rotatingTotalPressureFvPatchScalarField Class Reference

This boundary condition provides a total pressure condition for patches in a rotating frame. More...

Inheritance diagram for rotatingTotalPressureFvPatchScalarField:

Collaboration diagram for rotatingTotalPressureFvPatchScalarField:

Public Member Functions
	TypeName ("rotatingTotalPressure")
	rotatingTotalPressureFvPatchScalarField (const fvPatch &, const DimensionedField< scalar, volMesh > &)
	rotatingTotalPressureFvPatchScalarField (const fvPatch &, const DimensionedField< scalar, volMesh > &, const dictionary &)
	rotatingTotalPressureFvPatchScalarField (const rotatingTotalPressureFvPatchScalarField &, const fvPatch &, const DimensionedField< scalar, volMesh > &, const fvPatchFieldMapper &)
	rotatingTotalPressureFvPatchScalarField (const rotatingTotalPressureFvPatchScalarField &)
virtual tmp< fvPatchScalarField >	clone () const
	rotatingTotalPressureFvPatchScalarField (const rotatingTotalPressureFvPatchScalarField &, const DimensionedField< scalar, volMesh > &)
virtual tmp< fvPatchScalarField >	clone (const DimensionedField< scalar, volMesh > &iF) const
virtual void	updateCoeffs ()
virtual void	write (Ostream &) const
Public Member Functions inherited from totalPressureFvPatchScalarField
	TypeName ("totalPressure")
	totalPressureFvPatchScalarField (const fvPatch &, const DimensionedField< scalar, volMesh > &)
	totalPressureFvPatchScalarField (const fvPatch &, const DimensionedField< scalar, volMesh > &, const dictionary &)
	totalPressureFvPatchScalarField (const totalPressureFvPatchScalarField &, const fvPatch &, const DimensionedField< scalar, volMesh > &, const fvPatchFieldMapper &)
	totalPressureFvPatchScalarField (const totalPressureFvPatchScalarField &)
	totalPressureFvPatchScalarField (const totalPressureFvPatchScalarField &, const DimensionedField< scalar, volMesh > &)
const word &	UName () const
word &	UName ()
const word &	phiName () const
word &	phiName ()
const word &	rhoName () const
word &	rhoName ()
const word &	psiName () const
word &	psiName ()
scalar	gamma () const
scalar &	gamma ()
const scalarField &	p0 () const
scalarField &	p0 ()
virtual void	autoMap (const fvPatchFieldMapper &)
virtual void	rmap (const fvPatchScalarField &, const labelList &)
virtual void	updateCoeffs (const scalarField &p0p, const vectorField &Up)

Detailed Description

This boundary condition provides a total pressure condition for patches in a rotating frame.

Usage

Property	Description	Required	Default value
U	velocity field name	no	U
phi	flux field name	no	phi
rho	density field name	no	none
psi	compressibility field name	no	none
gamma	ratio of specific heats (Cp/Cv)	yes
p0	static pressure reference	yes
omega	angular velocty of the frame [rad/s]	yes

Example of the boundary condition specification:

    <patchName>
    {
        type            rotatingTotalPressure;
        U               U;
        phi             phi;
        rho             rho;
        psi             psi;
        gamma           1.4;
        p0              uniform 1e5;
        omega           100;
    }

The omega entry is a Function1 type, able to describe time varying functions.

See also

Foam::totalPressureFvPatchScalarField Foam::Function1Types

Source files

• rotatingTotalPressureFvPatchScalarField.H
• rotatingTotalPressureFvPatchScalarField.C

Definition at line 125 of file rotatingTotalPressureFvPatchScalarField.H.

Constructor & Destructor Documentation

rotatingTotalPressureFvPatchScalarField() [1/5]

rotatingTotalPressureFvPatchScalarField	(	const fvPatch &	p,
		const DimensionedField< scalar, volMesh > &	iF
	)

Definition at line 32 of file rotatingTotalPressureFvPatchScalarField.C.

Referenced by rotatingTotalPressureFvPatchScalarField::clone().

Here is the caller graph for this function:

rotatingTotalPressureFvPatchScalarField() [2/5]

rotatingTotalPressureFvPatchScalarField	(	const fvPatch &	p,
		const DimensionedField< scalar, volMesh > &	iF,
		const dictionary &	dict
	)

Definition at line 58 of file rotatingTotalPressureFvPatchScalarField.C.

rotatingTotalPressureFvPatchScalarField() [3/5]

rotatingTotalPressureFvPatchScalarField	(	const rotatingTotalPressureFvPatchScalarField &	ptf,
		const fvPatch &	p,
		const DimensionedField< scalar, volMesh > &	iF,
		const fvPatchFieldMapper &	mapper
	)

Definition at line 44 of file rotatingTotalPressureFvPatchScalarField.C.

rotatingTotalPressureFvPatchScalarField() [4/5]

rotatingTotalPressureFvPatchScalarField

(

const rotatingTotalPressureFvPatchScalarField &

rtppsf

)

Definition at line 71 of file rotatingTotalPressureFvPatchScalarField.C.

rotatingTotalPressureFvPatchScalarField() [5/5]

rotatingTotalPressureFvPatchScalarField	(	const rotatingTotalPressureFvPatchScalarField &	rtppsf,
		const DimensionedField< scalar, volMesh > &	iF
	)

Definition at line 82 of file rotatingTotalPressureFvPatchScalarField.C.

Member Function Documentation

TypeName()

TypeName

(

"rotatingTotalPressure"

)

clone() [1/2]

virtual tmp<fvPatchScalarField> clone ( ) const

inlinevirtual

Reimplemented from totalPressureFvPatchScalarField.

Definition at line 175 of file rotatingTotalPressureFvPatchScalarField.H.

References rotatingTotalPressureFvPatchScalarField::rotatingTotalPressureFvPatchScalarField().

Here is the call graph for this function:

clone() [2/2]

virtual tmp<fvPatchScalarField> clone ( const DimensionedField< scalar, volMesh > &  iF ) const

inlinevirtual

Reimplemented from totalPressureFvPatchScalarField.

Definition at line 192 of file rotatingTotalPressureFvPatchScalarField.H.

References rotatingTotalPressureFvPatchScalarField::rotatingTotalPressureFvPatchScalarField().

Here is the call graph for this function:

updateCoeffs()

void updateCoeffs ( )

virtual

Reimplemented from totalPressureFvPatchScalarField.

Definition at line 94 of file rotatingTotalPressureFvPatchScalarField.C.

References Foam::mag(), om, totalPressureFvPatchScalarField::p0(), Foam::foamVersion::patch, totalPressureFvPatchScalarField::UName(), and totalPressureFvPatchScalarField::updateCoeffs().

Here is the call graph for this function:

write()

void write ( Ostream &  os ) const

virtual

Reimplemented from totalPressureFvPatchScalarField.

Definition at line 118 of file rotatingTotalPressureFvPatchScalarField.C.

References os(), and totalPressureFvPatchScalarField::write().

Here is the call graph for this function:

---

The documentation for this class was generated from the following files:

• src/finiteVolume/fields/fvPatchFields/derived/rotatingTotalPressure/rotatingTotalPressureFvPatchScalarField.H
• src/finiteVolume/fields/fvPatchFields/derived/rotatingTotalPressure/rotatingTotalPressureFvPatchScalarField.C
