An abstract class for surfaces with sampling. More...

Inheritance diagram for sampledSurface:

[legend]

Collaboration diagram for sampledSurface:

Classes
class	iNew

class	iNewCapture

Public Member Functions
	TypeName ("sampledSurface")

	declareRunTimeSelectionTable (autoPtr, sampledSurface, word,(const word &name, const polyMesh &mesh, const dictionary &dict),(name, mesh, dict))

	sampledSurface (const word &name, const polyMesh &mesh, const bool interpolateToPoints=false)

	sampledSurface (const word &name, const polyMesh &mesh, const dictionary &dict)

autoPtr< sampledSurface >	clone () const

virtual	~sampledSurface ()

const polyMesh &	mesh () const noexcept

const word &	name () const noexcept

bool	enabled () const noexcept

bool	invariant () const noexcept

bool	isPointData () const noexcept

virtual bool	isPointData (const bool on)

virtual bool	needsUpdate () const =0

virtual bool	expire ()=0

virtual bool	update ()=0

virtual const pointField &	points () const =0

virtual const faceList &	faces () const =0

virtual const vectorField &	Sf () const =0

virtual const scalarField &	magSf () const =0

virtual const vectorField &	Cf () const =0

scalar	area () const

virtual bool	hasFaceIds () const

polySurface *	getRegistrySurface (const objectRegistry &obr, word lookupName="") const

polySurface *	storeRegistrySurface (objectRegistry &obr, word lookupName="") const

bool	removeRegistrySurface (objectRegistry &obr, word lookupName="") const

template<class Type , class GeoMeshType >
bool	storeRegistryField (const objectRegistry &obr, const word &fieldName, const dimensionSet &dims, const Field< Type > &values, word lookupName="") const

template<class Type , class GeoMeshType >
bool	storeRegistryField (const objectRegistry &obr, const word &fieldName, const dimensionSet &dims, Field< Type > &&values, word lookupName="") const

surfMesh *	getSurfMesh (word lookupName="") const

surfMesh *	storeSurfMesh (word lookupName="") const

bool	removeSurfMesh (word lookupName="") const

template<class Type , class GeoMeshType >
bool	storeSurfMeshField (const word &fieldName, const dimensionSet &dims, const Field< Type > &values, word lookupName="") const

template<class Type , class GeoMeshType >
bool	storeSurfMeshField (const word &fieldName, const dimensionSet &dims, Field< Type > &&values, word lookupName="") const

virtual tmp< scalarField >	sample (const interpolation< scalar > &sampler) const =0

virtual tmp< vectorField >	sample (const interpolation< vector > &sampler) const =0

virtual tmp< sphericalTensorField >	sample (const interpolation< sphericalTensor > &sampler) const =0

virtual tmp< symmTensorField >	sample (const interpolation< symmTensor > &sampler) const =0

virtual tmp< tensorField >	sample (const interpolation< tensor > &sampler) const =0

virtual bool	withSurfaceFields () const

virtual tmp< scalarField >	sample (const surfaceScalarField &sField) const

virtual tmp< vectorField >	sample (const surfaceVectorField &sField) const

virtual tmp< sphericalTensorField >	sample (const surfaceSphericalTensorField &sField) const

virtual tmp< symmTensorField >	sample (const surfaceSymmTensorField &sField) const

virtual tmp< tensorField >	sample (const surfaceTensorField &sField) const

virtual tmp< scalarField >	interpolate (const interpolation< scalar > &interpolator) const =0

virtual tmp< vectorField >	interpolate (const interpolation< vector > &interpolator) const =0

virtual tmp< sphericalTensorField >	interpolate (const interpolation< sphericalTensor > &interpolator) const =0

virtual tmp< symmTensorField >	interpolate (const interpolation< symmTensor > &interpolator) const =0

virtual tmp< tensorField >	interpolate (const interpolation< tensor > &interpolator) const =0

virtual void	rename (const word &newName)

virtual void	print (Ostream &os, int level=0) const

bool	interpolate () const noexcept

template<class Type >
Foam::tmp< Foam::Field< Type > >	sampleOnFaces (const interpolation< Type > &sampler, const labelUList &elements, const faceList &fcs, const pointField &pts, const Type &defaultValue)

template<class Type >
Foam::tmp< Foam::Field< Type > >	sampleOnPoints (const interpolation< Type > &interpolator, const labelUList &elements, const faceList &fcs, const pointField &pts)

template<class Type >
Foam::tmp< Foam::GeometricField< Type, Foam::fvPatchField, Foam::volMesh > >	pointAverage (const GeometricField< Type, pointPatchField, pointMesh > &pfld)

Public Member Functions inherited from meshedSurf
constexpr	meshedSurf () noexcept=default

virtual	~meshedSurf ()=default

virtual const labelList &	zoneIds () const

virtual const labelList &	faceIds () const

Static Public Member Functions
static autoPtr< sampledSurface >	New (const word &name, const polyMesh &mesh, const dictionary &dict)

Static Public Attributes
static const wordList	surfaceFieldTypes

Protected Member Functions
virtual void	clearGeom () const

	sampledSurface (const word &name, std::nullptr_t)

Static Protected Member Functions
template<class Type >
static tmp< Field< Type > >	sampleOnFaces (const interpolation< Type > &sampler, const labelUList &elements, const faceList &fcs, const pointField &pts, const Type &defaultValue=Type(Zero))

template<class Type >
static tmp< Field< Type > >	sampleOnPoints (const interpolation< Type > &interpolator, const labelUList &elements, const faceList &fcs, const pointField &pts)

template<class Type >
static tmp< GeometricField< Type, fvPatchField, volMesh > >	pointAverage (const GeometricField< Type, pointPatchField, pointMesh > &pfld)

Detailed Description

An abstract class for surfaces with sampling.

The constructors for the derived classes should generally start in a 'expired' condition (ie, needsUpdate() == true) and rely on a subsequent call to the update() method to complete the initialization. Delaying the final construction as late as possible allows the construction of surfaces that may depend on intermediate calculation results (eg, iso-surfaces) and also avoids the unnecessary reconstruction of surfaces between sampling intervals.

It is the responsibility of the caller to ensure that the surface update() is called before the surface is used. The update() method implementation should do nothing when the surface is already up-to-date.

Any sampler is assumed to work for the standard volume field types. Some may also support surface fields.

Dictionary entries:

Property	Description	Required	Default
`name`	Alternative name	no
`enabled`	Enable/disable the surface?	no	yes
`interpolate`	Interpolate to nodes instead of faces	no	false
`invariant`	Invariant with geometry change (use with caution!)	no	false

Note: The invariant switch is an advanced feature to declare that the surface is unaffected by changes in the general mesh geometry. For example, if sampling on a static patch while some other motion occurs elsewhere. If used improperly, there is a significant possibility for problems (caveat emptor).

Source files

Definition at line 117 of file sampledSurface.H.

Constructor & Destructor Documentation

◆ sampledSurface() [1/3]

sampledSurface	(	const word &	name,
		std::nullptr_t
	)

explicitprotected

Definition at line 85 of file sampledSurface.C.

◆ sampledSurface() [2/3]

sampledSurface	(	const word &	name,
		const polyMesh &	mesh,
		const bool	interpolateToPoints = `false`
	)

Definition at line 97 of file sampledSurface.C.

◆ sampledSurface() [3/3]

sampledSurface	(	const word &	name,
		const polyMesh &	mesh,
		const dictionary &	dict
	)

Definition at line 113 of file sampledSurface.C.

◆ ~sampledSurface()

~sampledSurface ( )

virtual

Definition at line 130 of file sampledSurface.C.

Member Function Documentation

◆ sampleOnFaces() [1/2]

static tmp<Field<Type> > sampleOnFaces	(	const interpolation< Type > &	sampler,
		const labelUList &	elements,
		const faceList &	fcs,
		const pointField &	pts,
		const Type &	defaultValue = `Type(Zero)`
	)

staticprotected

◆ sampleOnPoints() [1/2]

static tmp<Field<Type> > sampleOnPoints	(	const interpolation< Type > &	interpolator,
		const labelUList &	elements,
		const faceList &	fcs,
		const pointField &	pts
	)

staticprotected

◆ pointAverage() [1/2]

static tmp<GeometricField<Type, fvPatchField, volMesh> > pointAverage ( const GeometricField< Type, pointPatchField, pointMesh > & pfld )

staticprotected

◆ clearGeom()

void clearGeom ( ) const

protectedvirtual

Definition at line 46 of file sampledSurface.C.

Referenced by sampledCuttingSurface::expire(), sampledFaceZone::expire(), sampledPlane::expire(), sampledPatch::expire(), sampledCuttingPlane::expire(), sampledMeshedSurface::expire(), sampledIsoSurface::expire(), sampledCuttingSurface::update(), and sampledPlane::update().

Here is the caller graph for this function:

◆ TypeName()

TypeName ( "sampledSurface" )

◆ declareRunTimeSelectionTable()

declareRunTimeSelectionTable	(	autoPtr	,
		sampledSurface	,
		word	,
		(const word &name, const polyMesh &mesh, const dictionary &dict)	,
		(name, mesh, dict)
	)

◆ clone()

autoPtr<sampledSurface> clone ( ) const

inline

Definition at line 285 of file sampledSurface.H.

References NotImplemented.

◆ New()

Foam::autoPtr< Foam::sampledSurface > New	(	const word &	name,
		const polyMesh &	mesh,
		const dictionary &	dict
	)

static

Definition at line 55 of file sampledSurface.C.

References DebugInfo, dict, Foam::endl(), Foam::exit(), Foam::FatalIOError, FatalIOErrorInLookup, dictionary::get(), mesh, and Foam::name().

Referenced by sampledSurface::iNew::operator()(), sampledSurface::iNewCapture::operator()(), sampledSurfaces::read(), and surfaceFieldValue::read().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ mesh()

const polyMesh& mesh ( ) const

inlinenoexcept

Definition at line 312 of file sampledSurface.H.

Referenced by sampledSurface::getSurfMesh(), sampledPatch::patchIDs(), and sampledFaceZone::zoneIDs().

Here is the caller graph for this function:

◆ name()

const word& name ( ) const

inlinenoexcept

Definition at line 318 of file sampledSurface.H.

Referenced by sampledSurface::getSurfMesh(), sampledSurface::iNew::operator()(), sampledSurface::iNewCapture::operator()(), and sampledPatchInternalField::print().

Here is the caller graph for this function:

◆ enabled()

bool enabled ( ) const

inlinenoexcept

Definition at line 324 of file sampledSurface.H.

◆ invariant()

bool invariant ( ) const

inlinenoexcept

Definition at line 330 of file sampledSurface.H.

◆ isPointData() [1/2]

bool isPointData ( ) const

inlinenoexcept

Definition at line 336 of file sampledSurface.H.

◆ isPointData() [2/2]

bool isPointData ( const bool on )

virtual

Definition at line 149 of file sampledSurface.C.

◆ needsUpdate()

virtual bool needsUpdate ( ) const

pure virtual

Implemented in sampledIsoSurface, sampledMeshedSurface, sampledCuttingPlane, sampledDistanceSurface, sampledPatch, sampledPlane, sampledThresholdCellFaces, sampledFaceZone, sampledCuttingSurface, sampledInterface, and sampledNone.

◆ expire()

virtual bool expire ( )

pure virtual

Implemented in sampledIsoSurface, sampledMeshedSurface, sampledCuttingPlane, sampledDistanceSurface, sampledPatch, sampledPlane, sampledThresholdCellFaces, sampledFaceZone, sampledCuttingSurface, sampledInterface, and sampledNone.

◆ update()

virtual bool update ( )

pure virtual

Implemented in sampledIsoSurface, sampledMeshedSurface, sampledCuttingPlane, sampledDistanceSurface, sampledPatch, sampledPlane, sampledThresholdCellFaces, sampledFaceZone, sampledCuttingSurface, sampledInterface, and sampledNone.

◆ points()

virtual const pointField& points ( ) const

pure virtual

Implements meshedSurf.

Implemented in sampledIsoSurface, sampledCuttingPlane, sampledMeshedSurface, sampledDistanceSurface, sampledPatch, sampledPlane, sampledThresholdCellFaces, sampledFaceZone, sampledCuttingSurface, sampledInterface, and sampledNone.

◆ faces()

virtual const faceList& faces ( ) const

pure virtual

Implements meshedSurf.

Implemented in sampledIsoSurface, sampledCuttingPlane, sampledMeshedSurface, sampledDistanceSurface, sampledPatch, sampledPlane, sampledThresholdCellFaces, sampledFaceZone, sampledCuttingSurface, sampledInterface, and sampledNone.

◆ Sf()

virtual const vectorField& Sf ( ) const

pure virtual

Implemented in sampledIsoSurface, sampledMeshedSurface, sampledCuttingPlane, sampledDistanceSurface, sampledPatch, sampledPlane, sampledThresholdCellFaces, sampledFaceZone, sampledCuttingSurface, sampledInterface, and sampledNone.

◆ magSf()

virtual const scalarField& magSf ( ) const

pure virtual

Implemented in sampledIsoSurface, sampledMeshedSurface, sampledCuttingPlane, sampledDistanceSurface, sampledPatch, sampledPlane, sampledThresholdCellFaces, sampledFaceZone, sampledCuttingSurface, sampledInterface, and sampledNone.

◆ Cf()

virtual const vectorField& Cf ( ) const

pure virtual

Implemented in sampledIsoSurface, sampledMeshedSurface, sampledCuttingPlane, sampledDistanceSurface, sampledPatch, sampledPlane, sampledThresholdCellFaces, sampledFaceZone, sampledCuttingSurface, sampledInterface, and sampledNone.

◆ area()

Foam::scalar area ( ) const

Definition at line 138 of file sampledSurface.C.

References Foam::gSum().

Here is the call graph for this function:

◆ hasFaceIds()

virtual bool hasFaceIds ( ) const

inlinevirtual

Reimplemented in sampledMeshedSurface.

Definition at line 376 of file sampledSurface.H.

◆ getRegistrySurface()

Foam::polySurface * getRegistrySurface	(	const objectRegistry &	obr,
		word	lookupName = `""`
	)		const

Definition at line 28 of file sampledSurfaceRegister.C.

References objectRegistry::getObjectPtr(), and Foam::name().

Here is the call graph for this function:

◆ storeRegistrySurface()

Foam::polySurface * storeRegistrySurface	(	objectRegistry &	obr,
		word	lookupName = `""`
	)		const

Definition at line 43 of file sampledSurfaceRegister.C.

References polySurface::copySurface(), and Foam::name().

Here is the call graph for this function:

◆ removeRegistrySurface()

bool removeRegistrySurface	(	objectRegistry &	obr,
		word	lookupName = `""`
	)		const

Definition at line 68 of file sampledSurfaceRegister.C.

References objectRegistry::checkOut().

Here is the call graph for this function:

◆ storeRegistryField() [1/2]

bool storeRegistryField	(	const objectRegistry &	obr,
		const word &	fieldName,
		const dimensionSet &	dims,
		const Field< Type > &	values,
		word	lookupName = `""`
	)		const

Definition at line 175 of file sampledSurfaceTemplates.C.

References polySurface::storeField(), and Foam::HashTableOps::values().

Here is the call graph for this function:

◆ storeRegistryField() [2/2]

bool storeRegistryField	(	const objectRegistry &	obr,
		const word &	fieldName,
		const dimensionSet &	dims,
		Field< Type > &&	values,
		word	lookupName = `""`
	)		const

Definition at line 199 of file sampledSurfaceTemplates.C.

References polySurface::storeField(), and Foam::HashTableOps::values().

Here is the call graph for this function:

◆ getSurfMesh()

Foam::surfMesh * getSurfMesh ( word lookupName = "" ) const

Definition at line 78 of file sampledSurfaceRegister.C.

References objectRegistry::getObjectPtr(), sampledSurface::mesh(), and sampledSurface::name().

Here is the call graph for this function:

◆ storeSurfMesh()

Foam::surfMesh * storeSurfMesh ( word lookupName = "" ) const

Definition at line 89 of file sampledSurfaceRegister.C.

References surfMesh::copySurface(), mesh, Foam::name(), and regIOobject::store().

Here is the call graph for this function:

◆ removeSurfMesh()

bool removeSurfMesh ( word lookupName = "" ) const

Definition at line 112 of file sampledSurfaceRegister.C.

References objectRegistry::checkOut(), and mesh.

Here is the call graph for this function:

◆ storeSurfMeshField() [1/2]

bool storeSurfMeshField	(	const word &	fieldName,
		const dimensionSet &	dims,
		const Field< Type > &	values,
		word	lookupName = `""`
	)		const

Definition at line 223 of file sampledSurfaceTemplates.C.

References surfMesh::storeField(), and Foam::HashTableOps::values().

Here is the call graph for this function:

◆ storeSurfMeshField() [2/2]

bool storeSurfMeshField	(	const word &	fieldName,
		const dimensionSet &	dims,
		Field< Type > &&	values,
		word	lookupName = `""`
	)		const

Definition at line 246 of file sampledSurfaceTemplates.C.

References surfMesh::storeField(), and Foam::HashTableOps::values().

Here is the call graph for this function:

◆ sample() [1/10]

virtual tmp<scalarField> sample ( const interpolation< scalar > & sampler ) const

pure virtual

Implemented in sampledIsoSurface, sampledMeshedSurface, sampledCuttingPlane, sampledDistanceSurface, sampledPatch, sampledPlane, sampledThresholdCellFaces, sampledFaceZone, sampledCuttingSurface, sampledInterface, sampledPatchInternalField, sampledMeshedSurfaceNormal, and sampledNone.

◆ sample() [2/10]

virtual tmp<vectorField> sample ( const interpolation< vector > & sampler ) const

pure virtual

Implemented in sampledIsoSurface, sampledMeshedSurface, sampledCuttingPlane, sampledDistanceSurface, sampledPatch, sampledPlane, sampledThresholdCellFaces, sampledFaceZone, sampledCuttingSurface, sampledInterface, sampledPatchInternalField, sampledMeshedSurfaceNormal, and sampledNone.

◆ sample() [3/10]

virtual tmp<sphericalTensorField> sample ( const interpolation< sphericalTensor > & sampler ) const

pure virtual

Implemented in sampledIsoSurface, sampledMeshedSurface, sampledCuttingPlane, sampledDistanceSurface, sampledPatch, sampledPlane, sampledThresholdCellFaces, sampledFaceZone, sampledCuttingSurface, sampledInterface, sampledPatchInternalField, sampledMeshedSurfaceNormal, and sampledNone.

◆ sample() [4/10]

virtual tmp<symmTensorField> sample ( const interpolation< symmTensor > & sampler ) const

pure virtual

Implemented in sampledIsoSurface, sampledMeshedSurface, sampledCuttingPlane, sampledDistanceSurface, sampledPatch, sampledPlane, sampledThresholdCellFaces, sampledFaceZone, sampledCuttingSurface, sampledInterface, sampledPatchInternalField, sampledMeshedSurfaceNormal, and sampledNone.

◆ sample() [5/10]

virtual tmp<tensorField> sample ( const interpolation< tensor > & sampler ) const

pure virtual

Implemented in sampledIsoSurface, sampledMeshedSurface, sampledCuttingPlane, sampledDistanceSurface, sampledPatch, sampledPlane, sampledThresholdCellFaces, sampledFaceZone, sampledCuttingSurface, sampledInterface, sampledPatchInternalField, sampledMeshedSurfaceNormal, and sampledNone.

◆ withSurfaceFields()

bool withSurfaceFields ( ) const

virtual

Reimplemented in sampledPatch, and sampledFaceZone.

Definition at line 157 of file sampledSurface.C.

◆ sample() [6/10]

Foam::tmp< Foam::tensorField > sample ( const surfaceScalarField & sField ) const

virtual

Reimplemented in sampledPatch, sampledFaceZone, sampledPatch, sampledFaceZone, sampledPatch, sampledFaceZone, sampledPatch, sampledFaceZone, sampledPatch, and sampledFaceZone.

Definition at line 164 of file sampledSurface.C.

References NotImplemented.

◆ sample() [7/10]

virtual tmp<vectorField> sample ( const surfaceVectorField & sField ) const

virtual

Reimplemented in sampledPatch, sampledFaceZone, sampledPatch, sampledFaceZone, sampledPatch, sampledFaceZone, sampledPatch, sampledFaceZone, sampledPatch, and sampledFaceZone.

◆ sample() [8/10]

virtual tmp<sphericalTensorField> sample ( const surfaceSphericalTensorField & sField ) const

virtual

Reimplemented in sampledPatch, sampledFaceZone, sampledPatch, sampledFaceZone, sampledPatch, sampledFaceZone, sampledPatch, sampledFaceZone, sampledPatch, and sampledFaceZone.

◆ sample() [9/10]

virtual tmp<symmTensorField> sample ( const surfaceSymmTensorField & sField ) const

virtual

Reimplemented in sampledPatch, sampledFaceZone, sampledPatch, sampledFaceZone, sampledPatch, sampledFaceZone, sampledPatch, sampledFaceZone, sampledPatch, and sampledFaceZone.

◆ sample() [10/10]

virtual tmp<tensorField> sample ( const surfaceTensorField & sField ) const

virtual

Reimplemented in sampledPatch, sampledFaceZone, sampledPatch, sampledFaceZone, sampledPatch, sampledFaceZone, sampledPatch, sampledFaceZone, sampledPatch, and sampledFaceZone.

◆ interpolate() [1/6]

virtual tmp<scalarField> interpolate ( const interpolation< scalar > & interpolator ) const

pure virtual

Implemented in sampledIsoSurface, sampledMeshedSurface, sampledCuttingPlane, sampledPatch, sampledDistanceSurface, sampledFaceZone, sampledPlane, sampledThresholdCellFaces, sampledCuttingSurface, sampledInterface, sampledPatchInternalField, sampledMeshedSurfaceNormal, and sampledNone.

◆ interpolate() [2/6]

virtual tmp<vectorField> interpolate ( const interpolation< vector > & interpolator ) const

pure virtual

Implemented in sampledIsoSurface, sampledMeshedSurface, sampledCuttingPlane, sampledPatch, sampledDistanceSurface, sampledFaceZone, sampledPlane, sampledThresholdCellFaces, sampledCuttingSurface, sampledInterface, sampledMeshedSurfaceNormal, sampledPatchInternalField, and sampledNone.

◆ interpolate() [3/6]

virtual tmp<sphericalTensorField> interpolate ( const interpolation< sphericalTensor > & interpolator ) const

pure virtual

Implemented in sampledIsoSurface, sampledMeshedSurface, sampledCuttingPlane, sampledPatch, sampledDistanceSurface, sampledFaceZone, sampledPlane, sampledThresholdCellFaces, sampledCuttingSurface, sampledInterface, sampledMeshedSurfaceNormal, sampledPatchInternalField, and sampledNone.

◆ interpolate() [4/6]

virtual tmp<symmTensorField> interpolate ( const interpolation< symmTensor > & interpolator ) const

pure virtual

Implemented in sampledIsoSurface, sampledMeshedSurface, sampledCuttingPlane, sampledPatch, sampledDistanceSurface, sampledFaceZone, sampledPlane, sampledThresholdCellFaces, sampledCuttingSurface, sampledInterface, sampledMeshedSurfaceNormal, sampledPatchInternalField, and sampledNone.

◆ interpolate() [5/6]

virtual tmp<tensorField> interpolate ( const interpolation< tensor > & interpolator ) const

pure virtual

Implemented in sampledIsoSurface, sampledMeshedSurface, sampledCuttingPlane, sampledPatch, sampledDistanceSurface, sampledFaceZone, sampledPlane, sampledThresholdCellFaces, sampledCuttingSurface, sampledInterface, sampledMeshedSurfaceNormal, sampledPatchInternalField, and sampledNone.

◆ rename()

virtual void rename ( const word & newName )

inlinevirtual

Definition at line 579 of file sampledSurface.H.

◆ print()

void print	(	Ostream &	os,
		int	level = `0`
	)		const

virtual

Reimplemented in sampledIsoSurface, sampledMeshedSurface, sampledCuttingPlane, sampledPatch, sampledDistanceSurface, sampledFaceZone, sampledPlane, sampledThresholdCellFaces, sampledInterface, and sampledPatchInternalField.

Definition at line 213 of file sampledSurface.C.

References os(), and Foam::type().

Here is the call graph for this function:

◆ interpolate() [6/6]

bool interpolate ( ) const

inlinenoexcept

Definition at line 594 of file sampledSurface.H.

◆ sampleOnFaces() [2/2]

Foam::tmp<Foam::Field<Type> > sampleOnFaces	(	const interpolation< Type > &	sampler,
		const labelUList &	elements,
		const faceList &	fcs,
		const pointField &	pts,
		const Type &	defaultValue
	)

Definition at line 29 of file sampledSurfaceTemplates.C.

References Foam::exit(), Foam::FatalError, FatalErrorInFunction, interpolation::interpolate(), Foam::New(), UList::size(), and Foam::HashTableOps::values().

Here is the call graph for this function:

◆ sampleOnPoints() [2/2]

Foam::tmp<Foam::Field<Type> > sampleOnPoints	(	const interpolation< Type > &	interpolator,
		const labelUList &	elements,
		const faceList &	fcs,
		const pointField &	pts
	)

Definition at line 73 of file sampledSurfaceTemplates.C.

References Foam::exit(), f(), Foam::FatalError, FatalErrorInFunction, forAll, interpolation::interpolate(), Foam::New(), bitSet::set(), UList::size(), Foam::HashTableOps::values(), and Foam::Zero.

Here is the call graph for this function:

◆ pointAverage() [2/2]

Foam::tmp<Foam::GeometricField<Type, Foam::fvPatchField, Foam::volMesh> > pointAverage ( const GeometricField< Type, pointPatchField, pointMesh > & pfld )

Definition at line 123 of file sampledSurfaceTemplates.C.

References Foam::dimless, forAll, mesh, Foam::New(), and Foam::Zero.

Here is the call graph for this function:

Member Data Documentation

◆ surfaceFieldTypes

const Foam::wordList surfaceFieldTypes

static

Definition at line 126 of file sampledSurface.H.

The documentation for this class was generated from the following files:

src/sampling/sampledSurface/sampledSurface/sampledSurface.H
src/sampling/sampledSurface/sampledSurface/sampledSurface.C
src/sampling/sampledSurface/sampledSurface/sampledSurfaceRegister.C
src/sampling/sampledSurface/sampledSurface/sampledSurfaceTemplates.C

Classes

Public Member Functions

Static Public Member Functions

Static Public Attributes

Protected Member Functions

Static Protected Member Functions

Detailed Description

Constructor & Destructor Documentation

◆ sampledSurface() [1/3]

◆ sampledSurface() [2/3]

◆ sampledSurface() [3/3]

◆ ~sampledSurface()

Member Function Documentation

◆ sampleOnFaces() [1/2]

◆ sampleOnPoints() [1/2]

◆ pointAverage() [1/2]

◆ clearGeom()

◆ TypeName()

◆ declareRunTimeSelectionTable()

◆ clone()

◆ New()

◆ mesh()

◆ name()

◆ enabled()

◆ invariant()

◆ isPointData() [1/2]

◆ isPointData() [2/2]

◆ needsUpdate()

◆ expire()

◆ update()

◆ points()

◆ faces()

◆ Sf()

◆ magSf()

◆ Cf()

◆ area()

◆ hasFaceIds()

◆ getRegistrySurface()

◆ storeRegistrySurface()

◆ removeRegistrySurface()

◆ storeRegistryField() [1/2]

◆ storeRegistryField() [2/2]

◆ getSurfMesh()

◆ storeSurfMesh()

◆ removeSurfMesh()

◆ storeSurfMeshField() [1/2]

◆ storeSurfMeshField() [2/2]

◆ sample() [1/10]

◆ sample() [2/10]

◆ sample() [3/10]

◆ sample() [4/10]

◆ sample() [5/10]

◆ withSurfaceFields()

◆ sample() [6/10]

◆ sample() [7/10]

◆ sample() [8/10]

◆ sample() [9/10]

◆ sample() [10/10]

◆ interpolate() [1/6]

◆ interpolate() [2/6]

◆ interpolate() [3/6]

◆ interpolate() [4/6]

◆ interpolate() [5/6]

◆ rename()

◆ print()

◆ interpolate() [6/6]

◆ sampleOnFaces() [2/2]

◆ sampleOnPoints() [2/2]

◆ pointAverage() [2/2]

Member Data Documentation

◆ surfaceFieldTypes
