refinementFeatures Class Reference

Encapsulates queries for features. More...

Inheritance diagram for refinementFeatures:

Collaboration diagram for refinementFeatures:

Public Member Functions
	refinementFeatures (const objectRegistry &io, const PtrList< dictionary > &featDicts, const bool dryRun=false)
const labelListList &	levels () const
const List< scalarField > &	distances () const
scalar	maxDistance () const
void	findNearestEdge (const pointField &samples, const scalarField &nearestDistSqr, labelList &nearFeature, List< pointIndexHit > &nearInfo, vectorField &nearNormal) const
void	findNearestRegionEdge (const pointField &samples, const scalarField &nearestDistSqr, labelList &nearFeature, List< pointIndexHit > &nearInfo, vectorField &nearNormal) const
void	findNearestPoint (const pointField &samples, const scalarField &nearestDistSqr, labelList &nearFeature, List< pointIndexHit > &nearInfo) const
void	findHigherLevel (const pointField &pt, const labelList &ptLevel, labelList &maxLevel) const
bool	checkSizes (const scalar maxRatio, const boundBox &meshBb, const bool report, Ostream &os) const
Public Member Functions inherited from PtrList< extendedFeatureEdgeMesh >
constexpr	PtrList () noexcept
	PtrList (const label len)
	PtrList (const PtrList< T > &list)
	PtrList (PtrList< T > &&list)
	PtrList (UList< T * > &list)
	PtrList (const PtrList< T > &list, const CloneArg &cloneArgs)
	PtrList (PtrList< T > &list, bool reuse)
	PtrList (const SLPtrList< T > &list)
	PtrList (Istream &is, const INew &inew)
	PtrList (Istream &is)
	PtrList (PtrList< T > &list, bool reuse)
	PtrList (const SLPtrList< T > &list)
constexpr	PtrList () noexcept
	PtrList (const label len)
	PtrList (const PtrList< T > &list)
	PtrList (PtrList< T > &&list)
	PtrList (UList< T * > &list)
	PtrList (Istream &is)
	~PtrList ()
PtrList< T >	clone (Args &&... args) const
Foam::PtrList< T >	clone (Args &&... args) const
const T *	set (const label i) const
autoPtr< T >	set (const label i, T *ptr)
autoPtr< T >	set (const label i, autoPtr< T > &ptr)
autoPtr< T >	set (const label i, autoPtr< T > &&ptr)
autoPtr< T >	set (const label i, std::unique_ptr< T > &&ptr)
autoPtr< T >	set (const label i, const refPtr< T > &ptr)
autoPtr< T >	set (const label i, const tmp< T > &ptr)
void	clear ()
void	resize (const label newLen)
void	setSize (const label newLen)
void	emplace_append (Args &&... args)
void	append (T *ptr)
void	append (autoPtr< T > &ptr)
void	append (autoPtr< T > &&ptr)
void	append (std::unique_ptr< T > &&ptr)
void	append (const refPtr< T > &ptr)
void	append (const tmp< T > &ptr)
autoPtr< T >	emplace (const label i, Args &&... args)
Foam::autoPtr< T >	emplace (const label i, Args &&... args)
autoPtr< T >	release (const label i)
void	transfer (PtrList< T > &list)
void	operator= (const PtrList< T > &list)
void	operator= (PtrList< T > &&list)

Protected Member Functions
const PtrList< indexedOctree< treeDataEdge > > &	edgeTrees () const
const PtrList< indexedOctree< treeDataPoint > > &	pointTrees () const
const PtrList< indexedOctree< treeDataEdge > > &	regionEdgeTrees () const
Protected Member Functions inherited from PtrList< extendedFeatureEdgeMesh >
void	readIstream (Istream &is, const INew &inew)
void	free ()

Detailed Description

Encapsulates queries for features.

Source files

• refinementFeatures.H
• refinementFeatures.C

Definition at line 49 of file refinementFeatures.H.

Constructor & Destructor Documentation

refinementFeatures()

refinementFeatures	(	const objectRegistry &	io,
		const PtrList< dictionary > &	featDicts,
		const bool	dryRun = false
	)

Definition at line 466 of file refinementFeatures.C.

References forAll, and Foam::read().

Here is the call graph for this function:

Member Function Documentation

edgeTrees()

const PtrList<indexedOctree<treeDataEdge> >& edgeTrees ( ) const

inlineprotected

Definition at line 94 of file refinementFeatures.H.

pointTrees()

const PtrList<indexedOctree<treeDataPoint> >& pointTrees ( ) const

inlineprotected

Definition at line 99 of file refinementFeatures.H.

regionEdgeTrees()

const Foam::PtrList< Foam::indexedOctree< Foam::treeDataEdge > > & regionEdgeTrees ( ) const

protected

Definition at line 410 of file refinementFeatures.C.

References Foam::constant::electromagnetic::e, edgeMesh::edges(), treeBoundBox::extend(), forAll, boundBox::max(), boundBox::min(), points, edgeMesh::points(), extendedEdgeMesh::regionEdges(), rndGen, PtrList::set(), and VectorSpace< Vector< scalar >, scalar, 3 >::uniform().

Here is the call graph for this function:

levels()

const labelListList& levels ( ) const

inline

Definition at line 125 of file refinementFeatures.H.

distances()

const List<scalarField>& distances ( ) const

inline

Definition at line 131 of file refinementFeatures.H.

maxDistance()

Foam::scalar maxDistance

(

)

const

Definition at line 874 of file refinementFeatures.C.

References forAll, and Foam::max().

Here is the call graph for this function:

findNearestEdge()

void findNearestEdge	(	const pointField &	samples,
		const scalarField &	nearestDistSqr,
		labelList &	nearFeature,
		List< pointIndexHit > &	nearInfo,
		vectorField &	nearNormal
	)		const

Definition at line 633 of file refinementFeatures.C.

References Foam::constant::electromagnetic::e, treeDataEdge::edges(), forAll, PointIndexHit::hit(), PointIndexHit::hitPoint(), PointIndexHit::index(), Foam::magSqr(), treeDataEdge::points(), samples(), List::setSize(), indexedOctree::shapes(), and Foam::Zero.

Here is the call graph for this function:

findNearestRegionEdge()

void findNearestRegionEdge	(	const pointField &	samples,
		const scalarField &	nearestDistSqr,
		labelList &	nearFeature,
		List< pointIndexHit > &	nearInfo,
		vectorField &	nearNormal
	)		const

Definition at line 692 of file refinementFeatures.C.

References Foam::constant::electromagnetic::e, treeDataEdge::edges(), forAll, PointIndexHit::hit(), PointIndexHit::hitPoint(), PointIndexHit::index(), Foam::magSqr(), treeDataEdge::points(), samples(), List::setSize(), indexedOctree::shapes(), and Foam::Zero.

Here is the call graph for this function:

findNearestPoint()

void findNearestPoint	(	const pointField &	samples,
		const scalarField &	nearestDistSqr,
		labelList &	nearFeature,
		List< pointIndexHit > &	nearInfo
	)		const

Definition at line 807 of file refinementFeatures.C.

References forAll, PointIndexHit::hit(), PointIndexHit::hitPoint(), PointIndexHit::index(), Foam::magSqr(), samples(), List::setSize(), and indexedOctree::shapes().

Here is the call graph for this function:

findHigherLevel()

void findHigherLevel	(	const pointField &	pt,
		const labelList &	ptLevel,
		labelList &	maxLevel
	)		const

Definition at line 858 of file refinementFeatures.C.

References forAll.

checkSizes()

bool checkSizes	(	const scalar	maxRatio,
		const boundBox &	meshBb,
		const bool	report,
		Ostream &	os
	)		const

Definition at line 563 of file refinementFeatures.C.

References Foam::endl(), forAll, boundBox::mag(), meshBb(), IOobject::name(), Foam::nl, os(), edgeMesh::points(), and Foam::returnReduce().

Here is the call graph for this function:

---

The documentation for this class was generated from the following files:

• src/mesh/snappyHexMesh/refinementFeatures/refinementFeatures.H
• src/mesh/snappyHexMesh/refinementFeatures/refinementFeatures.C
