blackBodyEmission Class Reference

Class black body emission. More...

Collaboration diagram for blackBodyEmission:

Public Member Functions
	blackBodyEmission (const label nLambda, const volScalarField &T)
	~blackBodyEmission ()
const volScalarField &	bLambda (const label lambdaI) const
dimensionedScalar	EblambdaT (const dimensionedScalar &T, const scalar lambda) const
tmp< Foam::volScalarField >	deltaLambdaT (const volScalarField &T, const Vector2D< scalar > &band) const
tmp< Foam::volScalarField >	EbDeltaLambdaT (const volScalarField &T, const Vector2D< scalar > &band) const
void	correct (const label lambdaI, const Vector2D< scalar > &band)

Static Public Attributes
static const List< Tuple2< scalar, scalar > >	emissivePowerTable

Detailed Description

Class black body emission.

Table of black body emissive power from: Modest, "Radiative Heat Transfer", pp.775-777, 1993

Source files

• blackBodyEmission.H
• blackBodyEmission.C

Definition at line 54 of file blackBodyEmission.H.

Constructor & Destructor Documentation

blackBodyEmission()

blackBodyEmission	(	const label	nLambda,
		const volScalarField &	T
	)

Definition at line 134 of file blackBodyEmission.C.

References forAll, Foam::name(), IOobject::NO_READ, IOobject::NO_WRITE, Foam::pow4(), Foam::constant::physicoChemical::sigma, and Foam::T().

Here is the call graph for this function:

~blackBodyEmission()

~blackBodyEmission

(

)

Definition at line 175 of file blackBodyEmission.C.

Member Function Documentation

bLambda()

const volScalarField& bLambda ( const label  lambdaI ) const

inline

Definition at line 108 of file blackBodyEmission.H.

EblambdaT()

dimensionedScalar EblambdaT ( const dimensionedScalar &  T, const scalar  lambda  ) const

inline

Definition at line 115 of file blackBodyEmission.H.

References Foam::exp(), lambda(), Foam::pow5(), and Foam::T().

Here is the call graph for this function:

deltaLambdaT()

Foam::tmp< Foam::volScalarField > deltaLambdaT	(	const volScalarField &	T,
		const Vector2D< scalar > &	band
	)		const

Definition at line 192 of file blackBodyEmission.C.

References Foam::dimless, forAll, IOobject::NO_READ, IOobject::NO_WRITE, tmp::ref(), and Foam::T().

Here is the call graph for this function:

EbDeltaLambdaT()

Foam::tmp< Foam::volScalarField > EbDeltaLambdaT	(	const volScalarField &	T,
		const Vector2D< scalar > &	band
	)		const

Definition at line 230 of file blackBodyEmission.C.

References fvPatchField::coupled(), forAll, IOobject::NO_READ, IOobject::NO_WRITE, Foam::pow4(), tmp::ref(), Foam::constant::physicoChemical::sigma, and Foam::T().

Here is the call graph for this function:

correct()

void correct	(	const label	lambdaI,
		const Vector2D< scalar > &	band
	)

Definition at line 286 of file blackBodyEmission.C.

Member Data Documentation

emissivePowerTable

const Foam::List< Foam::Tuple2< Foam::scalar, Foam::scalar > > emissivePowerTable

static

Definition at line 59 of file blackBodyEmission.H.

---

The documentation for this class was generated from the following files:

• src/thermophysicalModels/radiation/radiationModels/fvDOM/blackBodyEmission/blackBodyEmission.H
• src/thermophysicalModels/radiation/radiationModels/fvDOM/blackBodyEmission/blackBodyEmission.C
