processorLduInterfaceField Class Reference

Abstract base class for processor coupled interfaces. More...

Inheritance diagram for processorLduInterfaceField:

Public Member Functions
	TypeName ("processorLduInterfaceField")
	processorLduInterfaceField ()=default
virtual	~processorLduInterfaceField ()=default
virtual label	comm () const =0
virtual int	myProcNo () const =0
virtual int	neighbProcNo () const =0
virtual bool	doTransform () const =0
virtual const tensorField &	forwardT () const =0
virtual int	rank () const =0
template<class Type >
void	transformCoupleField (Field< Type > &f) const
void	transformCoupleField (solveScalarField &f, const direction cmpt) const

Detailed Description

Abstract base class for processor coupled interfaces.

Source files

• processorLduInterfaceField.H
• processorLduInterfaceField.C

Definition at line 48 of file processorLduInterfaceField.H.

Constructor & Destructor Documentation

processorLduInterfaceField()

processorLduInterfaceField ( )

default

~processorLduInterfaceField()

virtual ~processorLduInterfaceField ( )

virtualdefault

Member Function Documentation

TypeName()

TypeName

(

"processorLduInterfaceField"

)

comm()

virtual label comm ( ) const

pure virtual

Implemented in processorFvPatchField< Type >, processorFaPatchField< Type >, processorGAMGInterfaceField, calculatedProcessorGAMGInterfaceField, and calculatedProcessorFvPatchField< Type >.

myProcNo()

virtual int myProcNo ( ) const

pure virtual

Implemented in processorFvPatchField< Type >, processorFaPatchField< Type >, processorGAMGInterfaceField, calculatedProcessorGAMGInterfaceField, and calculatedProcessorFvPatchField< Type >.

neighbProcNo()

virtual int neighbProcNo ( ) const

pure virtual

Implemented in processorFvPatchField< Type >, processorFaPatchField< Type >, processorGAMGInterfaceField, calculatedProcessorFvPatchField< Type >, and calculatedProcessorGAMGInterfaceField.

doTransform()

virtual bool doTransform ( ) const

pure virtual

Implemented in processorFvPatchField< Type >, processorFaPatchField< Type >, processorGAMGInterfaceField, calculatedProcessorFvPatchField< Type >, calculatedProcessorGAMGInterfaceField, and processorCyclicFvPatchField< Type >.

forwardT()

virtual const tensorField& forwardT ( ) const

pure virtual

Implemented in processorFvPatchField< Type >, processorFaPatchField< Type >, processorGAMGInterfaceField, calculatedProcessorFvPatchField< Type >, calculatedProcessorGAMGInterfaceField, and processorCyclicFvPatchField< Type >.

rank()

virtual int rank ( ) const

pure virtual

Implemented in processorFvPatchField< Type >, processorFaPatchField< Type >, processorGAMGInterfaceField, calculatedProcessorFvPatchField< Type >, and calculatedProcessorGAMGInterfaceField.

transformCoupleField() [1/2]

void transformCoupleField

(

Field< Type > &

f

)

const

Definition at line 113 of file processorLduInterfaceField.H.

References f(), and Foam::transform().

Referenced by processorFaPatchField< Type >::transformCoupleField().

Here is the call graph for this function:

Here is the caller graph for this function:

transformCoupleField() [2/2]

void transformCoupleField	(	solveScalarField &	f,
		const direction	cmpt
	)		const

Definition at line 36 of file processorLduInterfaceField.C.

References Foam::component(), Foam::diag(), f(), and Foam::pow().

Here is the call graph for this function:

---

The documentation for this class was generated from the following files:

• src/OpenFOAM/matrices/lduMatrix/lduAddressing/lduInterfaceFields/processorLduInterfaceField/processorLduInterfaceField.H
• src/OpenFOAM/matrices/lduMatrix/lduAddressing/lduInterfaceFields/processorLduInterfaceField/processorLduInterfaceField.C
