Inheritance diagram for polyMeshTools:

Collaboration diagram for polyMeshTools:

Static Public Member Functions
static tmp< scalarField >	faceOrthogonality (const polyMesh &mesh, const vectorField &fAreas, const vectorField &cellCtrs)

static tmp< scalarField >	faceSkewness (const polyMesh &mesh, const pointField &points, const vectorField &fCtrs, const vectorField &fAreas, const vectorField &cellCtrs)

static tmp< scalarField >	faceWeights (const polyMesh &mesh, const vectorField &fCtrs, const vectorField &fAreas, const vectorField &cellCtrs)

static tmp< scalarField >	volRatio (const polyMesh &mesh, const scalarField &vol)

static polyMesh::readUpdateState	combine (const polyMesh::readUpdateState &state0, const polyMesh::readUpdateState &state1)

Static Public Member Functions inherited from primitiveMeshTools
static void	makeFaceCentresAndAreas (const primitiveMesh &mesh, const pointField &p, vectorField &fCtrs, vectorField &fAreas)

static void	makeCellCentresAndVols (const primitiveMesh &mesh, const vectorField &fCtrs, const vectorField &fAreas, vectorField &cellCtrs, scalarField &cellVols)

static tmp< scalarField >	faceOrthogonality (const primitiveMesh &mesh, const vectorField &fAreas, const vectorField &cellCtrs)

static void	facePyramidVolume (const primitiveMesh &mesh, const pointField &points, const vectorField &cellCtrs, scalarField &ownPyrVol, scalarField &neiPyrVol)

static tmp< scalarField >	faceSkewness (const primitiveMesh &mesh, const pointField &points, const vectorField &fCtrs, const vectorField &fAreas, const vectorField &cellCtrs)

static void	cellClosedness (const primitiveMesh &mesh, const Vector< label > &meshD, const vectorField &areas, const scalarField &vols, scalarField &openness, scalarField &aratio)

static tmp< scalarField >	faceConcavity (const scalar maxSin, const primitiveMesh &mesh, const pointField &p, const vectorField &faceAreas)

static tmp< scalarField >	faceFlatness (const primitiveMesh &mesh, const pointField &p, const vectorField &fCtrs, const vectorField &faceAreas)

static tmp< scalarField >	edgeAlignment (const primitiveMesh &mesh, const Vector< label > &directions, const pointField &p)

static tmp< scalarField >	cellDeterminant (const primitiveMesh &mesh, const Vector< label > &directions, const vectorField &faceAreas, const bitSet &internalOrCoupledFace)

static scalar	faceSkewness (const primitiveMesh &mesh, const pointField &p, const vectorField &fCtrs, const vectorField &fAreas, const label facei, const point &ownCc, const point &neiCc)

static scalar	boundaryFaceSkewness (const primitiveMesh &mesh, const pointField &p, const vectorField &fCtrs, const vectorField &fAreas, const label facei, const point &ownCc)

static scalar	faceOrthogonality (const point &ownCc, const point &neiCc, const vector &s)

Detailed Description

Definition at line 50 of file polyMeshTools.H.

Member Function Documentation

◆ faceOrthogonality()

Foam::tmp< Foam::scalarField > faceOrthogonality	(	const polyMesh &	mesh,
		const vectorField &	fAreas,
		const vectorField &	cellCtrs
	)

static

Definition at line 30 of file polyMeshTools.C.

References polyPatch::coupled(), forAll, mesh, tmp::ref(), and polyPatch::start().

Referenced by averageNeighbourFvGeometryScheme::movePoints().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ faceSkewness()

Foam::tmp< Foam::scalarField > faceSkewness	(	const polyMesh &	mesh,
		const pointField &	points,
		const vectorField &	fCtrs,
		const vectorField &	fAreas,
		const vectorField &	cellCtrs
	)

static

Definition at line 85 of file polyMeshTools.C.

References polyPatch::coupled(), forAll, mesh, p, tmp::ref(), Foam::skew(), and polyPatch::start().

Here is the call graph for this function:

◆ faceWeights()

Foam::tmp< Foam::scalarField > faceWeights	(	const polyMesh &	mesh,
		const vectorField &	fCtrs,
		const vectorField &	fAreas,
		const vectorField &	cellCtrs
	)
