimit

See also: Foam::thresholdCellFaces

Source files

Definition at line 112 of file sampledThresholdCellFaces.H.

Constructor & Destructor Documentation

◆ sampledThresholdCellFaces()

sampledThresholdCellFaces	(	const word &	name,
		const polyMesh &	mesh,
		const dictionary &	dict
	)

Definition at line 139 of file sampledThresholdCellFaces.C.

References Foam::abort(), dict, Foam::endl(), Foam::FatalError, FatalErrorInFunction, and dictionary::found().

Here is the call graph for this function:

◆ ~sampledThresholdCellFaces()

virtual ~sampledThresholdCellFaces ( )

virtualdefault

Member Function Documentation

◆ TypeName()

TypeName ( "sampledThresholdCellFaces" )

◆ needsUpdate()

bool needsUpdate ( ) const

virtual

Implements sampledSurface.

Definition at line 164 of file sampledThresholdCellFaces.C.

References mesh, fvMesh::time(), and TimeState::timeIndex().

Here is the call graph for this function:

◆ expire()

bool expire ( )

virtual

Implements sampledSurface.

Definition at line 172 of file sampledThresholdCellFaces.C.

◆ update()

bool update ( )

virtual

Implements sampledSurface.

Definition at line 186 of file sampledThresholdCellFaces.C.

◆ points()

virtual const pointField& points ( ) const

inlinevirtual

Implements sampledSurface.

Definition at line 201 of file sampledThresholdCellFaces.H.

References points.

◆ faces()

virtual const faceList& faces ( ) const

inlinevirtual

Implements sampledSurface.

Definition at line 207 of file sampledThresholdCellFaces.H.

References MeshedSurface::surfFaces().

Here is the call graph for this function:

◆ zoneIds()

virtual const labelList& zoneIds ( ) const

inlinevirtual

Reimplemented from meshedSurf.

Definition at line 213 of file sampledThresholdCellFaces.H.

References List::null().

Here is the call graph for this function:

◆ Sf()

virtual const vectorField& Sf ( ) const

inlinevirtual

Implements sampledSurface.

Definition at line 219 of file sampledThresholdCellFaces.H.

References MeshedSurface::Sf().

Here is the call graph for this function:

◆ magSf()

virtual const scalarField& magSf ( ) const

inlinevirtual

Implements sampledSurface.

Definition at line 225 of file sampledThresholdCellFaces.H.

References MeshedSurface::magSf().

Here is the call graph for this function:

◆ Cf()

virtual const vectorField& Cf ( ) const

inlinevirtual

Implements sampledSurface.

Definition at line 231 of file sampledThresholdCellFaces.H.

References MeshedSurface::Cf().

Here is the call graph for this function:

◆ sample() [1/5]

Foam::tmp< Foam::scalarField > sample ( const interpolation< scalar > & sampler ) const

virtual

Implements sampledSurface.

Definition at line 193 of file sampledThresholdCellFaces.C.

◆ sample() [2/5]

Foam::tmp< Foam::vectorField > sample ( const interpolation< vector > & sampler ) const

virtual

Implements sampledSurface.

Definition at line 202 of file sampledThresholdCellFaces.C.

◆ sample() [3/5]

Foam::tmp< Foam::sphericalTensorField > sample ( const interpolation< sphericalTensor > & sampler ) const

virtual

Implements sampledSurface.

Definition at line 211 of file sampledThresholdCellFaces.C.

◆ sample() [4/5]

Foam::tmp< Foam::symmTensorField > sample ( const interpolation< symmTensor > & sampler ) const

virtual

Implements sampledSurface.

Definition at line 220 of file sampledThresholdCellFaces.C.

◆ sample() [5/5]

Foam::tmp< Foam::tensorField > sample ( const interpolation< tensor > & sampler ) const

virtual

Implements sampledSurface.

Definition at line 229 of file sampledThresholdCellFaces.C.

◆ interpolate() [1/5]

Foam::tmp< Foam::scalarField > interpolate ( const interpolation< scalar > & interpolator ) const

virtual

Implements sampledSurface.

Definition at line 238 of file sampledThresholdCellFaces.C.

◆ interpolate() [2/5]

Foam::tmp< Foam::vectorField > interpolate ( const interpolation< vector > & interpolator ) const

virtual

Implements sampledSurface.

Definition at line 247 of file sampledThresholdCellFaces.C.

◆ interpolate() [3/5]

Foam::tmp< Foam::sphericalTensorField > interpolate ( const interpolation< sphericalTensor > & interpolator ) const

virtual

Implements sampledSurface.

Definition at line 256 of file sampledThresholdCellFaces.C.

◆ interpolate() [4/5]

Foam::tmp< Foam::symmTensorField > interpolate ( const interpolation< symmTensor > & interpolator ) const

virtual

Implements sampledSurface.

Definition at line 265 of file sampledThresholdCellFaces.C.

◆ interpolate() [5/5]

Foam::tmp< Foam::tensorField > interpolate ( const interpolation< tensor > & interpolator ) const

virtual

Implements sampledSurface.

Definition at line 274 of file sampledThresholdCellFaces.C.

◆ print()

void print	(	Ostream &	os,
		int	level = `0`
	)		const

virtual

Reimplemented from sampledSurface.

Definition at line 282 of file sampledThresholdCellFaces.C.

References Foam::name(), and os().

Here is the call graph for this function:

◆ sampleOnFaces()

Foam::tmp<Foam::Field<Type> > sampleOnFaces ( const interpolation< Type > & sampler ) const

Definition at line 34 of file sampledThresholdCellFacesTemplates.C.

References points.

◆ sampleOnPoints()

Foam::tmp<Foam::Field<Type> > sampleOnPoints ( const interpolation< Type > & interpolator ) const

Definition at line 53 of file sampledThresholdCellFacesTemplates.C.

References points.

The documentation for this class was generated from the following files:

src/sampling/sampledSurface/thresholdCellFaces/sampledThresholdCellFaces.H
src/sampling/sampledSurface/thresholdCellFaces/sampledThresholdCellFaces.C
src/sampling/sampledSurface/thresholdCellFaces/sampledThresholdCellFacesTemplates.C

Public Member Functions

Additional Inherited Members

Detailed Description

Constructor & Destructor Documentation

◆ sampledThresholdCellFaces()

◆ ~sampledThresholdCellFaces()

Member Function Documentation

◆ TypeName()

◆ needsUpdate()

◆ expire()

◆ update()

◆ points()

◆ faces()

◆ zoneIds()

◆ Sf()

◆ magSf()

◆ Cf()

◆ sample() [1/5]

◆ sample() [2/5]

◆ sample() [3/5]

◆ sample() [4/5]

◆ sample() [5/5]

◆ interpolate() [1/5]

◆ interpolate() [2/5]

◆ interpolate() [3/5]

◆ interpolate() [4/5]

◆ interpolate() [5/5]

◆ print()

◆ sampleOnFaces()

◆ sampleOnPoints()
