Public Member Functions | Protected Attributes | List of all members
thixotropicViscosity Class Reference

Thixotropic viscosity model based on the evolution of the structural parameter $ \lambda $: More...

Inheritance diagram for thixotropicViscosity:
Inheritance graph
[legend]
Collaboration diagram for thixotropicViscosity:
Collaboration graph
[legend]

Public Member Functions

 TypeName ("thixotropic")

 thixotropicViscosity (surfaceFilmRegionModel &film, const dictionary &dict, volScalarField &mu)

virtual ~thixotropicViscosity ()

virtual void correct (const volScalarField &p, const volScalarField &T)

- Public Member Functions inherited from filmViscosityModel
 TypeName ("filmViscosityModel")

 declareRunTimeSelectionTable (autoPtr, filmViscosityModel, dictionary,(surfaceFilmRegionModel &film, const dictionary &dict, volScalarField &mu),(film, dict, mu))

 filmViscosityModel (const word &modelType, surfaceFilmRegionModel &film, const dictionary &dict, volScalarField &mu)

virtual ~filmViscosityModel ()

virtual void info (Ostream &os) const

- Public Member Functions inherited from filmSubModelBase
 filmSubModelBase (surfaceFilmRegionModel &film)

 filmSubModelBase (surfaceFilmRegionModel &film, const dictionary &dict, const word &baseName, const word &modelType, const word &dictExt="Coeffs")

 filmSubModelBase (const word &modelName, surfaceFilmRegionModel &film, const dictionary &dict, const word &baseName, const word &modelType)

virtual ~filmSubModelBase ()

virtual bool writeTime () const

const surfaceFilmRegionModel & film () const

surfaceFilmRegionModel & film ()

template<class FilmType >
const FilmType & filmType () const

- Public Member Functions inherited from subModelBase
 subModelBase (dictionary &properties)

 subModelBase (dictionary &properties, const dictionary &dict, const word &baseName, const word &modelType, const word &dictExt="Coeffs")

 subModelBase (const word &modelName, dictionary &properties, const dictionary &dict, const word &baseName, const word &modelType)

 subModelBase (const subModelBase &smb)

virtual ~subModelBase ()

const word & modelName () const

const dictionary & dict () const

const word & baseName () const

const word & modelType () const

const dictionary & coeffDict () const

const dictionary & properties () const

virtual bool defaultCoeffs (const bool printMsg) const

virtual bool active () const

virtual void cacheFields (const bool store)

virtual fileName localPath () const

template<class Type >
Type getBaseProperty (const word &entryName, const Type &defaultValue=Type(Zero)) const

template<class Type >
void getBaseProperty (const word &entryName, Type &value) const

template<class Type >
void setBaseProperty (const word &entryName, const Type &value)

bool getModelDict (const word &entryName, dictionary &dict) const

template<class Type >
void getModelProperty (const word &entryName, Type &value) const

template<class Type >
Type getModelProperty (const word &entryName, const Type &defaultValue=Type(Zero)) const

template<class Type >
void setModelProperty (const word &entryName, const Type &value)

virtual void write (Ostream &os) const


Protected Attributes

dimensionedScalar a_

dimensionedScalar b_

dimensionedScalar d_

dimensionedScalar c_

dimensionedScalar mu0_

dimensionedScalar muInf_

dimensionedScalar K_

volScalarField lambda_

- Protected Attributes inherited from filmViscosityModel
volScalarField & mu_

- Protected Attributes inherited from filmSubModelBase
surfaceFilmRegionModel & filmModel_

- Protected Attributes inherited from subModelBase
const word modelName_

dictionary & properties_

const dictionary dict_

const word baseName_

const word modelType_

const dictionary coeffDict_


Additional Inherited Members

- Static Public Member Functions inherited from filmViscosityModel
static autoPtr< filmViscosityModel > New (surfaceFilmRegionModel &film, const dictionary &dict, volScalarField &mu)

- Protected Member Functions inherited from subModelBase
bool inLine () const


Detailed Description

Thixotropic viscosity model based on the evolution of the structural parameter $ \lambda $:

\[ \lambda = a(1 - \lambda)^b - c \lambda \dot{\gamma}^d \]

The viscosity is then calculated using the expression

\[ \mu = \frac{\mu_{\infty}}{{1 - K \lambda}^2} \]

Where the parameter K is given by:

\[ K = 1 - \sqrt{\frac{\mu_{\infty}}{\mu_{0}}} \]

Here:

$ \lambda $ = structural parameter
$ a $ = model coefficient
$ b $ = model coefficient
$ c $ = model coefficient
$ d $ = model coefficient
$ \dot{\gamma} $ = stress rate [1/s]
$ \mu_{0} $ = limiting viscosity when $ \lambda = 1 $
$ \mu_{\infty} $ = limiting viscosity when $ \lambda = 0 $

Reference:

        Barnes H A, 1997.  Thixotropy - a review.  J. Non-Newtonian Fluid
        Mech 70, pp 1-33
Source files

Definition at line 117 of file thixotropicViscosity.H.

Constructor & Destructor Documentation

◆ thixotropicViscosity()

thixotropicViscosity ( surfaceFilmRegionModel &  film,
const dictionary &  dict,
volScalarField &  mu
)

Definition at line 54 of file thixotropicViscosity.C.

◆ ~thixotropicViscosity()

~thixotropicViscosity ( )
virtual

Definition at line 92 of file thixotropicViscosity.C.

Member Function Documentation

◆ TypeName()

TypeName ( "thixotropic"  )

◆ correct()

void correct ( const volScalarField &  p,
const volScalarField &  T
)
virtual

Implements filmViscosityModel.

Definition at line 99 of file thixotropicViscosity.C.

References Foam::constant::atomic::alpha, kinematicSingleLayer::alpha(), Foam::fvm::ddt(), Foam::expressions::patchExpr::debug, delta, kinematicSingleLayer::delta(), kinematicSingleLayer::deltaRho(), kinematicSingleLayer::deltaSmall(), Foam::dimless, Foam::dimTime, Foam::fvm::div(), Foam::fvc::div(), Foam::fvc::interpolate(), Foam::mag(), Foam::max(), phi, kinematicSingleLayer::phi(), Foam::pow(), regionModel::regionMesh(), fvMatrix::relax(), kinematicSingleLayer::rhoSp(), runTime, fvMatrix::solve(), Foam::fvm::Sp(), Foam::sqr(), Foam::fvm::SuSp(), fvMesh::time(), U, kinematicSingleLayer::U(), kinematicSingleLayer::Uw(), and Foam::Zero.

Here is the call graph for this function:

Member Data Documentation

◆ a_

dimensionedScalar a_
protected

Definition at line 135 of file thixotropicViscosity.H.

◆ b_

dimensionedScalar b_
protected

Definition at line 138 of file thixotropicViscosity.H.

◆ d_

dimensionedScalar d_
protected

Definition at line 141 of file thixotropicViscosity.H.

◆ c_

dimensionedScalar c_
protected

Definition at line 144 of file thixotropicViscosity.H.

◆ mu0_

dimensionedScalar mu0_
protected

Definition at line 147 of file thixotropicViscosity.H.

◆ muInf_

dimensionedScalar muInf_
protected

Definition at line 150 of file thixotropicViscosity.H.

◆ K_

dimensionedScalar K_
protected

Definition at line 153 of file thixotropicViscosity.H.

◆ lambda_

volScalarField lambda_
protected

Definition at line 158 of file thixotropicViscosity.H.

The documentation for this class was generated from the following files:
