Variant of meshWave distance-to-patch method. More...

Inheritance diagram for directionalMeshWave:

Collaboration diagram for directionalMeshWave:

Public Member Functions
	TypeName ("directionalMeshWave")

	directionalMeshWave (const dictionary &dict, const fvMesh &mesh, const labelHashSet &patchIDs)

virtual bool	correct (volScalarField &y)

virtual bool	correct (volScalarField &y, volVectorField &n)

Public Member Functions inherited from meshWave
	TypeName ("meshWave")

	meshWave (const dictionary &dict, const fvMesh &mesh, const labelHashSet &patchIDs)

	meshWave (const fvMesh &mesh, const labelHashSet &patchIDs, const bool correctWalls=true)

Public Member Functions inherited from patchDistMethod
	TypeName ("patchDistMethod")

	declareRunTimeSelectionTable (autoPtr, patchDistMethod, dictionary,(const dictionary &dict, const fvMesh &mesh, const labelHashSet &patchIDs),(dict, mesh, patchIDs))

	patchDistMethod (const fvMesh &mesh, const labelHashSet &patchIDs)

virtual	~patchDistMethod ()

const labelHashSet &	patchIDs () const

virtual bool	movePoints ()

virtual void	updateMesh (const mapPolyMesh &)

template<class Type >
Foam::wordList	patchTypes (const fvMesh &mesh, const labelHashSet &patchIDs)

Additional Inherited Members
Static Public Member Functions inherited from patchDistMethod
static autoPtr< patchDistMethod >	New (const dictionary &dict, const fvMesh &mesh, const labelHashSet &patchIDs, const word &defaultPatchDistMethod=word::null)

template<class Type >
static wordList	patchTypes (const fvMesh &mesh, const labelHashSet &patchIDs)

Protected Member Functions inherited from patchDistMethod
	patchDistMethod (const patchDistMethod &)=delete

void	operator= (const patchDistMethod &)=delete

Protected Attributes inherited from meshWave
const bool	correctWalls_

label	nUnset_

Protected Attributes inherited from patchDistMethod
const fvMesh &	mesh_

const labelHashSet	patchIDs_

Detailed Description

Variant of meshWave distance-to-patch method.

Ignores the component in the specified direction. Can be used e.g. to calculate the distance in the z-direction only.

Usage

Example of specification in fvSchemes.wallDist:

    wallDist
    {
        // Mandatory entries (unmodifiable)
        method      directionalMeshWave;
        n           (0 0 1);

        // Optional (inherited) entries (unmodifiable)
        ...
    }

where the entries mean:

Property	Description	Type	Req'd	Dflt
`method`	Method name: directionalMeshWave	word	yes	-
`n`	The direction component to ignore	vector	yes	-

The inherited entries are elaborated in:

meshWavePatchDistMethod.H

See also: Foam::wallDist Foam::patchDistMethod::meshWave Foam::patchDistMethod::Poisson Foam::directionalWallPoint

Source files

Definition at line 99 of file directionalMeshWavePatchDistMethod.H.

Constructor & Destructor Documentation

◆ directionalMeshWave()

directionalMeshWave	(	const dictionary &	dict,
		const fvMesh &	mesh,
		const labelHashSet &	patchIDs
	)

Definition at line 48 of file directionalMeshWavePatchDistMethod.C.

Member Function Documentation

◆ TypeName()

TypeName ( "directionalMeshWave" )

◆ correct() [1/2]

bool correct ( volScalarField & y )

virtual

Reimplemented from meshWave.

Definition at line 61 of file directionalMeshWavePatchDistMethod.C.

References fvMesh::boundary(), Foam::dimLength, Foam::dimless, patchDistMethod::mesh_, n, IOobject::NO_READ, IOobject::NO_WRITE, patches, patchDistMethod::patchIDs_, y, and Foam::Zero.

Here is the call graph for this function:

◆ correct() [2/2]

bool correct	(	volScalarField &	y,
		volVectorField &	n
	)

virtual

Reimplemented from meshWave.

Definition at line 95 of file directionalMeshWavePatchDistMethod.C.

References patchDataWave< TransferType, TrackingData >::cellData(), Foam::dimLength, patchDataWave< TransferType, TrackingData >::distance(), forAll, n, patchDataWave< TransferType, TrackingData >::nUnset(), patchDataWave< TransferType, TrackingData >::patchData(), patchDataWave< TransferType, TrackingData >::patchDistance(), UPtrList::set(), and y.
