polyPatch Class Reference

A patch is a list of labels that address the faces in the global face list. More...

Inheritance diagram for polyPatch:

Collaboration diagram for polyPatch:

Public Member Functions
	TypeName ("patch")
	declareRunTimeSelectionTable (autoPtr, polyPatch, word,(const word &name, const label size, const label start, const label index, const polyBoundaryMesh &bm, const word &patchType),(name, size, start, index, bm, patchType))
	declareRunTimeSelectionTable (autoPtr, polyPatch, dictionary,(const word &name, const dictionary &dict, const label index, const polyBoundaryMesh &bm, const word &patchType),(name, dict, index, bm, patchType))
	polyPatch (const word &name, const label size, const label start, const label index, const polyBoundaryMesh &bm, const word &patchType)
	polyPatch (const word &name, const label size, const label start, const label index, const polyBoundaryMesh &bm, const word &physicalType, const wordList &inGroups)
	polyPatch (const word &name, const dictionary &dict, const label index, const polyBoundaryMesh &bm, const word &patchType)
	polyPatch (const polyPatch &, const polyBoundaryMesh &)
	polyPatch (const polyPatch &pp, const polyBoundaryMesh &bm, const label index, const label newSize, const label newStart)
	polyPatch (const polyPatch &pp, const polyBoundaryMesh &bm, const label index, const labelUList &mapAddressing, const label newStart)
	polyPatch (const polyPatch &p)
	polyPatch (const polyPatch &p, const labelList &faceCells)
virtual autoPtr< polyPatch >	clone (const labelList &faceCells) const
virtual autoPtr< polyPatch >	clone (const polyBoundaryMesh &bm) const
virtual autoPtr< polyPatch >	clone (const polyBoundaryMesh &bm, const label index, const label newSize, const label newStart) const
virtual autoPtr< polyPatch >	clone (const polyBoundaryMesh &bm, const label index, const labelUList &mapAddressing, const label newStart) const
virtual	~polyPatch ()
virtual void	newInternalProcFaces (label &, label &) const
virtual const labelUList &	nbrCells () const
virtual label	neighbPolyPatchID () const
virtual refPtr< labelListList >	mapCollocatedFaces () const
virtual bool	masterImplicit () const
virtual word	neighbRegionID () const
label	offset () const
label	start () const
labelRange	range () const
const polyBoundaryMesh &	boundaryMesh () const
virtual bool	coupled () const
template<class T >
const UIndirectList< T >	patchInternalList (const UList< T > &internalValues) const
template<class T >
const List< T >::subList	patchSlice (const UList< T > &l) const
template<class T >
const Field< T >::subField	patchSlice (const Field< T > &l) const
virtual void	write (Ostream &os) const
const vectorField::subField	faceCentres () const
const vectorField::subField	faceAreas () const
tmp< vectorField >	faceCellCentres () const
tmp< scalarField >	areaFraction () const
const labelUList &	faceCells () const
const labelList &	meshEdges () const
virtual void	clearAddressing ()
label	whichFace (const label l) const
virtual void	initOrder (PstreamBuffers &, const primitivePatch &) const
virtual bool	order (PstreamBuffers &, const primitivePatch &, labelList &faceMap, labelList &rotation) const
virtual bool	changeTopology () const
virtual bool	setTopology (polyTopoChange &)
void	operator= (const polyPatch &)
Public Member Functions inherited from patchIdentifier
	patchIdentifier (const patchIdentifier &)=default
patchIdentifier &	operator= (const patchIdentifier &)=default
virtual	~patchIdentifier ()=default
	patchIdentifier ()
	patchIdentifier (const word &name, const label index)
	patchIdentifier (const word &name, const label index, const word &physicalType, const wordList &inGroups=wordList())
	patchIdentifier (const word &name, const dictionary &dict, const label index)
	patchIdentifier (const patchIdentifier &ident, const label index)
const word &	name () const noexcept
word &	name () noexcept
label	index () const noexcept
label &	index () noexcept
const word &	physicalType () const noexcept
word &	physicalType () noexcept
const wordList &	inGroups () const noexcept
wordList &	inGroups () noexcept
bool	inGroup (const word &name) const
void	write (Ostream &os) const
Public Member Functions inherited from PrimitivePatch< FaceList, PointField >
	PrimitivePatch (const FaceList &faces, const PointField &points)
	PrimitivePatch (FaceList &&faces, const PointField &points)
	PrimitivePatch (FaceList &faces, PointField &points, const bool reuse)
	PrimitivePatch (const PrimitivePatch< FaceList, PointField > &pp)
virtual	~PrimitivePatch ()
void	clearOut ()
void	clearGeom ()
void	clearTopology ()
void	clearPatchMeshAddr ()
void	swap (PrimitivePatch &)=delete
const Field< point_type > &	points () const noexcept
label	nFaces () const noexcept
label	nPoints () const
label	nEdges () const
const edgeList &	edges () const
const edgeList::subList	internalEdges () const
const edgeList::subList	boundaryEdges () const
label	nInternalEdges () const
label	nBoundaryEdges () const
bool	isInternalEdge (const label edgei) const
const labelList &	boundaryPoints () const
const labelListList &	faceFaces () const
const labelListList &	edgeFaces () const
const labelListList &	faceEdges () const
const labelListList &	pointEdges () const
const labelListList &	pointFaces () const
const List< face_type > &	localFaces () const
labelList	boundaryFaces () const
labelList	uniqBoundaryFaces () const
const labelList &	meshPoints () const
const Map< label > &	meshPointMap () const
const Field< point_type > &	localPoints () const
const labelList &	localPointOrder () const
label	whichPoint (const label gp) const
edge	meshEdge (const label edgei) const
edge	meshEdge (const edge &e) const
label	findEdge (const edge &e) const
labelList	meshEdges (const edgeList &allEdges, const labelListList &cellEdges, const labelList &faceCells) const
labelList	meshEdges (const edgeList &allEdges, const labelListList &pointEdges) const
label	meshEdge (const label edgei, const edgeList &allEdges, const labelListList &pointEdges) const
labelList	meshEdges (const labelUList &edgeLabels, const edgeList &allEdges, const labelListList &pointEdges) const
const Field< point_type > &	faceCentres () const
const Field< point_type > &	faceAreas () const
const Field< scalar > &	magFaceAreas () const
const Field< point_type > &	faceNormals () const
const Field< point_type > &	pointNormals () const
bool	hasFaceAreas () const
bool	hasFaceCentres () const
bool	hasFaceNormals () const
bool	hasPointNormals () const
bool	hasBoundaryPoints () const
bool	hasFaceFaces () const
bool	hasEdgeFaces () const
bool	hasFaceEdges () const
bool	hasPointEdges () const
bool	hasPointFaces () const
bool	hasMeshPointMap () const
template<class ToPatch >
List< objectHit >	projectPoints (const ToPatch &targetPatch, const Field< point_type > &projectionDirection, const intersection::algorithm=intersection::FULL_RAY, const intersection::direction=intersection::VECTOR) const
template<class ToPatch >
List< objectHit >	projectFaceCentres (const ToPatch &targetPatch, const Field< point_type > &projectionDirection, const intersection::algorithm=intersection::FULL_RAY, const intersection::direction=intersection::VECTOR) const
const labelListList &	edgeLoops () const
surfaceTopo	surfaceType () const
bool	checkTopology (const bool report=false, labelHashSet *setPtr=nullptr) const
bool	checkPointManifold (const bool report=false, labelHashSet *setPtr=nullptr) const
virtual void	movePoints (const Field< point_type > &)
void	operator= (const PrimitivePatch< FaceList, PointField > &rhs)
void	operator= (PrimitivePatch< FaceList, PointField > &&rhs)
label	whichEdge (const edge &e) const
template<class ToPatch >
Foam::List< Foam::objectHit >	projectPoints (const ToPatch &targetPatch, const Field< typename Foam::PrimitivePatch< FaceList, PointField >::point_type > &projectionDirection, const intersection::algorithm alg, const intersection::direction dir) const
template<class ToPatch >
Foam::List< Foam::objectHit >	projectFaceCentres (const ToPatch &targetPatch, const Field< typename Foam::PrimitivePatch< FaceList, PointField >::point_type > &projectionDirection, const intersection::algorithm alg, const intersection::direction dir) const
Public Member Functions inherited from PrimitivePatchBase
	ClassName ("PrimitivePatch")
	PrimitivePatchBase ()=default

Static Public Member Functions
static autoPtr< polyPatch >	New (const word &patchType, const word &name, const label size, const label start, const label index, const polyBoundaryMesh &bm)
static autoPtr< polyPatch >	New (const word &name, const dictionary &dict, const label index, const polyBoundaryMesh &bm)
static autoPtr< polyPatch >	New (const word &patchType, const word &name, const dictionary &dict, const label index, const polyBoundaryMesh &bm)
static bool	constraintType (const word &pt)
static wordList	constraintTypes ()
Static Public Member Functions inherited from patchIdentifier
static word	defaultName (const label n=-1)

Static Public Attributes
static int	disallowGenericPolyPatch

Protected Member Functions
virtual void	initGeometry (PstreamBuffers &)
virtual void	calcGeometry (PstreamBuffers &)
virtual void	initMovePoints (PstreamBuffers &, const pointField &)
virtual void	movePoints (PstreamBuffers &, const pointField &p)
virtual void	initUpdateMesh (PstreamBuffers &)
virtual void	updateMesh (PstreamBuffers &)
virtual void	clearGeom ()
virtual void	movePoints (const Field< point_type > &)

Friends
class	polyBoundaryMesh
Ostream &	operator<< (Ostream &, const polyPatch &)

Additional Inherited Members
Public Types inherited from PrimitivePatch< FaceList, PointField >
enum	surfaceTopo { MANIFOLD, OPEN, ILLEGAL }
typedef std::remove_reference< FaceList >::type::value_type	face_type
typedef std::remove_reference< PointField >::type::value_type	point_type
typedef FaceList	FaceListType
typedef PointField	PointFieldType
typedef face_type	FaceType

Detailed Description

A patch is a list of labels that address the faces in the global face list.

The patch can calculate its own edges based on the global faces. Patch also contains all addressing between the faces.

Source files

• polyPatch.H
• polyPatch.C
• polyPatchNew.C

Definition at line 64 of file polyPatch.H.

Constructor & Destructor Documentation

polyPatch() [1/8]

polyPatch	(	const word &	name,
		const label	size,
		const label	start,
		const label	index,
		const polyBoundaryMesh &	bm,
		const word &	patchType
	)

Definition at line 76 of file polyPatch.C.

polyPatch() [2/8]

polyPatch	(	const word &	name,
		const label	size,
		const label	start,
		const label	index,
		const polyBoundaryMesh &	bm,
		const word &	physicalType,
		const wordList &	inGroups
	)

Definition at line 104 of file polyPatch.C.

polyPatch() [3/8]

polyPatch	(	const word &	name,
		const dictionary &	dict,
		const label	index,
		const polyBoundaryMesh &	bm,
		const word &	patchType
	)

Definition at line 128 of file polyPatch.C.

References List::appendUniq().

Here is the call graph for this function:

polyPatch() [4/8]

polyPatch	(	const polyPatch &	pp,
		const polyBoundaryMesh &	bm
	)

Definition at line 160 of file polyPatch.C.

polyPatch() [5/8]

polyPatch	(	const polyPatch &	pp,
		const polyBoundaryMesh &	bm,
		const label	index,
		const label	newSize,
		const label	newStart
	)

Definition at line 184 of file polyPatch.C.

polyPatch() [6/8]

polyPatch	(	const polyPatch &	pp,
		const polyBoundaryMesh &	bm,
		const label	index,
		const labelUList &	mapAddressing,
		const label	newStart
	)

Definition at line 211 of file polyPatch.C.

polyPatch() [7/8]

polyPatch

(

const polyPatch &

p

)

Definition at line 237 of file polyPatch.C.

polyPatch() [8/8]

polyPatch	(	const polyPatch &	p,
		const labelList &	faceCells
	)

Definition at line 249 of file polyPatch.C.

~polyPatch()

~polyPatch ( )

virtual

Definition at line 262 of file polyPatch.C.

Member Function Documentation

initGeometry()

virtual void initGeometry ( PstreamBuffers &  )

inlineprotectedvirtual

Reimplemented in coupledPolyPatch, cyclicAMIPolyPatch, cyclicACMIPolyPatch, oldCyclicPolyPatch, cyclicPolyPatch, processorPolyPatch, processorCyclicPolyPatch, mappedPolyPatch, and mappedWallPolyPatch.

Definition at line 95 of file polyPatch.H.

Referenced by mappedPolyPatch::initGeometry(), mappedWallPolyPatch::initGeometry(), cyclicPolyPatch::initGeometry(), oldCyclicPolyPatch::initGeometry(), and cyclicAMIPolyPatch::initGeometry().

Here is the caller graph for this function:

calcGeometry()

virtual void calcGeometry ( PstreamBuffers &  )

inlineprotectedvirtual

Reimplemented in coupledPolyPatch, cyclicAMIPolyPatch, cyclicACMIPolyPatch, cyclicPolyPatch, oldCyclicPolyPatch, processorPolyPatch, wedgePolyPatch, processorCyclicPolyPatch, mappedPolyPatch, mappedWallPolyPatch, and symmetryPlanePolyPatch.

Definition at line 99 of file polyPatch.H.

Referenced by mappedPolyPatch::calcGeometry(), and mappedWallPolyPatch::calcGeometry().

Here is the caller graph for this function:

initMovePoints()

virtual void initMovePoints ( PstreamBuffers &  , const pointField &    )

inlineprotectedvirtual

Reimplemented in cyclicAMIPolyPatch, cyclicACMIPolyPatch, coupledPolyPatch, cyclicPolyPatch, oldCyclicPolyPatch, processorPolyPatch, processorCyclicPolyPatch, mappedPolyPatch, and mappedWallPolyPatch.

Definition at line 103 of file polyPatch.H.

Referenced by mappedPolyPatch::initMovePoints(), mappedWallPolyPatch::initMovePoints(), oldCyclicPolyPatch::initMovePoints(), and cyclicPolyPatch::initMovePoints().

Here is the caller graph for this function:

movePoints() [1/2]

void movePoints ( PstreamBuffers &  , const pointField &  p  )

protectedvirtual

Reimplemented in cyclicAMIPolyPatch, cyclicACMIPolyPatch, coupledPolyPatch, cyclicPolyPatch, oldCyclicPolyPatch, processorPolyPatch, processorCyclicPolyPatch, mappedPolyPatch, and mappedWallPolyPatch.

Definition at line 54 of file polyPatch.C.

References PrimitivePatch< FaceList, PointField >::movePoints(), and p.

Referenced by processorPolyPatch::initMovePoints(), mappedWallPolyPatch::movePoints(), mappedPolyPatch::movePoints(), oldCyclicPolyPatch::movePoints(), and cyclicPolyPatch::movePoints().

Here is the call graph for this function:

Here is the caller graph for this function:

initUpdateMesh()

virtual void initUpdateMesh ( PstreamBuffers &  )

inlineprotectedvirtual

Reimplemented in coupledPolyPatch, cyclicAMIPolyPatch, cyclicPolyPatch, cyclicACMIPolyPatch, oldCyclicPolyPatch, processorPolyPatch, processorCyclicPolyPatch, mappedPolyPatch, and mappedWallPolyPatch.

Definition at line 110 of file polyPatch.H.

Referenced by mappedPolyPatch::initUpdateMesh(), mappedWallPolyPatch::initUpdateMesh(), processorPolyPatch::initUpdateMesh(), oldCyclicPolyPatch::initUpdateMesh(), cyclicPolyPatch::initUpdateMesh(), and cyclicAMIPolyPatch::initUpdateMesh().

Here is the caller graph for this function:

updateMesh()

void updateMesh ( PstreamBuffers &  )

protectedvirtual

Reimplemented in coupledPolyPatch, cyclicAMIPolyPatch, cyclicPolyPatch, cyclicACMIPolyPatch, oldCyclicPolyPatch, processorPolyPatch, processorCyclicPolyPatch, mappedPolyPatch, and mappedWallPolyPatch.

Definition at line 60 of file polyPatch.C.

References PrimitivePatch< FaceList, PointField >::clearGeom().

Referenced by mappedPolyPatch::updateMesh(), mappedWallPolyPatch::updateMesh(), processorPolyPatch::updateMesh(), oldCyclicPolyPatch::updateMesh(), cyclicPolyPatch::updateMesh(), and cyclicAMIPolyPatch::updateMesh().

Here is the call graph for this function:

Here is the caller graph for this function:

clearGeom()

void clearGeom ( )

protectedvirtual

Reimplemented in cyclicAMIPolyPatch, and cyclicACMIPolyPatch.

Definition at line 67 of file polyPatch.C.

References PrimitivePatch< FaceList, PointField >::clearGeom().

Referenced by cyclicAMIPolyPatch::clearGeom().

Here is the call graph for this function:

Here is the caller graph for this function:

TypeName()

TypeName

(

"patch"

)

declareRunTimeSelectionTable() [1/2]

declareRunTimeSelectionTable	(	autoPtr	,
		polyPatch	,
		word	,
		(const word &name, const label size, const label start, const label index, const polyBoundaryMesh &bm, const word &patchType)	,
		(name, size, start, index, bm, patchType)
	)

declareRunTimeSelectionTable() [2/2]

declareRunTimeSelectionTable	(	autoPtr	,
		polyPatch	,
		dictionary	,
		(const word &name, const dictionary &dict, const label index, const polyBoundaryMesh &bm, const word &patchType)	,
		(name, dict, index, bm, patchType)
	)

clone() [1/4]

virtual autoPtr<polyPatch> clone ( const labelList &  faceCells ) const

inlinevirtual

Definition at line 231 of file polyPatch.H.

References autoPtr::New().

Referenced by boundaryMesh::patchify().

Here is the call graph for this function:

Here is the caller graph for this function:

clone() [2/4]

virtual autoPtr<polyPatch> clone ( const polyBoundaryMesh &  bm ) const

inlinevirtual

Reimplemented in cyclicAMIPolyPatch, cyclicPolyPatch, cyclicACMIPolyPatch, oldCyclicPolyPatch, processorPolyPatch, processorCyclicPolyPatch, mappedPolyPatch, mappedWallPolyPatch, mappedVariableThicknessWallPolyPatch, cyclicPeriodicAMIPolyPatch, wedgePolyPatch, cyclicSlipPolyPatch, nonuniformTransformCyclicPolyPatch, symmetryPlanePolyPatch, genericPolyPatch, oversetPolyPatch, symmetryPolyPatch, emptyPolyPatch, and wallPolyPatch.

Definition at line 237 of file polyPatch.H.

References autoPtr::New().

Here is the call graph for this function:

clone() [3/4]

virtual autoPtr<polyPatch> clone ( const polyBoundaryMesh &  bm, const label  index, const label  newSize, const label  newStart  ) const

inlinevirtual

Reimplemented in cyclicAMIPolyPatch, cyclicPolyPatch, cyclicACMIPolyPatch, oldCyclicPolyPatch, processorPolyPatch, processorCyclicPolyPatch, mappedPolyPatch, mappedWallPolyPatch, mappedVariableThicknessWallPolyPatch, cyclicPeriodicAMIPolyPatch, wedgePolyPatch, nonuniformTransformCyclicPolyPatch, cyclicSlipPolyPatch, symmetryPlanePolyPatch, genericPolyPatch, oversetPolyPatch, symmetryPolyPatch, emptyPolyPatch, and wallPolyPatch.

Definition at line 245 of file polyPatch.H.

References patchIdentifier::index(), and autoPtr::New().

Here is the call graph for this function:

clone() [4/4]

virtual autoPtr<polyPatch> clone ( const polyBoundaryMesh &  bm, const label  index, const labelUList &  mapAddressing, const label  newStart  ) const

inlinevirtual

Reimplemented in cyclicAMIPolyPatch, cyclicPolyPatch, cyclicACMIPolyPatch, processorCyclicPolyPatch, processorPolyPatch, mappedWallPolyPatch, mappedPolyPatch, mappedVariableThicknessWallPolyPatch, cyclicPeriodicAMIPolyPatch, nonuniformTransformCyclicPolyPatch, cyclicSlipPolyPatch, wedgePolyPatch, symmetryPlanePolyPatch, genericPolyPatch, oversetPolyPatch, symmetryPolyPatch, emptyPolyPatch, and wallPolyPatch.

Definition at line 258 of file polyPatch.H.

References patchIdentifier::index(), and autoPtr::New().

Here is the call graph for this function:

New() [1/3]

Foam::autoPtr< Foam::polyPatch > New ( const word &  patchType, const word &  name, const label  size, const label  start, const label  index, const polyBoundaryMesh &  bm  )

static

Definition at line 28 of file polyPatchNew.C.

References DebugInFunction, Foam::endl(), Foam::exit(), Foam::FatalError, FatalErrorInLookup, and Foam::name().

Referenced by columnFvMeshInfo::addLocalPatches(), meshRefinement::appendPatch(), extrudePatchMesh::extrudePatchMesh(), PDRblock::innerMesh(), fvMeshTools::newMesh(), boundaryMesh::patchify(), polyBoundaryMesh::polyBoundaryMesh(), and polyMesh::polyMesh().

Here is the call graph for this function:

Here is the caller graph for this function:

New() [2/3]

Foam::autoPtr< Foam::polyPatch > New ( const word &  name, const dictionary &  dict, const label  index, const polyBoundaryMesh &  bm  )

static

Definition at line 67 of file polyPatchNew.C.

References DebugInFunction, dict, Foam::endl(), Foam::name(), and Foam::New().

Here is the call graph for this function:

New() [3/3]

Foam::autoPtr< Foam::polyPatch > New ( const word &  patchType, const word &  name, const dictionary &  dict, const label  index, const polyBoundaryMesh &  bm  )

static

Definition at line 84 of file polyPatchNew.C.

References DebugInFunction, dict, Foam::endl(), Foam::exit(), Foam::FatalIOError, FatalIOErrorInLookup, and Foam::name().

Here is the call graph for this function:

newInternalProcFaces()

virtual void newInternalProcFaces ( label &  , label &    ) const

inlinevirtual

Reimplemented in cyclicPolyPatch, mappedWallPolyPatch, mappedPolyPatch, cyclicAMIPolyPatch, and cyclicACMIPolyPatch.

Definition at line 312 of file polyPatch.H.

References NotImplemented.

Referenced by lduPrimitiveMeshAssembly::update().

Here is the caller graph for this function:

nbrCells()

virtual const labelUList& nbrCells ( ) const

inlinevirtual

Reimplemented in cyclicAMIPolyPatch, cyclicPolyPatch, mappedWallPolyPatch, and mappedPolyPatch.

Definition at line 318 of file polyPatch.H.

References NotImplemented, and UList::null().

Referenced by lduPrimitiveMeshAssembly::update().

Here is the call graph for this function:

Here is the caller graph for this function:

neighbPolyPatchID()

virtual label neighbPolyPatchID ( ) const

inlinevirtual

Reimplemented in cyclicAMIPolyPatch, cyclicPolyPatch, mappedWallPolyPatch, and mappedPolyPatch.

Definition at line 325 of file polyPatch.H.

References NotImplemented.

Referenced by fvMatrix< Type >::mapContributions(), and lduPrimitiveMeshAssembly::update().

Here is the caller graph for this function:

mapCollocatedFaces()

virtual refPtr<labelListList> mapCollocatedFaces ( ) const

inlinevirtual

Reimplemented in cyclicAMIPolyPatch, cyclicPolyPatch, cyclicACMIPolyPatch, mappedWallPolyPatch, and mappedPolyPatch.

Definition at line 332 of file polyPatch.H.

References NotImplemented.

Referenced by lduPrimitiveMeshAssembly::update().

Here is the caller graph for this function:

masterImplicit()

virtual bool masterImplicit ( ) const

inlinevirtual

Reimplemented in cyclicAMIPolyPatch, cyclicPolyPatch, mappedWallPolyPatch, and mappedPolyPatch.

Definition at line 339 of file polyPatch.H.

References NotImplemented.

Referenced by assemblyFaceAreaPairGAMGAgglomeration::assemblyFaceAreaPairGAMGAgglomeration(), fvMatrix< Type >::mapContributions(), and lduPrimitiveMeshAssembly::update().

Here is the caller graph for this function:

neighbRegionID()

virtual word neighbRegionID ( ) const

inlinevirtual

Reimplemented in mappedWallPolyPatch, and mappedPolyPatch.

Definition at line 346 of file polyPatch.H.

Referenced by lduPrimitiveMeshAssembly::findNbrMeshId().

Here is the caller graph for this function:

offset()

Foam::label offset

(

)

const

Definition at line 302 of file polyPatch.C.

Referenced by preservePatches::apply(), cyclicPolyPatch::transformGlobalFace(), and Foam::ensightOutput::writeVolField().

Here is the caller graph for this function:

start()

label start ( ) const

inline

Definition at line 357 of file polyPatch.H.

Referenced by preservePatches::add(), polyMeshAdder::add(), cyclicAMIPolyPatch::addAMIFaces(), polyTopoChange::addMesh(), fvMeshTools::addPatch(), meshRefinement::addPatch(), cellToFaceStencil::allCoupledFacesPatch(), cellToFaceStencil::calcFaceStencil(), polyDualMesh::calcFeatures(), FaceCellWave< Type, int >::checkCyclic(), hexRef8::checkMesh(), particle< Type >::correctAfterParallelTransfer(), globalMeshData::coupledPatch(), meshRefinement::createBaffles(), structuredDecomp::decompose(), Bezier::dndbBasedSensitivities(), NURBS3DVolume::dndbBasedSensitivities(), faceCoupleInfo::faceLabels(), polyMeshTools::faceOrthogonality(), mappedPatchBase::facePoints(), polyMeshTools::faceSkewness(), polyMeshTools::faceWeights(), patchProbes::findElements(), externalDisplacementMeshMover::getPatch(), particle< Type >::hitCyclicACMIPatch(), particle< Type >::hitCyclicAMIPatch(), fluxSummary::initialiseCellZoneAndDirection(), isoSurfacePoint::isoSurfacePoint(), meshRefinement::makePatch(), combine< Type, TrackingData >::operator()(), polyMeshAdder::patchFacePairs(), boundaryMesh::patchify(), PatchCollisionDensity< CloudType >::postPatch(), fvMeshDistribute::printMeshInfo(), boundaryMesh::read(), cyclicAMIPolyPatch::removeAMIFaces(), structuredRenumber::renumber(), snappySnapDriver::repatchToSurface(), sampledPatchInternalField::sampleOnPoints(), sampledPatch::sampleOnPoints(), sampledFaceZone::sampleOnPoints(), fvMeshSubset::setCellSubset(), rotorDiskSource::setFaceArea(), lumpedPointMovement::setPatchControl(), removeFaces::setRefinement(), fvPatch::start(), syncTools::syncBoundaryFaceList(), syncTools::syncFaceList(), meshRefinement::testSyncBoundaryFaceList(), cyclicPolyPatch::transformGlobalFace(), sampledPatch::update(), cellToFaceStencil::validBoundaryFaces(), polyMeshTools::volRatio(), wallLayerCells::wallLayerCells(), regionSizeDistribution::write(), and meshRefinement::zonify().

range()

labelRange range ( ) const

inline

Definition at line 363 of file polyPatch.H.

Referenced by mappedPatchBase::findLocalSamples(), labelRangeOp< polyPatch >::operator()(), and perfectInterface::setRefinement().

Here is the caller graph for this function:

boundaryMesh()

const Foam::polyBoundaryMesh & boundaryMesh

(

)

const

Definition at line 308 of file polyPatch.C.

Referenced by mappedPatchBase::addWorldConnection(), viewFactor::calculate(), cyclicAMIPolyPatch::canResetAMI(), processorPolyPatch::comm(), patchPatchDist::correct(), mappedPatchBase::facePoints(), coupleGroupIdentifier::findOtherPatchID(), fluxSummary::initialiseFaceZone(), fluxSummary::initialiseFaceZoneAndDirection(), mappedVariableThicknessWallFvPatch::makeDeltaCoeffs(), regionModel::nbrCoupledPatchID(), cyclicPolyPatch::neighbPatch(), AMIWeights::read(), processorCyclicPolyPatch::referPatch(), processorCyclicPolyPatch::referPatchID(), cyclicAMIPolyPatch::restoreScaledGeometry(), meshRefinement::selectSeparatedCoupledFaces(), extractEulerianParticles::setBlockedFaces(), lumpedPointMovement::setPatchControl(), lduPrimitiveMeshAssembly::update(), cyclicACMIPolyPatch::updateAreas(), and outletMappedUniformInletHeatAdditionFvPatchField::updateCoeffs().

Here is the caller graph for this function:

coupled()

virtual bool coupled ( ) const

inlinevirtual

Reimplemented in cyclicAMIPolyPatch, processorPolyPatch, and coupledPolyPatch.

Definition at line 373 of file polyPatch.H.

Referenced by cellToFaceStencil::allCoupledFacesPatch(), cellToFaceStencil::calcFaceStencil(), solarLoad::calculate(), hexRef8::checkMesh(), facePointPatch::coupled(), fvPatch::coupled(), globalMeshData::coupledPatch(), meshRefinement::createBaffles(), snappyLayerDriver::doLayers(), polyMeshTools::faceOrthogonality(), polyMeshTools::faceSkewness(), polyMeshTools::faceWeights(), fluxSummary::initialiseCellZoneAndDirection(), isoSurfacePoint::isoSurfacePoint(), rotorDiskSource::setFaceArea(), shortestPathSet::shortestPathSet(), cellToFaceStencil::validBoundaryFaces(), polyMeshTools::volRatio(), and meshRefinement::zonify().

Here is the caller graph for this function:

constraintType()

bool constraintType ( const word &  pt )

static

Definition at line 270 of file polyPatch.C.

References found.

Referenced by Foam::evaluateConstraintTypes(), surfaceDistance::execute(), KinematicParcel::hitPatch(), meshRefinement::meshedPatches(), and Foam::reusable().

Here is the caller graph for this function:

constraintTypes()

Foam::wordList constraintTypes ( )

static

Definition at line 280 of file polyPatch.C.

References forAllConstIters(), and List::setSize().

Here is the call graph for this function:

patchInternalList()

const UIndirectList<T> patchInternalList ( const UList< T > &  internalValues ) const

inline

Definition at line 387 of file polyPatch.H.

References polyPatch::faceCells().

Here is the call graph for this function:

patchSlice() [1/2]

const List<T>::subList patchSlice ( const UList< T > &  l ) const

inline

Definition at line 396 of file polyPatch.H.

Referenced by isoSurfacePoint::isoSurfacePoint().

Here is the caller graph for this function:

patchSlice() [2/2]

const Field<T>::subField patchSlice ( const Field< T > &  l ) const

inline

Definition at line 403 of file polyPatch.H.

write()

void write ( Ostream &  os ) const

virtual

Reimplemented in coupledPolyPatch, cyclicAMIPolyPatch, cyclicPolyPatch, processorCyclicPolyPatch, processorPolyPatch, cyclicACMIPolyPatch, oldCyclicPolyPatch, mappedWallPolyPatch, mappedPolyPatch, mappedVariableThicknessWallPolyPatch, cyclicPeriodicAMIPolyPatch, and genericPolyPatch.

Definition at line 406 of file polyPatch.C.

References os(), Foam::type(), patchIdentifier::write(), and Ostream::writeEntry().

Referenced by mappedPolyPatch::write(), mappedWallPolyPatch::write(), and coupledPolyPatch::write().

Here is the call graph for this function:

Here is the caller graph for this function:

faceCentres()

const Foam::vectorField::subField faceCentres

(

)

const

Definition at line 314 of file polyPatch.C.

References mesh.

Referenced by cyclicPolyPatch::calcTransforms(), cyclicAMIPolyPatch::calcTransforms(), forces::initialiseBins(), cyclicAMIPolyPatch::interpolate(), trackingInverseDistance::markBoundaries(), cyclicAMIFvPatch::movePoints(), cyclicACMIFvPatch::resetPatchAreas(), cyclicAMIPolyPatch::restoreScaledGeometry(), cyclicAMIPolyPatch::setAMIFaces(), and movingWallVelocityFvPatchVectorField::Uwall().

Here is the caller graph for this function:

faceAreas()

const Foam::vectorField::subField faceAreas

(

)

const

Definition at line 320 of file polyPatch.C.

References mesh.

Referenced by DSMCParcel::hitWallPatch(), regionModel1D::moveMesh(), cyclicAMIFvPatch::movePoints(), cyclicACMIPolyPatch::nonOverlapPatchID(), cyclicACMIFvPatch::resetPatchAreas(), cyclicAMIPolyPatch::restoreScaledGeometry(), cyclicACMIPolyPatch::scalePatchFaceAreas(), cyclicAMIPolyPatch::setAMIFaces(), and dynamicMotionSolverFvMeshAMI::update().

Here is the caller graph for this function:

faceCellCentres()

Foam::tmp< Foam::vectorField > faceCellCentres

(

)

const

Definition at line 326 of file polyPatch.C.

References forAll, and tmp::ref().

Here is the call graph for this function:

areaFraction()

Foam::tmp< Foam::scalarField > areaFraction

(

)

const

Definition at line 345 of file polyPatch.C.

References forAll, face::mag(), Foam::mag(), points, and tmp::ref().

Here is the call graph for this function:

faceCells()

const Foam::labelUList & faceCells

(

)

const

Definition at line 364 of file polyPatch.C.

References mesh.

Referenced by preservePatches::apply(), assemblyFaceAreaPairGAMGAgglomeration::assemblyFaceAreaPairGAMGAgglomeration(), reconstructedDistanceFunction::constructRDF(), patchInjection::correct(), particle< Type >::correctAfterParallelTransfer(), structuredDecomp::decompose(), snappyLayerDriver::doLayers(), oversetFvPatch::faceCells(), mappedPolyPatch::nbrCells(), mappedWallPolyPatch::nbrCells(), cyclicPolyPatch::nbrCells(), cyclicAMIPolyPatch::nbrCells(), polyPatch::patchInternalList(), structuredRenumber::renumber(), lduPrimitiveMeshAssembly::update(), activeBaffleVelocityFvPatchVectorField::updateCoeffs(), and activePressureForceBaffleVelocityFvPatchVectorField::updateCoeffs().

Here is the caller graph for this function:

meshEdges()

const Foam::labelList & meshEdges

(

)

const

Definition at line 378 of file polyPatch.C.

References mesh, and PrimitivePatch< FaceList, PointField >::meshEdges().

Here is the call graph for this function:

clearAddressing()

void clearAddressing ( )

virtual

Definition at line 397 of file polyPatch.C.

References PrimitivePatch< FaceList, PointField >::clearPatchMeshAddr(), PrimitivePatch< FaceList, PointField >::clearTopology(), and Foam::deleteDemandDrivenData().

Here is the call graph for this function:

whichFace()

label whichFace ( const label  l ) const

inline

Definition at line 444 of file polyPatch.H.

Referenced by MaxwellianThermal< CloudType >::correct(), MixedDiffuseSpecular< CloudType >::correct(), LocalInteraction< CloudType >::correct(), FacePostProcessing< CloudType >::FacePostProcessing(), particle< Type >::hitCyclicACMIPatch(), particle< Type >::hitCyclicAMIPatch(), particle< Type >::hitCyclicPatch(), DSMCParcel::hitWallPatch(), fluxSummary::initialiseFaceZone(), fluxSummary::initialiseFaceZoneAndDirection(), KinematicCloud< Cloud< basicKinematicCollidingParcel > >::patchData(), ParticleErosion< CloudType >::postPatch(), PatchInteractionFields< CloudType >::postPatch(), RemoveParcels< CloudType >::RemoveParcels(), extractEulerianParticles::setBlockedFaces(), ThermoSurfaceFilm< CloudType >::transferParcel(), KinematicSurfaceFilm< CloudType >::transferParcel(), and sampledFaceZone::update().

Here is the caller graph for this function:

initOrder()

void initOrder ( PstreamBuffers &  , const primitivePatch &    ) const

virtual

Reimplemented in coupledPolyPatch, cyclicAMIPolyPatch, cyclicPolyPatch, processorCyclicPolyPatch, cyclicACMIPolyPatch, processorPolyPatch, and oldCyclicPolyPatch.

Definition at line 415 of file polyPatch.C.

order()

bool order ( PstreamBuffers &  , const primitivePatch &  , labelList &  faceMap, labelList &  rotation  ) const

virtual

Reimplemented in coupledPolyPatch, cyclicAMIPolyPatch, cyclicPolyPatch, processorCyclicPolyPatch, processorPolyPatch, cyclicACMIPolyPatch, and oldCyclicPolyPatch.

Definition at line 420 of file polyPatch.C.

changeTopology()

virtual bool changeTopology ( ) const

inlinevirtual

Reimplemented in cyclicAMIPolyPatch.

Definition at line 469 of file polyPatch.H.

Referenced by dynamicMotionSolverFvMeshAMI::update().

Here is the caller graph for this function:

setTopology()

virtual bool setTopology ( polyTopoChange &  )

inlinevirtual

Reimplemented in cyclicAMIPolyPatch.

Definition at line 475 of file polyPatch.H.

operator=()

void operator=

(

const polyPatch &

p

)

Definition at line 434 of file polyPatch.C.

References patchIdentifier::operator=(), PrimitivePatch< FaceList, PointField >::operator=(), and p.

Here is the call graph for this function:

movePoints() [2/2]

void movePoints

protected

Definition at line 164 of file PrimitivePatch.C.

Friends And Related Function Documentation

polyBoundaryMesh

friend class polyBoundaryMesh

friend

Definition at line 92 of file polyPatch.H.

operator<<

Ostream& operator<< ( Ostream &  , const polyPatch &    )

friend

Member Data Documentation

disallowGenericPolyPatch

int disallowGenericPolyPatch

static

Definition at line 126 of file polyPatch.H.

---

The documentation for this class was generated from the following files:

• src/OpenFOAM/meshes/polyMesh/polyPatches/polyPatch/polyPatch.H
• src/OpenFOAM/meshes/polyMesh/polyPatches/polyPatch/polyPatch.C
• src/OpenFOAM/meshes/polyMesh/polyPatches/polyPatch/polyPatchNew.C
