nutLowReWallFunctionFvPatchScalarField Class Reference

This boundary condition provides a wall constraint on the turbulent viscosity, i.e. nut, for low Reynolds number models. It sets nut to zero, and provides an access function to calculate y+. More...

Inheritance diagram for nutLowReWallFunctionFvPatchScalarField:

Collaboration diagram for nutLowReWallFunctionFvPatchScalarField:

Public Member Functions
	TypeName ("nutLowReWallFunction")
	nutLowReWallFunctionFvPatchScalarField (const fvPatch &, const DimensionedField< scalar, volMesh > &)
	nutLowReWallFunctionFvPatchScalarField (const fvPatch &, const DimensionedField< scalar, volMesh > &, const dictionary &)
	nutLowReWallFunctionFvPatchScalarField (const nutLowReWallFunctionFvPatchScalarField &, const fvPatch &, const DimensionedField< scalar, volMesh > &, const fvPatchFieldMapper &)
	nutLowReWallFunctionFvPatchScalarField (const nutLowReWallFunctionFvPatchScalarField &)
virtual tmp< fvPatchScalarField >	clone () const
	nutLowReWallFunctionFvPatchScalarField (const nutLowReWallFunctionFvPatchScalarField &, const DimensionedField< scalar, volMesh > &)
virtual tmp< fvPatchScalarField >	clone (const DimensionedField< scalar, volMesh > &iF) const
virtual tmp< scalarField >	yPlus () const
Public Member Functions inherited from nutWallFunctionFvPatchScalarField
	TypeName ("nutWallFunction")
	nutWallFunctionFvPatchScalarField (const fvPatch &, const DimensionedField< scalar, volMesh > &)
	nutWallFunctionFvPatchScalarField (const fvPatch &, const DimensionedField< scalar, volMesh > &, const dictionary &)
	nutWallFunctionFvPatchScalarField (const nutWallFunctionFvPatchScalarField &, const fvPatch &, const DimensionedField< scalar, volMesh > &, const fvPatchFieldMapper &)
	nutWallFunctionFvPatchScalarField (const nutWallFunctionFvPatchScalarField &)
	nutWallFunctionFvPatchScalarField (const nutWallFunctionFvPatchScalarField &, const DimensionedField< scalar, volMesh > &)
scalar	Cmu () const
scalar	kappa () const
scalar	E () const
scalar	yPlusLam () const
scalar	blend (const scalar nutVis, const scalar nutLog, const scalar yPlus) const
virtual void	updateCoeffs ()
virtual void	write (Ostream &) const

Protected Member Functions
virtual tmp< scalarField >	calcNut () const
Protected Member Functions inherited from nutWallFunctionFvPatchScalarField
virtual const volVectorField &	U (const turbulenceModel &turb) const
virtual void	checkType ()
virtual void	writeLocalEntries (Ostream &) const

Additional Inherited Members
Static Public Member Functions inherited from nutWallFunctionFvPatchScalarField
static const nutWallFunctionFvPatchScalarField &	nutw (const turbulenceModel &turbModel, const label patchi)
static scalar	yPlusLam (const scalar kappa, const scalar E)
Protected Types inherited from nutWallFunctionFvPatchScalarField
enum	blendingType { STEPWISE, MAX, BINOMIAL, EXPONENTIAL }
Protected Attributes inherited from nutWallFunctionFvPatchScalarField
enum blendingType	blending_
const scalar	n_
word	UName_
scalar	Cmu_
scalar	kappa_
scalar	E_
scalar	yPlusLam_
Static Protected Attributes inherited from nutWallFunctionFvPatchScalarField
static const Enum< blendingType >	blendingTypeNames

Detailed Description

This boundary condition provides a wall constraint on the turbulent viscosity, i.e. nut, for low Reynolds number models. It sets nut to zero, and provides an access function to calculate y+.

Usage

Example of the boundary condition specification:

<patchName>
{
    // Mandatory entries (unmodifiable)
    type            nutLowReWallFunction;

    // Optional (inherited) entries
    ...
}

where the entries mean:

Property	Description	Type	Req'd	Dflt
type	Type name: nutLowReWallFunction	word	yes	-

The inherited entries are elaborated in:

• nutWallFunctionFvPatchScalarField.H

Source files

• nutLowReWallFunctionFvPatchScalarField.H
• nutLowReWallFunctionFvPatchScalarField.C

Definition at line 86 of file nutLowReWallFunctionFvPatchScalarField.H.

Constructor & Destructor Documentation

nutLowReWallFunctionFvPatchScalarField() [1/5]

nutLowReWallFunctionFvPatchScalarField	(	const fvPatch &	p,
		const DimensionedField< scalar, volMesh > &	iF
	)

Definition at line 42 of file nutLowReWallFunctionFvPatchScalarField.C.

Referenced by nutLowReWallFunctionFvPatchScalarField::clone().

Here is the caller graph for this function:

nutLowReWallFunctionFvPatchScalarField() [2/5]

nutLowReWallFunctionFvPatchScalarField	(	const fvPatch &	p,
		const DimensionedField< scalar, volMesh > &	iF,
		const dictionary &	dict
	)

Definition at line 66 of file nutLowReWallFunctionFvPatchScalarField.C.

nutLowReWallFunctionFvPatchScalarField() [3/5]

nutLowReWallFunctionFvPatchScalarField	(	const nutLowReWallFunctionFvPatchScalarField &	ptf,
		const fvPatch &	p,
		const DimensionedField< scalar, volMesh > &	iF,
		const fvPatchFieldMapper &	mapper
	)

Definition at line 53 of file nutLowReWallFunctionFvPatchScalarField.C.

nutLowReWallFunctionFvPatchScalarField() [4/5]

nutLowReWallFunctionFvPatchScalarField

(

const nutLowReWallFunctionFvPatchScalarField &

nlrwfpsf

)

Definition at line 78 of file nutLowReWallFunctionFvPatchScalarField.C.

nutLowReWallFunctionFvPatchScalarField() [5/5]

nutLowReWallFunctionFvPatchScalarField	(	const nutLowReWallFunctionFvPatchScalarField &	nlrwfpsf,
		const DimensionedField< scalar, volMesh > &	iF
	)

Definition at line 88 of file nutLowReWallFunctionFvPatchScalarField.C.

Member Function Documentation

calcNut()

Foam::tmp< Foam::scalarField > calcNut ( ) const

protectedvirtual

Implements nutWallFunctionFvPatchScalarField.

Definition at line 32 of file nutLowReWallFunctionFvPatchScalarField.C.

References tmp::New(), Foam::foamVersion::patch, and Foam::Zero.

Here is the call graph for this function:

TypeName()

TypeName

(

"nutLowReWallFunction"

)

clone() [1/2]

virtual tmp<fvPatchScalarField> clone ( ) const

inlinevirtual

Definition at line 139 of file nutLowReWallFunctionFvPatchScalarField.H.

References nutLowReWallFunctionFvPatchScalarField::nutLowReWallFunctionFvPatchScalarField().

Here is the call graph for this function:

clone() [2/2]

virtual tmp<fvPatchScalarField> clone ( const DimensionedField< scalar, volMesh > &  iF ) const

inlinevirtual

Definition at line 156 of file nutLowReWallFunctionFvPatchScalarField.H.

References nutLowReWallFunctionFvPatchScalarField::nutLowReWallFunctionFvPatchScalarField().

Here is the call graph for this function:

yPlus()

Foam::tmp< Foam::scalarField > yPlus ( ) const

virtual

Implements nutWallFunctionFvPatchScalarField.

Definition at line 100 of file nutLowReWallFunctionFvPatchScalarField.C.

References Foam::constant::atomic::group, IOobject::groupName(), Foam::mag(), turbulenceModel::nu(), turbulenceModel::nuEff(), Foam::foamVersion::patch, turbulenceModel::propertiesName, fvPatchField::snGrad(), Foam::sqrt(), U, y, and turbulenceModel::y().

Here is the call graph for this function:

---

The documentation for this class was generated from the following files:

• src/TurbulenceModels/turbulenceModels/derivedFvPatchFields/wallFunctions/nutWallFunctions/nutLowReWallFunction/nutLowReWallFunctionFvPatchScalarField.H
• src/TurbulenceModels/turbulenceModels/derivedFvPatchFields/wallFunctions/nutWallFunctions/nutLowReWallFunction/nutLowReWallFunctionFvPatchScalarField.C
