Public Member Functions | List of all members
outletStabilised< Type > Class Template Reference
Numerics » Finite volume numerical schemes » Surface interpolation schemes

Outlet-stabilised interpolation scheme which applies upwind differencing to the faces of the cells adjacent to outlets. More...

Inheritance diagram for outletStabilised< Type >:
Inheritance graph
[legend]
Collaboration diagram for outletStabilised< Type >:
Collaboration graph
[legend]

Public Member Functions

 TypeName ("outletStabilised")

 outletStabilised (const fvMesh &mesh, Istream &is)

 outletStabilised (const fvMesh &mesh, const surfaceScalarField &faceFlux, Istream &is)

tmp< surfaceScalarField > weights (const GeometricField< Type, fvPatchField, volMesh > &vf) const

virtual bool corrected () const

virtual tmp< GeometricField< Type, fvsPatchField, surfaceMesh > > correction (const GeometricField< Type, fvPatchField, volMesh > &vf) const

- Public Member Functions inherited from surfaceInterpolationScheme< Type >
 TypeName ("surfaceInterpolationScheme")

 declareRunTimeSelectionTable (tmp, surfaceInterpolationScheme, Mesh,(const fvMesh &mesh, Istream &schemeData),(mesh, schemeData))

 declareRunTimeSelectionTable (tmp, surfaceInterpolationScheme, MeshFlux,(const fvMesh &mesh, const surfaceScalarField &faceFlux, Istream &schemeData),(mesh, faceFlux, schemeData))

 surfaceInterpolationScheme (const fvMesh &mesh)

virtual ~surfaceInterpolationScheme ()=default

const fvMesh & mesh () const

virtual tmp< GeometricField< typename innerProduct< vector, Type >::type, fvsPatchField, surfaceMesh > > dotInterpolate (const surfaceVectorField &Sf, const GeometricField< Type, fvPatchField, volMesh > &vf) const

tmp< GeometricField< typename innerProduct< vector, Type >::type, fvsPatchField, surfaceMesh > > dotInterpolate (const surfaceVectorField &Sf, const tmp< GeometricField< Type, fvPatchField, volMesh >> &) const

virtual tmp< GeometricField< Type, fvsPatchField, surfaceMesh > > interpolate (const GeometricField< Type, fvPatchField, volMesh > &) const

tmp< GeometricField< Type, fvsPatchField, surfaceMesh > > interpolate (const tmp< GeometricField< Type, fvPatchField, volMesh >> &) const

- Public Member Functions inherited from refCount
constexpr refCount () noexcept

int count () const noexcept

bool unique () const noexcept

void operator++ () noexcept

void operator++ (int) noexcept

void operator-- () noexcept

void operator-- (int) noexcept


Additional Inherited Members

- Static Public Member Functions inherited from surfaceInterpolationScheme< Type >
static tmp< surfaceInterpolationScheme< Type > > New (const fvMesh &mesh, Istream &schemeData)

static tmp< surfaceInterpolationScheme< Type > > New (const fvMesh &mesh, const surfaceScalarField &faceFlux, Istream &schemeData)

static tmp< GeometricField< Type, fvsPatchField, surfaceMesh > > interpolate (const GeometricField< Type, fvPatchField, volMesh > &, const tmp< surfaceScalarField > &, const tmp< surfaceScalarField > &)

template<class SFType >
static tmp< GeometricField< typename innerProduct< typename SFType::value_type, Type >::type, fvsPatchField, surfaceMesh > > dotInterpolate (const SFType &Sf, const GeometricField< Type, fvPatchField, volMesh > &vf, const tmp< surfaceScalarField > &tlambdas)

static tmp< GeometricField< Type, fvsPatchField, surfaceMesh > > interpolate (const GeometricField< Type, fvPatchField, volMesh > &, const tmp< surfaceScalarField > &)


Detailed Description

template<class Type>
class Foam::outletStabilised< Type >

Outlet-stabilised interpolation scheme which applies upwind differencing to the faces of the cells adjacent to outlets.

This is particularly useful to stabilise the velocity at entrainment boundaries for LES cases using linear or other centred differencing schemes.

Source files

Definition at line 61 of file outletStabilised.H.

Constructor & Destructor Documentation

◆ outletStabilised() [1/2]

outletStabilised ( const fvMesh &  mesh,
Istream &  is
)
inline

Definition at line 90 of file outletStabilised.H.

◆ outletStabilised() [2/2]

outletStabilised ( const fvMesh &  mesh,
const surfaceScalarField &  faceFlux,
Istream &  is
)
inline

Definition at line 112 of file outletStabilised.H.

Member Function Documentation

◆ TypeName()

TypeName ( "outletStabilised< Type >"  )

◆ weights()

tmp<surfaceScalarField> weights ( const GeometricField< Type, fvPatchField, volMesh > &  vf) const
inlinevirtual

Implements surfaceInterpolationScheme< Type >.

Definition at line 131 of file outletStabilised.H.

References fvMesh::boundary(), GeometricField::boundaryField(), cells, primitiveMesh::cells(), fvBoundaryMesh::faceCells(), forAll, Foam::isA(), primitiveMesh::isInternalFace(), surfaceInterpolationScheme< Type >::mesh(), Foam::pos0(), and tmp::ref().

Here is the call graph for this function:

◆ corrected()

virtual bool corrected ( ) const
inlinevirtual

Reimplemented from surfaceInterpolationScheme< Type >.

Definition at line 177 of file outletStabilised.H.

Referenced by outletStabilised< Type >::correction().

Here is the caller graph for this function:

◆ correction()

virtual tmp<GeometricField<Type, fvsPatchField, surfaceMesh> > correction ( const GeometricField< Type, fvPatchField, volMesh > &  vf) const
inlinevirtual

Reimplemented from surfaceInterpolationScheme< Type >.

Definition at line 186 of file outletStabilised.H.

References fvMesh::boundary(), GeometricField::boundaryField(), cells, primitiveMesh::cells(), outletStabilised< Type >::corrected(), fvBoundaryMesh::faceCells(), forAll, Foam::isA(), primitiveMesh::isInternalFace(), surfaceInterpolationScheme< Type >::mesh(), tmp::ref(), and Foam::Zero.

Here is the call graph for this function:
The documentation for this class was generated from the following file:
