nonBlockingGaussSeidelSmoother Class Reference

Variant of gaussSeidelSmoother that expects processor boundary cells to be sorted last and so can block later. Only when the cells are actually visited does it need the results to be present. It is expected that there is little benefit to be gained from doing this on a patch by patch basis since the number of processor interfaces is quite small and the overhead of checking whether a processor interface is finished might be quite high (call into mpi). Also this would require a dynamic memory allocation to store the state of the outstanding requests. More...

Inheritance diagram for nonBlockingGaussSeidelSmoother:

Collaboration diagram for nonBlockingGaussSeidelSmoother:

Public Member Functions
	TypeName ("nonBlockingGaussSeidel")
	nonBlockingGaussSeidelSmoother (const word &fieldName, const lduMatrix &matrix, const FieldField< Field, scalar > &interfaceBouCoeffs, const FieldField< Field, scalar > &interfaceIntCoeffs, const lduInterfaceFieldPtrsList &interfaces)
virtual void	smooth (solveScalarField &psi, const scalarField &Source, const direction cmpt, const label nSweeps) const
virtual void	scalarSmooth (solveScalarField &psi, const solveScalarField &source, const direction cmpt, const label nSweeps) const
Public Member Functions inherited from lduMatrix::smoother
virtual const word &	type () const =0
	declareRunTimeSelectionTable (autoPtr, smoother, symMatrix,(const word &fieldName, const lduMatrix &matrix, const FieldField< Field, scalar > &interfaceBouCoeffs, const FieldField< Field, scalar > &interfaceIntCoeffs, const lduInterfaceFieldPtrsList &interfaces),(fieldName, matrix, interfaceBouCoeffs, interfaceIntCoeffs, interfaces))
	declareRunTimeSelectionTable (autoPtr, smoother, asymMatrix,(const word &fieldName, const lduMatrix &matrix, const FieldField< Field, scalar > &interfaceBouCoeffs, const FieldField< Field, scalar > &interfaceIntCoeffs, const lduInterfaceFieldPtrsList &interfaces),(fieldName, matrix, interfaceBouCoeffs, interfaceIntCoeffs, interfaces))
	smoother (const word &fieldName, const lduMatrix &matrix, const FieldField< Field, scalar > &interfaceBouCoeffs, const FieldField< Field, scalar > &interfaceIntCoeffs, const lduInterfaceFieldPtrsList &interfaces)
virtual	~smoother ()=default
const word &	fieldName () const noexcept
const lduMatrix &	matrix () const noexcept
const FieldField< Field, scalar > &	interfaceBouCoeffs () const noexcept
const FieldField< Field, scalar > &	interfaceIntCoeffs () const noexcept
const lduInterfaceFieldPtrsList &	interfaces () const noexcept

Static Public Member Functions
static void	smooth (const word &fieldName, solveScalarField &psi, const lduMatrix &matrix, const label blockStart, const solveScalarField &source, const FieldField< Field, scalar > &interfaceBouCoeffs, const lduInterfaceFieldPtrsList &interfaces, const direction cmpt, const label nSweeps)
Static Public Member Functions inherited from lduMatrix::smoother
static word	getName (const dictionary &)
static autoPtr< smoother >	New (const word &fieldName, const lduMatrix &matrix, const FieldField< Field, scalar > &interfaceBouCoeffs, const FieldField< Field, scalar > &interfaceIntCoeffs, const lduInterfaceFieldPtrsList &interfaces, const dictionary &solverControls)

Additional Inherited Members
Protected Attributes inherited from lduMatrix::smoother
word	fieldName_
const lduMatrix &	matrix_
const FieldField< Field, scalar > &	interfaceBouCoeffs_
const FieldField< Field, scalar > &	interfaceIntCoeffs_
const lduInterfaceFieldPtrsList &	interfaces_

Detailed Description

Variant of gaussSeidelSmoother that expects processor boundary cells to be sorted last and so can block later. Only when the cells are actually visited does it need the results to be present. It is expected that there is little benefit to be gained from doing this on a patch by patch basis since the number of processor interfaces is quite small and the overhead of checking whether a processor interface is finished might be quite high (call into mpi). Also this would require a dynamic memory allocation to store the state of the outstanding requests.

Source files

• nonBlockingGaussSeidelSmoother.H
• nonBlockingGaussSeidelSmoother.C

Definition at line 58 of file nonBlockingGaussSeidelSmoother.H.

Constructor & Destructor Documentation

nonBlockingGaussSeidelSmoother()

nonBlockingGaussSeidelSmoother	(	const word &	fieldName,
		const lduMatrix &	matrix,
		const FieldField< Field, scalar > &	interfaceBouCoeffs,
		const FieldField< Field, scalar > &	interfaceIntCoeffs,
		const lduInterfaceFieldPtrsList &	interfaces
	)

Definition at line 44 of file nonBlockingGaussSeidelSmoother.C.

References Foam::expressions::patchExpr::debug, lduMatrix::diag(), Foam::endl(), forAll, Foam::min(), Foam::Pout, and UPtrList::set().

Here is the call graph for this function:

Member Function Documentation

TypeName()

TypeName

(

"nonBlockingGaussSeidel"

)

smooth() [1/2]

void smooth ( const word &  fieldName, solveScalarField &  psi, const lduMatrix &  matrix, const label  blockStart, const solveScalarField &  source, const FieldField< Field, scalar > &  interfaceBouCoeffs, const lduInterfaceFieldPtrsList &  interfaces, const direction  cmpt, const label  nSweeps  )

static

Definition at line 91 of file nonBlockingGaussSeidelSmoother.C.

References UList::begin(), lduMatrix::diag(), lduMatrix::initMatrixInterfaces(), lduMatrix::lduAddr(), lduMatrix::lower(), lduAddressing::ownerStartAddr(), psi, Foam::fvc::sweep(), lduMatrix::updateMatrixInterfaces(), lduMatrix::upper(), and lduAddressing::upperAddr().

Here is the call graph for this function:

smooth() [2/2]

void smooth ( solveScalarField &  psi, const scalarField &  Source, const direction  cmpt, const label  nSweeps  ) const

virtual

Implements lduMatrix::smoother.

Definition at line 247 of file nonBlockingGaussSeidelSmoother.C.

References psi.

scalarSmooth()

void scalarSmooth ( solveScalarField &  psi, const solveScalarField &  source, const direction  cmpt, const label  nSweeps  ) const

virtual

Implements lduMatrix::smoother.

Definition at line 224 of file nonBlockingGaussSeidelSmoother.C.

References psi, and Foam::fvc::smooth().

Here is the call graph for this function:

---

The documentation for this class was generated from the following files:

• src/OpenFOAM/matrices/lduMatrix/smoothers/nonBlockingGaussSeidel/nonBlockingGaussSeidelSmoother.H
• src/OpenFOAM/matrices/lduMatrix/smoothers/nonBlockingGaussSeidel/nonBlockingGaussSeidelSmoother.C
