orientedSurface Class Reference

Given point flip all faces such that normals point in same direction. More...

Inheritance diagram for orientedSurface:
Inheritance graph
[legend]
Collaboration diagram for orientedSurface:
Collaboration graph
[legend]

Public Types

enum  sideStat { UNVISITED, FLIP, NOFLIP }

- Public Types inherited from triSurface
typedef bool BoundaryMesh

typedef labelledTri face_type

typedef point point_type

- Public Types inherited from PrimitivePatch<::Foam::List< labelledTri >, pointField >
enum  surfaceTopo

typedef std::remove_reference< ::Foam::List< labelledTri > >::type::value_type face_type

typedef std::remove_reference< pointField >::type::value_type point_type

typedef ::Foam::List< labelledTri > FaceListType

typedef pointField PointFieldType

typedef face_type FaceType

- Public Types inherited from List< labelledTri >
typedef SubList< T > subList


Public Member Functions

 ClassName ("orientedSurface")

 orientedSurface ()

 orientedSurface (const triSurface &, const point &samplePoint, const bool orientOutside=true)

 orientedSurface (const triSurface &, const bool orientOutside=true)

- Public Member Functions inherited from triSurface
 ClassName ("triSurface")

 triSurface ()

 triSurface (const triSurface &surf)

 triSurface (triSurface &&surf)

 triSurface (const List< labelledTri > &triangles, const geometricSurfacePatchList &patches, const pointField &pts)

 triSurface (List< labelledTri > &triangles, const geometricSurfacePatchList &patches, pointField &pts, const bool reuse)

 triSurface (const List< labelledTri > &triangles, const pointField &pts)

 triSurface (const triFaceList &triangles, const pointField &pts)

 triSurface (const fileName &name, const scalar scaleFactor=-1)

 triSurface (const fileName &name, const word &fileType, const scalar scaleFactor=-1)

 triSurface (Istream &is)

 triSurface (const Time &d)

 triSurface (const IOobject &io, const dictionary &dict, const bool isGlobal=true)

virtual ~triSurface ()

void clearOut ()

void clearTopology ()

void clearPatchMeshAddr ()

void swap (triSurface &surf)

const geometricSurfacePatchList & patches () const noexcept

geometricSurfacePatchList & patches () noexcept

const List< labelledTri > & surfFaces () const noexcept

const labelListList & sortedEdgeFaces () const

const labelList & edgeOwner () const

const vectorField & Sf () const

const scalarField & magSf () const

const vectorField & Cf () const

List< surfZone > sortedZones (labelList &faceMap) const

void triFaceFaces (List< face > &plainFaceList) const

virtual void movePoints (const pointField &pts)

virtual void swapPoints (pointField &pts)

virtual void scalePoints (const scalar scaleFactor)

void checkTriangles (const bool verbose)

void checkEdges (const bool verbose)

void cleanup (const bool verbose)

void compactPoints (labelList &pointMap=const_cast< labelList & >(labelList::null()))

void markZone (const boolList &borderEdge, const label facei, const label currentZone, labelList &faceZone) const

label markZones (const boolList &borderEdge, labelList &faceZone) const

template<class BoolListType >
void subsetMeshMap (const BoolListType &include, labelList &pointMap, labelList &faceMap) const

triSurface subsetMesh (const UList< bool > &include, labelList &pointMap, labelList &faceMap) const

triSurface subsetMesh (const bitSet &include, labelList &pointMap, labelList &faceMap) const

triSurface subsetMesh (const UList< bool > &include) const

triSurface subsetMesh (const bitSet &include) const

triSurface subsetMesh (const wordRes &includeNames, const wordRes &excludeNames=wordRes()) const

void swapFaces (List< labelledTri > &faceLst)

void transfer (triSurface &surf)

void transfer (MeshedSurface< labelledTri > &surf)

void write (Ostream &os) const

void write (const fileName &, const bool sortByRegion=false) const

void write (const fileName &filename, const word &fileType, const bool sortByRegion=false) const

void write (const Time &d) const

void writeStats (Ostream &os) const

void operator= (const triSurface &surf)

void operator= (triSurface &&surf)

void operator= (MeshedSurface< labelledTri > &&surf)

- Public Member Functions inherited from PrimitivePatch<::Foam::List< labelledTri >, pointField >
 PrimitivePatch (const ::Foam::List< labelledTri > &faces, const pointField &points)

 PrimitivePatch (::Foam::List< labelledTri > &&faces, const pointField &points)

 PrimitivePatch (::Foam::List< labelledTri > &faces, pointField &points, const bool reuse)

 PrimitivePatch (const PrimitivePatch< ::Foam::List< labelledTri >, pointField > &pp)

virtual ~PrimitivePatch ()

void clearOut ()

void clearGeom ()

void clearTopology ()

void clearPatchMeshAddr ()

void swap (PrimitivePatch &)=delete

const Field< point_type > & points () const noexcept

label nFaces () const noexcept

label nPoints () const

label nEdges () const

const edgeList & edges () const

const edgeList::subList internalEdges () const

const edgeList::subList boundaryEdges () const

label nInternalEdges () const

label nBoundaryEdges () const

bool isInternalEdge (const label edgei) const

const labelList & boundaryPoints () const

const labelListList & faceFaces () const

const labelListList & edgeFaces () const

const labelListList & faceEdges () const

const labelListList & pointEdges () const

const labelListList & pointFaces () const

const List< face_type > & localFaces () const

labelList boundaryFaces () const

labelList uniqBoundaryFaces () const

const labelList & meshPoints () const

const Map< label > & meshPointMap () const

const Field< point_type > & localPoints () const

const labelList & localPointOrder () const

label whichPoint (const label gp) const

edge meshEdge (const label edgei) const

edge meshEdge (const edge &e) const

label meshEdge (const label edgei, const edgeList &allEdges, const labelListList &pointEdges) const

label findEdge (const edge &e) const

labelList meshEdges (const edgeList &allEdges, const labelListList &cellEdges, const labelList &faceCells) const

labelList meshEdges (const edgeList &allEdges, const labelListList &pointEdges) const

labelList meshEdges (const labelUList &edgeLabels, const edgeList &allEdges, const labelListList &pointEdges) const

const Field< point_type > & faceCentres () const

const Field< point_type > & faceAreas () const

const Field< scalar > & magFaceAreas () const

const Field< point_type > & faceNormals () const

const Field< point_type > & pointNormals () const

bool hasFaceAreas () const

bool hasFaceCentres () const

bool hasFaceNormals () const

bool hasPointNormals () const

bool hasBoundaryPoints () const

bool hasFaceFaces () const

bool hasEdgeFaces () const

bool hasFaceEdges () const

bool hasPointEdges () const

bool hasPointFaces () const

bool hasMeshPointMap () const

List< objectHit > projectPoints (const ToPatch &targetPatch, const Field< point_type > &projectionDirection, const intersection::algorithm=intersection::FULL_RAY, const intersection::direction=intersection::VECTOR) const

Foam::List< Foam::objectHit > projectPoints (const ToPatch &targetPatch, const Field< typename Foam::PrimitivePatch< ::Foam::List< labelledTri >, pointField >::point_type > &projectionDirection, const intersection::algorithm alg, const intersection::direction dir) const

List< objectHit > projectFaceCentres (const ToPatch &targetPatch, const Field< point_type > &projectionDirection, const intersection::algorithm=intersection::FULL_RAY, const intersection::direction=intersection::VECTOR) const

Foam::List< Foam::objectHit > projectFaceCentres (const ToPatch &targetPatch, const Field< typename Foam::PrimitivePatch< ::Foam::List< labelledTri >, pointField >::point_type > &projectionDirection, const intersection::algorithm alg, const intersection::direction dir) const

const labelListList & edgeLoops () const

surfaceTopo surfaceType () const

bool checkTopology (const bool report=false, labelHashSet *setPtr=nullptr) const

bool checkPointManifold (const bool report=false, labelHashSet *setPtr=nullptr) const

virtual void movePoints (const Field< point_type > &)

void operator= (const PrimitivePatch< ::Foam::List< labelledTri >, pointField > &rhs)

void operator= (PrimitivePatch< ::Foam::List< labelledTri >, pointField > &&rhs)

label whichEdge (const edge &e) const

- Public Member Functions inherited from PrimitivePatchBase
 ClassName ("PrimitivePatch")

 PrimitivePatchBase ()=default

- Public Member Functions inherited from List< labelledTri >
constexpr List () noexcept

 List (const label len)

 List (const label len, const T &val)

 List (const label len, const Foam::zero)

 List (const Foam::one, const T &val)

 List (const Foam::one, T &&val)

 List (const Foam::one, const Foam::zero)

 List (const List< T > &a)

 List (const UList< T > &a)

 List (List< T > &a, bool reuse)

 List (const UList< T > &list, const labelUList &indices)

 List (const UList< T > &list, const FixedList< label, N > &indices)

 List (const FixedList< T, N > &list)

 List (const PtrList< T > &list)

 List (const SLList< T > &list)

 List (const IndirectListBase< T, Addr > &list)

 List (std::initializer_list< T > list)

 List (List< T > &&list)

 List (DynamicList< T, SizeMin > &&list)

 List (SortableList< T > &&list)

 List (SLList< T > &&list)

 List (Istream &is)

 List (const label len)

 List (const label len, const T &val)

 List (const label len, const Foam::zero)

 List (const Foam::one, const T &val)

 List (const Foam::one, T &&val)

 List (const Foam::one, const Foam::zero)

 List (const UList< T > &a)

 List (const List< T > &a)

 List (List< T > &a, bool reuse)

 List (const UList< T > &list, const labelUList &indices)

 List (const PtrList< T > &list)

 List (const SLList< T > &list)

 List (std::initializer_list< T > list)

 List (List< T > &&list)

 List (SortableList< T > &&list)

 List (SLList< T > &&list)

constexpr List () noexcept

 List (Istream &is)

autoPtr< List< T > > clone () const

 ~List ()

void clear ()

void resize (const label len)

void resize (const label len, const T &val)

void resize (const label newLen)

void resize_nocopy (const label len)

void setSize (const label n)

void setSize (const label n, const T &val)

void append (const T &val)

void append (T &&val)

void append (const UList< T > &list)

void append (const IndirectListBase< T, Addr > &list)

void append (const T &val)

void append (T &&val)

void append (const UList< T > &list)

label appendUniq (const T &val)

void transfer (List< T > &list)

void transfer (DynamicList< T, SizeMin > &list)

void transfer (SortableList< T > &list)

void transfer (List< T > &list)

void transfer (SortableList< T > &list)

T & newElmt (const label i)

void operator= (const UList< T > &a)

void operator= (const List< T > &list)

void operator= (const SLList< T > &list)

void operator= (const IndirectListBase< T, Addr > &list)

void operator= (const FixedList< T, N > &list)

void operator= (std::initializer_list< T > list)

void operator= (const T &val)

void operator= (const Foam::zero)

void operator= (List< T > &&list)

void operator= (DynamicList< T, SizeMin > &&list)

void operator= (SortableList< T > &&list)

void operator= (SLList< T > &&list)

void operator= (const UList< T > &a)

void operator= (const List< T > &list)

void operator= (const SLList< T > &list)

void operator= (std::initializer_list< T > list)

void operator= (List< T > &&list)

void operator= (SortableList< T > &&list)

void operator= (SLList< T > &&list)

void operator= (const T &val)

void operator= (const Foam::zero)

Istream & readList (Istream &is)

Istream & readList (Istream &is)

Istream & readList (Istream &is)

void shallowCopy (const UList< T > &)=delete

std::enable_if< std::is_same< bool, TypeT >::value, bool >::type set (const label i, bool val=true)


Static Public Member Functions

static bool orient (triSurface &, const point &, const bool orientOutside)

static bool orient (triSurface &s, const triSurfaceSearch &querySurf, const point &samplePoint, const bool orientOutside)

- Static Public Member Functions inherited from triSurface
static fileName triSurfInstance (const Time &)

static wordHashSet readTypes ()

static wordHashSet writeTypes ()

static bool canReadType (const word &fileType, bool verbose=false)

static bool canWriteType (const word &fileType, bool verbose=false)

static bool canRead (const fileName &name, bool verbose=false)

static fileName relativeFilePath (const IOobject &io, const fileName &f, const bool isGlobal=true)

static fileName checkFile (const IOobject &io, const bool isGlobal=true)

static fileName checkFile (const IOobject &io, const dictionary &dict, const bool isGlobal=true)

static fileName findFile (const IOobject &io, const bool isGlobal=true)

static fileName findFile (const IOobject &io, const dictionary &dict, const bool isGlobal=true)

static autoPtr< triSurface > New (const fileName &name, const word &fileType)

static autoPtr< triSurface > New (const fileName &name)

- Static Public Member Functions inherited from List< labelledTri >
static const List< T > & null ()


Additional Inherited Members

- Protected Member Functions inherited from triSurface
pointField & storedPoints ()

List< labelledTri > & storedFaces ()


Detailed Description

Given point flip all faces such that normals point in same direction.

Source files

Definition at line 51 of file orientedSurface.H.

Member Enumeration Documentation

◆ sideStat

enum sideStat
Enumerator
UNVISITED
FLIP
NOFLIP

Definition at line 60 of file orientedSurface.H.

Constructor & Destructor Documentation

◆ orientedSurface() [1/3]

orientedSurface ( )

Definition at line 404 of file orientedSurface.C.

◆ orientedSurface() [2/3]

orientedSurface ( const triSurface &  surf,
const point &  samplePoint,
const bool  orientOutside = true
)

Definition at line 412 of file orientedSurface.C.

◆ orientedSurface() [3/3]

orientedSurface ( const triSurface &  surf,
const bool  orientOutside = true
)

Definition at line 426 of file orientedSurface.C.

References boundBox::max(), PrimitivePatch< FaceList, PointField >::meshPoints(), PrimitivePatch< FaceList, PointField >::points(), and boundBox::span().

Here is the call graph for this function:

Member Function Documentation

◆ ClassName()

ClassName ( "orientedSurface"  )

◆ orient() [1/2]

bool orient ( triSurface &  s,
const point &  samplePoint,
const bool  orientOutside
)
static

Definition at line 445 of file orientedSurface.C.

References PointHit< PointType >::distance(), forAll, PointHit< PointType >::rawPoint(), and s.

Here is the call graph for this function:

◆ orient() [2/2]

bool orient ( triSurface &  s,
const triSurfaceSearch &  querySurf,
const point &  samplePoint,
const bool  orientOutside
)
static

Definition at line 515 of file orientedSurface.C.

References forAll, nZones, and s.

The documentation for this class was generated from the following files:

Copyright © 2011-2018  OpenFOAM | OPENFOAM® is a registered trademark of OpenCFD Ltd.

Generated by   doxygen 1.8.17
