Takes a set of patches to start MeshWave from. More...

Inheritance diagram for patchDataWave< TransferType, TrackingData >:

Collaboration diagram for patchDataWave< TransferType, TrackingData >:

Public Member Functions
	patchDataWave (const polyMesh &mesh, const labelHashSet &patchIDs, const UPtrList< Field< Type >> &initialPatchValuePtrs, const bool correctWalls=true, TrackingData &td=dummyTrackData_)

virtual	~patchDataWave ()

virtual void	correct ()

const scalarField &	distance () const

scalarField &	distance ()

const FieldField< Field, scalar > &	patchDistance () const

FieldField< Field, scalar > &	patchDistance ()

const Field< Type > &	cellData () const

Field< Type > &	cellData ()

const FieldField< Field, Type > &	patchData () const

FieldField< Field, Type > &	patchData ()

label	nUnset () const

Public Member Functions inherited from cellDistFuncs
	ClassName ("cellDistFuncs")

	cellDistFuncs (const polyMesh &mesh)

const polyMesh &	mesh () const

labelHashSet	getPatchIDs (const UList< wordRe > &patchNames) const

template<class Type >
labelHashSet	getPatchIDs () const

scalar	smallestDist (const point &p, const polyPatch &patch, const labelUList &wallFaces, label &meshFacei) const

void	getPointNeighbours (const primitivePatch &, const label patchFacei, DynamicList< label > &) const

label	maxPatchSize (const labelHashSet &patchIDs) const

label	sumPatchSize (const labelHashSet &patchIDs) const

void	correctBoundaryFaceCells (const labelHashSet &patchIDs, scalarField &wallDistCorrected, Map< label > &nearestFace) const

void	correctBoundaryPointCells (const labelHashSet &patchIDs, scalarField &wallDistCorrected, Map< label > &nearestFace) const

template<class Type >
Foam::labelHashSet	getPatchIDs () const

Detailed Description

template<class TransferType, class TrackingData = int>
class Foam::patchDataWave< TransferType, TrackingData >

Takes a set of patches to start MeshWave from.

Holds after construction distance at cells and distance at patches (like patchWave), but also additional transported data. It is used, for example, in the y+ calculation.

See also: The patchWave class.

Source files

Definition at line 62 of file patchDataWave.H.

Constructor & Destructor Documentation

◆ patchDataWave()

patchDataWave	(	const polyMesh &	mesh,
		const labelHashSet &	patchIDs,
		const UPtrList< Field< Type >> &	initialPatchValuePtrs,
		const bool	correctWalls = `true`,
		TrackingData &	td = `dummyTrackData_`
	)
