profileModel Class Reference

Base class for profile models for handling aerofoil lift and drag polar diagrams. More...

Inheritance diagram for profileModel:

Collaboration diagram for profileModel:

Public Member Functions
	TypeName ("profileModel")
	declareRunTimeSelectionTable (autoPtr, profileModel, dictionary,(const dictionary &dict, const word &modelName),(dict, modelName))
	profileModel (const dictionary &dict, const word &modelName)
virtual	~profileModel ()=default
const word &	name () const
virtual void	Cdl (const scalar alpha, scalar &Cd, scalar &Cl) const =0

Static Public Member Functions
static autoPtr< profileModel >	New (const dictionary &dict)

Protected Member Functions
bool	readFromFile () const

Protected Attributes
const dictionary	dict_
const word	name_
fileName	fName_

Detailed Description

Base class for profile models for handling aerofoil lift and drag polar diagrams.

Usage

Minimal example by using constant/fvOptions: rotorDiskSource1 { Mandatory/Optional (inherited) entries ...

Mandatory entries (runtime modifiable) profiles { Mandatory entries (runtime modifiable) <profile1> { type <profileModel>;

Mandatory/Optional (inherited) entries ... } ... <profileN> { ... }

Optional entries (runtime modifiable) file <fileName>; } }

where the entries mean:

Property	Description	Type	Reqd	Dflt
type	Profile model - see below	word	yes	-
file	Name of file containing profile characteristics	word	no	-

Options for the type entry:

      lookup    | Polar data is linearly interpolated based on angle of attack
      series    | Polar data is computed as sum of cosine series

See also

• Foam::fv::rotorDiskSource
• Foam::lookupProfile
• Foam::seriesProfile

Source files

• profileModel.H
• profileModel.C
• profileModelList.C

Definition at line 116 of file profileModel.H.

Constructor & Destructor Documentation

profileModel()

profileModel	(	const dictionary &	dict,
		const word &	modelName
	)

Definition at line 44 of file profileModel.C.

~profileModel()

virtual ~profileModel ( )

virtualdefault

Member Function Documentation

readFromFile()

bool readFromFile ( ) const

protected

Definition at line 36 of file profileModel.C.

References profileModel::fName_.

TypeName()

TypeName

(

"profileModel"

)

declareRunTimeSelectionTable()

declareRunTimeSelectionTable	(	autoPtr	,
		profileModel	,
		dictionary	,
		(const dictionary &dict, const word &modelName)	,
		(dict, modelName)
	)

New()

Foam::autoPtr< Foam::profileModel > New ( const dictionary &  dict )

static

Definition at line 61 of file profileModel.C.

References dict, dictionary::dictName(), Foam::endl(), Foam::exit(), Foam::FatalIOError, FatalIOErrorInLookup, dictionary::get(), and Foam::Info.

Here is the call graph for this function:

name()

const Foam::word & name

(

)

const

Definition at line 54 of file profileModel.C.

Referenced by profileModelList::connectBlades().

Here is the caller graph for this function:

Cdl()

virtual void Cdl ( const scalar  alpha, scalar &  Cd, scalar &  Cl  ) const

pure virtual

Implemented in seriesProfile, and lookupProfile.

Member Data Documentation

dict_

const dictionary dict_

protected

Definition at line 123 of file profileModel.H.

name_

const word name_

protected

Definition at line 126 of file profileModel.H.

fName_

fileName fName_

protected

Definition at line 129 of file profileModel.H.

Referenced by profileModel::readFromFile().

---

The documentation for this class was generated from the following files:

• src/fvOptions/sources/derived/rotorDiskSource/profileModel/profileModel.H
• src/fvOptions/sources/derived/rotorDiskSource/profileModel/profileModel.C
