pointMVCWeight Class Reference

Container to calculate weights for interpolating directly from vertices of cell using Mean Value Coordinates. More...

Collaboration diagram for pointMVCWeight:

Public Member Functions
	pointMVCWeight (const polyMesh &mesh, const vector &position, const label celli, const label facei=-1)
label	cell () const
const scalarField &	weights () const
template<class Type >
Type	interpolate (const GeometricField< Type, pointPatchField, pointMesh > &psip) const

Static Public Attributes
static int	debug
static scalar	tol

Protected Member Functions
void	calcWeights (const Map< label > &toLocal, const face &f, const DynamicList< point > &u, const scalarField &dist, scalarField &weights) const
void	calcWeights (const polyMesh &mesh, const labelList &toGlobal, const Map< label > &toLocal, const vector &position, const vectorField &uVec, const scalarField &dist, scalarField &weights) const

Protected Attributes
const label	cellIndex_
scalarField	weights_

Detailed Description

Container to calculate weights for interpolating directly from vertices of cell using Mean Value Coordinates.

Based on (VTK's vtkMeanValueCoordinatesInterpolator's) implementation of "Spherical Barycentric Coordinates" 2006 paper Eurographics Symposium on Geometry Processing by Torsten Langer, Alexander Belyaev and Hans-Peter Seide

Source files

• pointMVCWeight.H
• pointMVCWeight.C

Definition at line 65 of file pointMVCWeight.H.

Constructor & Destructor Documentation

pointMVCWeight()

pointMVCWeight	(	const polyMesh &	mesh,
		const vector &	position,
		const label	celli,
		const label	facei = -1
	)

Definition at line 239 of file pointMVCWeight.C.

References f(), forAll, Foam::mag(), mesh, and Foam::pid().

Here is the call graph for this function:

Member Function Documentation

calcWeights() [1/2]

void calcWeights ( const Map< label > &  toLocal, const face &  f, const DynamicList< point > &  u, const scalarField &  dist, scalarField &  weights  ) const

protected

Definition at line 37 of file pointMVCWeight.C.

References Foam::asin(), f(), forAll, Foam::mag(), Foam::pid(), and Foam::tan().

Here is the call graph for this function:

calcWeights() [2/2]

void calcWeights ( const polyMesh &  mesh, const labelList &  toGlobal, const Map< label > &  toLocal, const vector &  position, const vectorField &  uVec, const scalarField &  dist, scalarField &  weights  ) const

protected

Definition at line 78 of file pointMVCWeight.C.

References Foam::constant::atomic::alpha, Foam::asin(), f(), forAll, Foam::mag(), mesh, Foam::min(), Foam::normalised(), Foam::pid(), Foam::sin(), Foam::sum(), Foam::tan(), and Foam::Zero.

Here is the call graph for this function:

cell()

label cell ( ) const

inline

Definition at line 127 of file pointMVCWeight.H.

References pointMVCWeight::cellIndex_.

weights()

const scalarField& weights ( ) const

inline

Definition at line 133 of file pointMVCWeight.H.

References pointMVCWeight::weights_.

interpolate()

Type interpolate ( const GeometricField< Type, pointPatchField, pointMesh > &  psip ) const

inline

Definition at line 27 of file pointMVCWeightI.H.

References forAll, Foam::vertices(), and Foam::Zero.

Referenced by interpolationPointMVC< Type >::interpolate(), and surfaceAlignedSBRStressFvMotionSolver::solve().

Here is the call graph for this function:

Here is the caller graph for this function:

Member Data Documentation

cellIndex_

const label cellIndex_

protected

Definition at line 72 of file pointMVCWeight.H.

Referenced by pointMVCWeight::cell().

weights_

scalarField weights_

protected

Definition at line 75 of file pointMVCWeight.H.

Referenced by pointMVCWeight::weights().

debug

int debug

static

Definition at line 105 of file pointMVCWeight.H.

tol

Foam::scalar tol

static

Definition at line 109 of file pointMVCWeight.H.

---

The documentation for this class was generated from the following files:

• src/finiteVolume/interpolation/interpolation/interpolationPointMVC/pointMVCWeight.H
• src/finiteVolume/interpolation/interpolation/interpolationPointMVC/pointMVCWeight.C
• src/finiteVolume/interpolation/interpolation/interpolationPointMVC/pointMVCWeightI.H
