Fast topological mesh-wave method for calculating the distance to nearest patch for all cells and boundary. More...

Inheritance diagram for meshWave:

Collaboration diagram for meshWave:

Public Member Functions
	TypeName ("meshWave")

	meshWave (const dictionary &dict, const fvMesh &mesh, const labelHashSet &patchIDs)

	meshWave (const fvMesh &mesh, const labelHashSet &patchIDs, const bool correctWalls=true)

virtual bool	correct (volScalarField &y)

virtual bool	correct (volScalarField &y, volVectorField &n)

Public Member Functions inherited from patchDistMethod
	TypeName ("patchDistMethod")

	declareRunTimeSelectionTable (autoPtr, patchDistMethod, dictionary,(const dictionary &dict, const fvMesh &mesh, const labelHashSet &patchIDs),(dict, mesh, patchIDs))

	patchDistMethod (const fvMesh &mesh, const labelHashSet &patchIDs)

virtual	~patchDistMethod ()

const labelHashSet &	patchIDs () const

virtual bool	movePoints ()

virtual void	updateMesh (const mapPolyMesh &)

template<class Type >
Foam::wordList	patchTypes (const fvMesh &mesh, const labelHashSet &patchIDs)

Protected Attributes
const bool	correctWalls_

label	nUnset_

Protected Attributes inherited from patchDistMethod
const fvMesh &	mesh_

const labelHashSet	patchIDs_

Additional Inherited Members
Static Public Member Functions inherited from patchDistMethod
static autoPtr< patchDistMethod >	New (const dictionary &dict, const fvMesh &mesh, const labelHashSet &patchIDs, const word &defaultPatchDistMethod=word::null)

template<class Type >
static wordList	patchTypes (const fvMesh &mesh, const labelHashSet &patchIDs)

Protected Member Functions inherited from patchDistMethod
	patchDistMethod (const patchDistMethod &)=delete

void	operator= (const patchDistMethod &)=delete

Detailed Description

Fast topological mesh-wave method for calculating the distance to nearest patch for all cells and boundary.

For regular/un-distorted meshes this method is accurate but for skewed, non-orthogonal meshes it is approximate with the error increasing with the degree of mesh distortion. The distance from the near-wall cells to the boundary may optionally be corrected for mesh distortion by setting correctWalls = true.

Example of the wallDist specification in fvSchemes:

    wallDist
    {
        method meshWave;

        // Optional entry enabling the calculation
        // of the normal-to-wall field
        nRequired false;
    }

See also: Foam::patchDistMethod::Poisson Foam::wallDist

Source files

Definition at line 72 of file meshWavePatchDistMethod.H.

Constructor & Destructor Documentation

◆ meshWave() [1/2]

meshWave	(	const dictionary &	dict,
		const fvMesh &	mesh,
		const labelHashSet &	patchIDs
	)

Definition at line 45 of file meshWavePatchDistMethod.C.

◆ meshWave() [2/2]

meshWave	(	const fvMesh &	mesh,
		const labelHashSet &	patchIDs,
		const bool	correctWalls = `true`
	)

Definition at line 58 of file meshWavePatchDistMethod.C.

Member Function Documentation

◆ TypeName()

TypeName ( "meshWave" )

◆ correct() [1/2]

bool correct ( volScalarField & y )

virtual

Implements patchDistMethod.

Reimplemented in directionalMeshWave.

Definition at line 72 of file meshWavePatchDistMethod.C.

References meshWave::correctWalls_, Foam::dimLength, patchWave::distance(), forAll, patchDistMethod::mesh_, patchWave::nUnset(), meshWave::nUnset_, patchWave::patchDistance(), patchDistMethod::patchIDs_, and y.

Here is the call graph for this function:

◆ correct() [2/2]

bool correct	(	volScalarField &	y,
		volVectorField &	n
	)

virtual

Implements patchDistMethod.

Reimplemented in directionalMeshWave.

Definition at line 103 of file meshWavePatchDistMethod.C.

References patchDataWave< TransferType, TrackingData >::cellData(), Foam::dimLength, patchDataWave< TransferType, TrackingData >::distance(), forAll, n, patchDataWave< TransferType, TrackingData >::nUnset(), patchDataWave< TransferType, TrackingData >::patchData(), patchDataWave< TransferType, TrackingData >::patchDistance(), UPtrList::set(), and y.

Here is the call graph for this function:

Member Data Documentation

◆ correctWalls_

const bool correctWalls_

protected

Definition at line 81 of file meshWavePatchDistMethod.H.

Referenced by meshWave::correct().

◆ nUnset_

label nUnset_

mutableprotected

Definition at line 84 of file meshWavePatchDistMethod.H.
