pointLinear< Type > Class Template Reference

Face-point interpolation scheme class derived from linear and returns linear weighting factors but also applies an explicit correction. More...

Inheritance diagram for pointLinear< Type >:

Collaboration diagram for pointLinear< Type >:

Public Member Functions
	TypeName ("pointLinear")
	pointLinear (const fvMesh &mesh)
	pointLinear (const fvMesh &mesh, Istream &)
	pointLinear (const fvMesh &mesh, const surfaceScalarField &, Istream &)
virtual bool	corrected () const
virtual tmp< GeometricField< Type, fvsPatchField, surfaceMesh > >	correction (const GeometricField< Type, fvPatchField, volMesh > &vf) const
Public Member Functions inherited from linear< Type >
	TypeName ("linear")
	linear (const fvMesh &mesh)
	linear (const fvMesh &mesh, Istream &)
	linear (const fvMesh &mesh, const surfaceScalarField &, Istream &)
tmp< surfaceScalarField >	weights (const GeometricField< Type, fvPatchField, volMesh > &) const
	linear (const Specie &sp, const scalar psi, const scalar rho0)
	linear (const dictionary &dict)
	linear (const word &name, const linear &)
autoPtr< linear >	clone () const
scalar	rho (scalar p, scalar T) const
scalar	H (const scalar p, const scalar T) const
scalar	Cp (scalar p, scalar T) const
scalar	E (const scalar p, const scalar T) const
scalar	Cv (scalar p, scalar T) const
scalar	S (const scalar p, const scalar T) const
scalar	psi (scalar p, scalar T) const
scalar	Z (scalar p, scalar T) const
scalar	CpMCv (scalar p, scalar T) const
void	write (Ostream &os) const
void	operator+= (const linear &)
void	operator*= (const scalar)
Public Member Functions inherited from surfaceInterpolationScheme< Type >
	TypeName ("surfaceInterpolationScheme")
	declareRunTimeSelectionTable (tmp, surfaceInterpolationScheme, Mesh,(const fvMesh &mesh, Istream &schemeData),(mesh, schemeData))
	declareRunTimeSelectionTable (tmp, surfaceInterpolationScheme, MeshFlux,(const fvMesh &mesh, const surfaceScalarField &faceFlux, Istream &schemeData),(mesh, faceFlux, schemeData))
	surfaceInterpolationScheme (const fvMesh &mesh)
virtual	~surfaceInterpolationScheme ()=default
const fvMesh &	mesh () const
virtual tmp< GeometricField< typename innerProduct< vector, Type >::type, fvsPatchField, surfaceMesh > >	dotInterpolate (const surfaceVectorField &Sf, const GeometricField< Type, fvPatchField, volMesh > &vf) const
tmp< GeometricField< typename innerProduct< vector, Type >::type, fvsPatchField, surfaceMesh > >	dotInterpolate (const surfaceVectorField &Sf, const tmp< GeometricField< Type, fvPatchField, volMesh >> &) const
virtual tmp< GeometricField< Type, fvsPatchField, surfaceMesh > >	interpolate (const GeometricField< Type, fvPatchField, volMesh > &) const
tmp< GeometricField< Type, fvsPatchField, surfaceMesh > >	interpolate (const tmp< GeometricField< Type, fvPatchField, volMesh >> &) const
Public Member Functions inherited from refCount
constexpr	refCount () noexcept
int	count () const noexcept
bool	unique () const noexcept
void	operator++ () noexcept
void	operator++ (int) noexcept
void	operator-- () noexcept
void	operator-- (int) noexcept

Additional Inherited Members
Static Public Member Functions inherited from linear< Type >
static autoPtr< linear >	New (const dictionary &dict)
static word	typeName ()
Static Public Member Functions inherited from surfaceInterpolationScheme< Type >
static tmp< surfaceInterpolationScheme< Type > >	New (const fvMesh &mesh, Istream &schemeData)
static tmp< surfaceInterpolationScheme< Type > >	New (const fvMesh &mesh, const surfaceScalarField &faceFlux, Istream &schemeData)
static tmp< GeometricField< Type, fvsPatchField, surfaceMesh > >	interpolate (const GeometricField< Type, fvPatchField, volMesh > &, const tmp< surfaceScalarField > &, const tmp< surfaceScalarField > &)
template<class SFType >
static tmp< GeometricField< typename innerProduct< typename SFType::value_type, Type >::type, fvsPatchField, surfaceMesh > >	dotInterpolate (const SFType &Sf, const GeometricField< Type, fvPatchField, volMesh > &vf, const tmp< surfaceScalarField > &tlambdas)
static tmp< GeometricField< Type, fvsPatchField, surfaceMesh > >	interpolate (const GeometricField< Type, fvPatchField, volMesh > &, const tmp< surfaceScalarField > &)
Static Public Attributes inherited from linear< Type >
static const bool	incompressible = false
static const bool	isochoric = false

Detailed Description

template<class Type>
class Foam::pointLinear< Type >

Face-point interpolation scheme class derived from linear and returns linear weighting factors but also applies an explicit correction.

Uses volPointInterpolation to obtain the field values at the face-points.

Source files

• pointLinear.H
• pointLinear.C

Definition at line 53 of file pointLinear.H.

Constructor & Destructor Documentation

pointLinear() [1/3]

pointLinear ( const fvMesh &  mesh )

inline

Definition at line 75 of file pointLinear.H.

pointLinear() [2/3]

pointLinear ( const fvMesh &  mesh, Istream &    )

inline

Definition at line 83 of file pointLinear.H.

pointLinear() [3/3]

pointLinear ( const fvMesh &  mesh, const surfaceScalarField &  , Istream &    )

inline

Definition at line 94 of file pointLinear.H.

Member Function Documentation

TypeName()

TypeName

(

"pointLinear< Type >"

)

corrected()

virtual bool corrected ( ) const

inlinevirtual

Reimplemented from surfaceInterpolationScheme< Type >.

Definition at line 107 of file pointLinear.H.

correction()

Foam::tmp< Foam::GeometricField< Type, Foam::fvsPatchField, Foam::surfaceMesh > > correction ( const GeometricField< Type, fvPatchField, volMesh > &  vf ) const

virtual

Reimplemented from surfaceInterpolationScheme< Type >.

Definition at line 32 of file pointLinear.C.

References fvsPatchField::coupled(), f(), fvPatch::faceCells(), forAll, Foam::fac::interpolate(), Foam::linearInterpolate(), triangle::mag(), mesh, Foam::New(), Foam::constant::mathematical::pi(), points, tmp::ref(), fvPatch::start(), and Foam::Zero.

Here is the call graph for this function:

---

The documentation for this class was generated from the following files:

• src/finiteVolume/interpolation/surfaceInterpolation/schemes/pointLinear/pointLinear.H
• src/finiteVolume/interpolation/surfaceInterpolation/schemes/pointLinear/pointLinear.C
