removePoints Class Reference

Removes selected points from mesh and updates faces using these points. More...

Public Member Functions
	ClassName ("removePoints")
	removePoints (const polyMesh &mesh, const bool undoable=false)
const labelList &	savedFaceLabels () const
label	countPointUsage (const scalar minCos, boolList &pointCanBeDeleted) const
void	setRefinement (const boolList &, polyTopoChange &)
void	updateMesh (const mapPolyMesh &)
void	getUnrefimentSet (const labelList &undoFaces, labelList &localFaces, labelList &localPoints) const
void	setUnrefinement (const labelList &localFaces, const labelList &localPoints, polyTopoChange &)

Detailed Description

Removes selected points from mesh and updates faces using these points.

Source files

• removePoints.H
• removePoints.C

Definition at line 56 of file removePoints.H.

Constructor & Destructor Documentation

removePoints()

removePoints ( const polyMesh &  mesh, const bool  undoable = false  )

explicit

Definition at line 128 of file removePoints.C.

Member Function Documentation

ClassName()

ClassName

(

"removePoints"

)

savedFaceLabels()

const labelList& savedFaceLabels ( ) const

inline

Definition at line 111 of file removePoints.H.

Referenced by meshRefinement::doRemovePoints(), and meshRefinement::mergeEdgesUndo().

Here is the caller graph for this function:

countPointUsage()

Foam::label countPointUsage	(	const scalar	minCos,
		boolList &	pointCanBeDeleted
	)		const

Definition at line 141 of file removePoints.C.

References List::clear(), edge::commonVertex(), Foam::constant::electromagnetic::e, f(), forAll, Foam::normalised(), edge::otherVertex(), points, Foam::returnReduce(), List::setSize(), and syncTools::syncPointList().

Referenced by edgeCollapser::markMergeEdges(), and meshRefinement::mergeEdgesUndo().

Here is the call graph for this function:

Here is the caller graph for this function:

setRefinement()

void setRefinement	(	const boolList &	pointCanBeDeleted,
		polyTopoChange &	meshMod
	)

Definition at line 289 of file removePoints.C.

References Foam::abort(), Foam::expressions::patchExpr::debug, f(), Foam::FatalError, FatalErrorInFunction, forAll, HashSet::insert(), Foam::nl, pFaces, polyTopoChange::setAction(), and List::setSize().

Referenced by meshRefinement::doRemovePoints().

Here is the call graph for this function:

Here is the caller graph for this function:

updateMesh()

void updateMesh

(

const mapPolyMesh &

map

)

Definition at line 444 of file removePoints.C.

References Foam::abort(), Foam::expressions::patchExpr::debug, f(), Foam::FatalError, FatalErrorInFunction, forAll, Foam::nl, mapPolyMesh::reverseFaceMap(), mapPolyMesh::reversePointMap(), and List::setSize().

Referenced by meshRefinement::doRemovePoints(), and meshRefinement::doRestorePoints().

Here is the call graph for this function:

Here is the caller graph for this function:

getUnrefimentSet()

void getUnrefimentSet	(	const labelList &	undoFaces,
		labelList &	localFaces,
		labelList &	localPoints
	)		const

Definition at line 546 of file removePoints.C.

References Foam::abort(), Foam::expressions::patchExpr::debug, Foam::endl(), Foam::FatalError, FatalErrorInFunction, forAll, HashSet::insert(), VectorSpace< Vector< scalar >, scalar, 3 >::max, List::setSize(), faceSet::sync(), and syncTools::syncBoundaryFaceList().

Referenced by meshRefinement::doRestorePoints().

Here is the call graph for this function:

Here is the caller graph for this function:

setUnrefinement()

void setUnrefinement	(	const labelList &	localFaces,
		const labelList &	localPoints,
		polyTopoChange &	meshMod
	)

Definition at line 758 of file removePoints.C.

References Foam::abort(), Foam::expressions::patchExpr::debug, Foam::FatalError, FatalErrorInFunction, forAll, VectorSpace< Vector< scalar >, scalar, 3 >::max, polyTopoChange::setAction(), and List::setSize().

Referenced by meshRefinement::doRestorePoints().

Here is the call graph for this function:

Here is the caller graph for this function:

---

The documentation for this class was generated from the following files:

• src/dynamicMesh/polyTopoChange/polyTopoChange/removePoints.H
• src/dynamicMesh/polyTopoChange/polyTopoChange/removePoints.C
