pressureInletOutletParSlipVelocityFvPatchVectorField Class Reference

This velocity inlet/outlet boundary condition for pressure boundary where the pressure is specified. A zero-gradient is applied for outflow (as defined by the flux); for inflow, the velocity is obtained from the flux with the specified inlet direction. More...

Inheritance diagram for pressureInletOutletParSlipVelocityFvPatchVectorField:

Collaboration diagram for pressureInletOutletParSlipVelocityFvPatchVectorField:

Public Member Functions
	TypeName ("pressureInletOutletParSlipVelocity")
	pressureInletOutletParSlipVelocityFvPatchVectorField (const fvPatch &, const DimensionedField< vector, volMesh > &)
	pressureInletOutletParSlipVelocityFvPatchVectorField (const pressureInletOutletParSlipVelocityFvPatchVectorField &, const fvPatch &, const DimensionedField< vector, volMesh > &, const fvPatchFieldMapper &)
	pressureInletOutletParSlipVelocityFvPatchVectorField (const fvPatch &, const DimensionedField< vector, volMesh > &, const dictionary &)
	pressureInletOutletParSlipVelocityFvPatchVectorField (const pressureInletOutletParSlipVelocityFvPatchVectorField &)
virtual tmp< fvPatchVectorField >	clone () const
	pressureInletOutletParSlipVelocityFvPatchVectorField (const pressureInletOutletParSlipVelocityFvPatchVectorField &, const DimensionedField< vector, volMesh > &)
virtual tmp< fvPatchVectorField >	clone (const DimensionedField< vector, volMesh > &iF) const
virtual bool	assignable () const
const word &	rhoName () const
word &	rhoName ()
const word &	phiName () const
word &	phiName ()
virtual void	updateCoeffs ()
virtual void	write (Ostream &) const
virtual void	operator= (const fvPatchField< vector > &pvf)

Detailed Description

This velocity inlet/outlet boundary condition for pressure boundary where the pressure is specified. A zero-gradient is applied for outflow (as defined by the flux); for inflow, the velocity is obtained from the flux with the specified inlet direction.

A slip condition is applied tangential to the patch.

Usage

Property	Description	Required	Default value
phi	flux field name	no	phi
rho	density field name	no	rho

Example of the boundary condition specification:

    <patchName>
    {
        type            pressureInletOutletParSlipVelocity;
        value           uniform 0;
    }

Note

Sign conventions:

• positive flux (out of domain): apply zero-gradient condition
• negative flux (into of domain): derive from the flux with specified direction

See also

Foam::mixedFvPatchVectorField Foam::pressureDirectedInletOutletVelocityFvPatchVectorField

Source files

• pressureInletOutletParSlipVelocityFvPatchVectorField.H
• pressureInletOutletParSlipVelocityFvPatchVectorField.C

Definition at line 96 of file pressureInletOutletParSlipVelocityFvPatchVectorField.H.

Constructor & Destructor Documentation

pressureInletOutletParSlipVelocityFvPatchVectorField() [1/5]

pressureInletOutletParSlipVelocityFvPatchVectorField	(	const fvPatch &	p,
		const DimensionedField< vector, volMesh > &	iF
	)

Definition at line 33 of file pressureInletOutletParSlipVelocityFvPatchVectorField.C.

References Foam::Zero.

pressureInletOutletParSlipVelocityFvPatchVectorField() [2/5]

pressureInletOutletParSlipVelocityFvPatchVectorField	(	const pressureInletOutletParSlipVelocityFvPatchVectorField &	ptf,
		const fvPatch &	p,
		const DimensionedField< vector, volMesh > &	iF,
		const fvPatchFieldMapper &	mapper
	)

Definition at line 50 of file pressureInletOutletParSlipVelocityFvPatchVectorField.C.

pressureInletOutletParSlipVelocityFvPatchVectorField() [3/5]

pressureInletOutletParSlipVelocityFvPatchVectorField	(	const fvPatch &	p,
		const DimensionedField< vector, volMesh > &	iF,
		const dictionary &	dict
	)

Definition at line 65 of file pressureInletOutletParSlipVelocityFvPatchVectorField.C.

References dict, p, and Foam::Zero.

pressureInletOutletParSlipVelocityFvPatchVectorField() [4/5]

pressureInletOutletParSlipVelocityFvPatchVectorField

(

const pressureInletOutletParSlipVelocityFvPatchVectorField &

pivpvf

)

Definition at line 85 of file pressureInletOutletParSlipVelocityFvPatchVectorField.C.

pressureInletOutletParSlipVelocityFvPatchVectorField() [5/5]

pressureInletOutletParSlipVelocityFvPatchVectorField	(	const pressureInletOutletParSlipVelocityFvPatchVectorField &	pivpvf,
		const DimensionedField< vector, volMesh > &	iF
	)

Definition at line 97 of file pressureInletOutletParSlipVelocityFvPatchVectorField.C.

Member Function Documentation

TypeName()

TypeName

(

"pressureInletOutletParSlipVelocity"

)

clone() [1/2]

virtual tmp<fvPatchVectorField> clone ( ) const

inlinevirtual

Definition at line 150 of file pressureInletOutletParSlipVelocityFvPatchVectorField.H.

clone() [2/2]

virtual tmp<fvPatchVectorField> clone ( const DimensionedField< vector, volMesh > &  iF ) const

inlinevirtual

Definition at line 170 of file pressureInletOutletParSlipVelocityFvPatchVectorField.H.

assignable()

virtual bool assignable ( ) const

inlinevirtual

Definition at line 190 of file pressureInletOutletParSlipVelocityFvPatchVectorField.H.

rhoName() [1/2]

const word& rhoName ( ) const

inline

Definition at line 199 of file pressureInletOutletParSlipVelocityFvPatchVectorField.H.

rhoName() [2/2]

word& rhoName ( )

inline

Definition at line 205 of file pressureInletOutletParSlipVelocityFvPatchVectorField.H.

phiName() [1/2]

const word& phiName ( ) const

inline

Definition at line 211 of file pressureInletOutletParSlipVelocityFvPatchVectorField.H.

phiName() [2/2]

word& phiName ( )

inline

Definition at line 217 of file pressureInletOutletParSlipVelocityFvPatchVectorField.H.

updateCoeffs()

void updateCoeffs ( )

virtual

Definition at line 110 of file pressureInletOutletParSlipVelocityFvPatchVectorField.C.

References Foam::dimArea, Foam::dimDensity, Foam::dimVelocity, Foam::exit(), Foam::FatalError, FatalErrorInFunction, n, Foam::nl, Foam::foamVersion::patch, phi, and Foam::pos0().

Here is the call graph for this function:

write()

void write ( Ostream &  os ) const

virtual

Definition at line 158 of file pressureInletOutletParSlipVelocityFvPatchVectorField.C.

References os(), fvPatchField::write(), and Ostream::writeEntryIfDifferent().

Here is the call graph for this function:

operator=()

void operator= ( const fvPatchField< vector > &  pvf )

virtual

Definition at line 172 of file pressureInletOutletParSlipVelocityFvPatchVectorField.C.

References fvPatchField::operator=().

Here is the call graph for this function:

---

The documentation for this class was generated from the following files:

• src/finiteVolume/fields/fvPatchFields/derived/pressureInletOutletParSlipVelocity/pressureInletOutletParSlipVelocityFvPatchVectorField.H
• src/finiteVolume/fields/fvPatchFields/derived/pressureInletOutletParSlipVelocity/pressureInletOutletParSlipVelocityFvPatchVectorField.C
